ACTIVE-BOX
ACTIVE-BO
MANUAL INSTRUCT
MANUAL INSTRUCTION
designed and manufactured
designed and manufactured by
ITEC Tontechnik und
ITEC Tontechnik und
Industrieelektronik GesmbH
8200 Laßnitzthal 300
Austria / Europe
ACTIVE-BOX 500_EN_2024/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACTIVE-BOX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Itec ACTIVE-BOX

  • Page 1 ACTIVE-BOX ACTIVE-BO MANUAL INSTRUCTION MANUAL INSTRUCT designed and manufactured by designed and manufactured ITEC Tontechnik und ITEC Tontechnik und Industrieelektronik GesmbH 8200 Laßnitzthal 300 Austria / Europe ACTIVE-BOX 500_EN_2024/07...
  • Page 2: Table Of Contents

    ITEC LECTERN interfaced either via cable or wireless radio-transmission. However you are going to use the versatile ACTIVE-BOX, you will certainly add the perfect sound to many successful events with this compact high performance tool, which is so easy to handle.
  • Page 3: How To Stand The Active-Box

    Mains operation: If the mains/charger is connected to a 230-volt socket, the ACTIVE-BOX is not powered by the battery, but by the mains. The operating/battery level indicator lights up blue. If the ACTIVE-BOX is switched off , charging of the battery begins immediately.
  • Page 4: Music Attenuation (Optional)

    Cable connection: the ACTIVE-BOX is connected to the LECTERN by means of the attached cable. At the ACTIVE-BOX plug the signal cable in one of the LINE IN cinch sockets, at the LECTERN plug it in one of the LINE OUT cinch sockets. The volume control lets you choose how loud the ACTIVE-BOX shall be in propor- tion to the LECTERN;...
  • Page 5: Connecting An External Amplifier

    - avoid storage at temperatures below +5°C. CHARGE THE DEVICE AFTER EACH USE OR AFTER A LONG PERIOD OF NON-USE - if the ACTIVE-BOX is not used for months, it is recommended to switch the device on for several hours and then charge it again.
  • Page 6: Changing Batteries Of Radio Microphones

    Insert two new batteries. Note the poles! Battery type: 2 „AA“ 1.5V Mignon Battery status on display Hereby ITEC Tontechnik und Industrieelektronik GmbH declares that these radio systems comply with the directive 2014/53/EU. The EU Declaration of Conformity for each product is available at https://www.itec-audio.com/products/itec-microphones-and-conference-technology/.
  • Page 7: Controls

    7 Volume control for external player or built-in player (both optional) 8 Volume control for radio microphones 9 AUTO MUTE for music attenuation (optional) 10 DC 12V socket (for additional ITEC equipment) 11 Operating and battery status display www.itec-audio.com ACTIVE-BOX_EN_2024/07...
  • Page 8: The Integrated Usb-Player/Recorder (Optional)

    ACTIVE-BOX 15. USB/SD Card Player/Recorder (Optional) You can connect USB storage media to the USB port (e.g.: USB memory stick). ( 4 ) Alternatively, you can also use an SD card. SD card slot For playback only fi les in .mp3 format can be used! If a USB stick and an SD card are inserted when the device is switched on, the device chooses the USB stick as the current storage, otherwise the medium last used.
  • Page 9: Bluetooth (Optional)

    ACTIVE-BOX Previous title Start / Pause Next track On/Off , Volume Stop Playback Mode Recording SD-Card Slot LED-Display USB-Port 16. Bluetooth (Optional) • Switch on the Bluetooth receiver on the box ( 11 ) • Activate Bluetooth on the playback device (smartphone, tablet, ...).
  • Page 10: Bluetooth Build-In Module (Optional)

    ACTIVE-BOX 17. USB/BLUETOOTH BUILT-IN MODULE (OPTION) Digital Player with Recorder (see page 8) On/Off , Volume USB-Port LOCK LED Previous title Next track Stop LED-Display SCAN LED LINK button Playback Mode Recording On/Off Bluetooth Bluetooth • Turn on the Bluetooth receiver and the LOCK LED will fl ash GREEN.
  • Page 11 ACTIVE-BOX www.itec-audio.com ACTIVE-BOX_EN_2024/07...
  • Page 12 Miscellaneous Speaker stand, carrying bag, rain cover, fl ight case, various audio connection cables All information without guarantee. Subject to technical changes. ITEC Tontechnik und Industrieelektronik GesmbH, A-8200 Gleisdorf, Lassnitzthal 300 Tel.: +43 (0)3133 / 3780-0, offi ce@itec-audio.com, www.itec-audio.com www.itec-audio.com...
