Instruction Manual
CAPiDi PREMIUM Baby Monitor
Thank you for purchasing our CAPiDi PREMIUM baby monitor. Your unit has been
manufactured and checked under the strictest possible quality control to ensure that
each monitor leaves the factory in perfect condition. In the unlikely event you find any
defects or have any problem, please contact our dealer or service center at
info@capidi.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PREMIUM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CAPIDI PREMIUM

Summary of Contents for CAPIDI PREMIUM

  • Page 1 Instruction Manual CAPiDi PREMIUM Baby Monitor Thank you for purchasing our CAPiDi PREMIUM baby monitor. Your unit has been manufactured and checked under the strictest possible quality control to ensure that each monitor leaves the factory in perfect condition. In the unlikely event you find any defects or have any problem, please contact our dealer or service center at info@capidi.com...
  • Page 2 Output Power: Baby unit 12dBm Parent unit 12dBm WARNING The CAPiDi Premium baby monitor should not be regarded as a medical device. Premature babies or those considered to be at risk should be under the supervision of your doctor or health personnel.

  • Page 3: Power Supply

    POWER SUPPLY Baby Unit (BU) and Parent Unit (PU) 1. Operation from battery pack The Li polymer battery pack is already installed in the unit. To exchange battery pack, remove the belt clip and slide open the battery door in direction as shown, take out the battery pack and disconnect from socket.
  • Page 4 a. Unit is switched on When BU is under charging, the BU no. indicator ○,7 on BU and the baby icon on PU will start pulsating. At the same time, the corresponding BU no. on PU will also light up. When PU is under charging, the parent icon on PU will start pulsating.
  • Page 5 CONTROLS LAYOUT ○,1. USB C port ○,12. Speaker ○,2. Speaker ○,13. Talk back and BU select button ○,3. Power on/off button ○,14. Battery cover lock button ○,4. Battery cover lock button ○,5. Night light ○,6. Microphone ○,7. BU no. indicator ○,8.
  • Page 6 PARENT UNIT (PU) SCREEN ICONS Parent icon Baby icon and corresponding BU No. Talk back icon Connected/out of range icon Battery icon Baby’s room temperature Night light icon Microphone sensitivity icon Vibration icon Volume level icon Sound level meter...
  • Page 7 PAIRING This process is to match the PU with BU so that they can communicate with each other while no other devices (even baby monitor of identical model) can interfere with you or receiving your signal. The PU and BU are already paired with preset code when they are shipped from factory.
  • Page 8 power on/off button is first pressed will be BU no. 1, second pressed will be BU no. 2 and third pressed will be BU no. 3. The BU no. indicator ○,7 will show their corresponding number.

  • Page 9: Operation

    OPERATION Baby unit (BU) 1. Press the power on/off button ○,3 for over 2 sec to switch on BU, the BU no. indicator ○,7 will show the battery level for 5 sec, then it will change showing its BU no. Short press the power on/off button ○,3 anytime can show its current battery level.
  • Page 10 Parent unit (PU) 1. Press the on/off button ○,9 for over 2 sec to switch on the unit, the screen will show the battery level (total 5 levels) of both PU and all BU for 5 sec (in case BU is switched on).
  • Page 11 c. Once the BU stops detecting any sound, PU will enter Standby mode after 5 sec. d. At anytime, parents can talk to baby by press and hold the talk back button ○,13. Speak towards the microphone ○,11 when the talk back icon show up on screen.
  • Page 12 i. Once PU battery level runs down, the parent icon and battery icon on PU screen will show flashing alongside with an alarm sound to alert parents. j. The various alarm is designed to have following priority : Baby’s cry > Out of range alarm > Battery low alarm Only one kind of alarm will be heard at any time to avoid confusion.
  • Page 13 c. Vibration setting Short press the volume up/down button ○,8 to set the vibrator ON or OFF. A level indicated means the vibrator is ON. Press power on/off button ○,9 to confirm your setting and move to next function. d. BU microphone sensitivity Short press the volume up/down button ○,8 to set the mic sensitivity.
  • Page 14 f. In case the PU is paired with more than one BU, the setting of microphone sensitivity and night light brightness will be done sequentially from BU no. 1 to BU no. 2 to BU no. 3.

  • Page 15: Standard Accessories

    PRECAUTIONS - Use only the supplied USB cable and power source with output voltage of not exceeding 5V DC, use of other may cause damage to unit. - When not using the unit for a long period of time, remove all batteries from the PU and the BU to avoid damage due to battery leakage.

  • Page 16: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE Problem Possible Causes Solution BU has no - PU is switched off - Switch on PU transmission - Mic sensitivity is too low - Adjust mic sensitivity higher within the menu - Battery has run down - Recharge battery using USB cable Always transmitting - Mic sensitivity is too high...
