- Page 1 6” BENCH GRINDER WITH LED LIGHTS MODEL: KC-690LN INSTRUCTION MANUAL COPYRIGHT © 2024 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.
-
Page 2: Warranty Information
Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS Replacement parts for this product are available at our authorized King Canada service centers across Canada. Please use the 10 digit part numbers listed in this manual for all part orders where applicable. -
Page 3: General Safety Instructions For Power Tools
GENERAL SAFETY INSTRUCTIONS FOR POWER TOOLS 1. KNOW YOUR TOOL 13. DON’T OVERREACH. Read and understand the owners manual and labels affixed to Keep proper footing and balance at all times. the tool. Learn its application and limitations as well as its specific potential hazards. -
Page 4: Maintenance
SPECIFIC SAFETY INSTRUCTIONS FOR YOUR BENCH GRINDER 1. EYE PROTECTION. be pulled down, causing loss of control and pulling your hand Grinding ejects small particles at a high rate of speed. ALWAYS into the grinding wheel. Keep the tool rest within 1⁄16” from the wear safety glasses when using this machine. -
Page 5: Electrical Information
ELECTRICAL INFORMATION WARNING! ALL ELECTRICAL CONNECTIONS MUST BE DONE BY A QUALIFIED ELECTRICIAN. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! ALL ADJUSTMENTS OR REPAIRS MUST BE DONE WITH THE MACHINE DISCONNECTED FROM THE POWER SOURCE. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! POWER SUPPLY PROPERLY GROUNDED OUTLET WARNING: YOUR BENCH GRINDER MUST BE CONNECTED TO A 110V-... - Page 6 5) Spark deflector 13) Tool rest lock knob 6) Grinding wheel guard 14) Tool rest 7) Eye shield lock knob (right) 15) Grinding wheel (36 Grit) Specifications MODEL KC-690LN Wheel size 6” x 3/4” Arbor size 1/2” Motor 2.1 Amp. 3,450...
- Page 7 ASSEMBLY Installing spark deflectors to wheel guards 1. Install a spark deflector (A) Fig.3 to the front surface of the wheel guard (B) using two pan head screws, spring washer and washer (C). Repeat for the other side. 2. Adjust both spark deflectors (A) Fig.3 until they are 1/16” away from the grinding wheel (D).
-
Page 8: Assembly And Operation
5. Reinstall the grinding wheel cover (A) Fig.8, and reposition the tool rest and spark shield assemblies if they were removed. FIGURE 9 PARTS DIAGRAM & PARTS LISTS Refer to the Parts section of the King Canada web site for the most updated parts diagram and parts list.
