Basic Troubleshooting
LED not displayed
Check the power source is correct voltage
and correct polarity.
Display appears scrambled
Check that all connections are correct and tight.
Check that there is no harsh interference nearby.
Just display 999
Voltage out of range.
Check the connection of signals cable.
Installation Size
48mm+0.5
QP5586 (8-30VDC Power Source Measure DC8-30V)
Distributed by:
Electus Distribution Pty Ltd
320 Victoria Rd
Rydalmere NSW 2116 Australia
Phone: 1300 738 555
Fax:
1300 738 500
www.electusdistribution.com.au
Digital Panel Meter
MANUAL
Advertisement
Related Manuals for Electus Distribution QP5586
Summary of Contents for Electus Distribution QP5586
- Page 1 QP5586 (8-30VDC Power Source Measure DC8-30V) Basic Troubleshooting Digital Panel Meter LED not displayed Check the power source is correct voltage MANUAL and correct polarity. Display appears scrambled Check that all connections are correct and tight. Check that there is no harsh interference nearby.
- Page 2 WIRING DIAGRAM: QP5586 Digital Voltmeter Power Source DC8-30V measure DC8-30V FEATURES: DC - -Ultra-bright LED display DC + QP5586 Meter -Polarity: Automatic Sensing -Automatic Calibration upon zero reading for 0V input -High accuracy and Low cost -Easy to install -Re-calibrated by adjusting the calibration potentiometer -Ideal for auto, boat, industrial, commercial &...
