- Page 1 Original Instructions Version 1 12V 1200A LITHIUM JUMP STARTER 23724 IMPORTANT: This product must be charged immediately after purchase and recharged every 3 months to maintain its performance.
-
Page 2: Product Reference
All photographs and drawings within this manual are document is part of the product; retain it for the life supplied by Draper Tools to help illustrate correct of the product, passing it on to subsequent holders. operation of the product. -
Page 3: Table Of Contents
2. Contents 1. Preface 1.1 Product Reference 1.2 Revisions 1.3 Understanding the Safety Content of This Manual 1.4 Copyright © Notice 2. Contents 3. Product Introduction 3.1 Intended Use 3.2 Specification 4. Health and Safety Information 4.1 Vehicle Battery Health and Safety Precautions 4.2 Jump Starter Health & Safety Precautions 4.3 Rechargeable Battery Health &... -
Page 4: Product Introduction
USB power bank supplying maintaining the product, and retain it for later use. several full charges to most smart phones. Any other application beyond the conditions established for use will be considered misuse. Draper Tools accepts no 3.2 Specification Stock No. 23724 Part No. -
Page 5: Health And Safety Information
– Review warning marks on all these products and defects are present; take it out of service until it on the engine. has been repaired or replaced. Contact Draper – When working near a lead-acid battery, ensure Tools for repair and replacement options. -
Page 6: Flashlight Health & Safety Precautions
4. Health and Safety Information 4.4 Flashlight Health & Safety Precautions • DO NOT turn the light on when the jump starter is being charged. • DO NOT shine the light directly into eyes. • DO NOT allow children to use the light. 4.5 Residual Risk The safety instructions in this manual cannot account for all possible conditions and situations that may occur. -
Page 7: Product Overview
5. Identification and Unpacking 5.1 Product Overview Jump starter lead port Flashlight 2 X USB output port Jump starter Display screen ON/OFF button DC output USB- C Input USB type-C charging cable – 7 –... -
Page 8: Identification And Unpacking
If any part is occurred during shipment. damaged or missing, do not attempt to use the product. Please contact the Draper Helpline; contact details can be found at the back of this manual. (B1) -
Page 9: Charging The Product
6. Charging the Product 6.1 Charging the Jump Starter 2. Press the ‘ON/OFF’ button (6) to turn on. Note: Before using for the first time, ensure that the jump starter is fully charged. 3. During charging, ‘IN’ will be displayed and the screen will turn off automatically once fully charged. -
Page 10: Jump Starting The Vehicle
7. Operating Instructions Important: Before preparing or using this product, read and understand all the safety instructions listed in this manual. 7.1 Jump Starting the Vehicle - Fig. 2. Green - Start Note: • This product is for 12V petrol 6 litre engine and diesel 4 litre engine cars only. -
Page 11: Operating Instructions
7. Operating Instructions 7.2 Using the built in Flashlight 3. To turn off the flashlight press the ‘ON/OFF’ button 1. To operate the flashlight, press and hold the ‘ON/OFF’ until the light goes out. button (6) for 3 seconds or until the light comes on. Note: the jump starter display will remain off and will 2. -
Page 12: Maintenance And Troubleshooting
8. Maintenance and Troubleshooting 8.1 General Maintenance • Do not use detergents to clean the product. • Check the battery level and recharge at least once every 3 months. • When not in use store in a dry well-ventilated area, out of direct sunlight and out of the reach of children. -
Page 13: Disposal
It also does not cover any damage caused by misuse, be free from defective materials and workmanship. Full careless or unsafe handling, modifications, or repairs details of the warranty period can be found on the Draper carried out by any personnel other than an authorised Tools Website. - Page 14 Notes – 14 –...
- Page 15 Notes – 15 –...
-
Page 16: Contact Details
Product Helpline: +44 (0) 23 8049 4344 Telephone Sales Desk: +44 (0) 23 8049 4333 General Enquiries: +44 (0) 23 8026 6355 Please contact the Draper Tools Product Helpline for repair and servicing enquiries. © Published by Draper Tools Limited © Published by Draper Tools Limited...
