- Page 1 User Manual EV DC Charger HEVDC-(12,25)S2C5...
-
Page 2: Copyright Notice
User manual Copyright Notice • Copyright© 2024 Qingdao NaHui Intelligent Technologies Co.,Ltd. All Rights Reserved. • Description in this document may contain predictive statements regarding financial and operating results, product portfolio, new technology, configurations and features of product. Several factors could cause difference between actual results and those expressed or implied in the predictive statements. -
Page 3: Table Of Contents
Chapter 3 Location Requirements Chapter 4 Equipment Installation and Connection Chapter 5 How to Use 5.1 LED Indicator Status 5.2 Haier Smart Cube Download and Login 5.3 Binding RFID Card 5.4 Use of Equipment 5.4.1 App-managed or RFID Card-based Charging Mode (Recommended) 5.4.2 Unauthenticated Charging Mode... -
Page 4: Overview
User manual User Manual Overview Introduction This document mainly describes product information, networking, and system operation and maintenance of HEVDC- 12S2C5 and HEVDC-25S2C5 (hereafter referred to as EV DC Charger). Readers This document is suitable for product users and professionals Sign Definition The following signs may be used in the document to indicate security precautions or key information. -
Page 5: Chapter 1 Safety Precautions
User manual Chapter 1 Safety Precautions Basic Information Before installing, operating, and maintaining the equipment, familiarize yourself with this document. The "Danger ", "Warning", "Caution" items described in this manual are only supplementary to all precautions. The Company shall not be liable for equipment damage or property loss caused by the following reasons: •... -
Page 6: Safety Requirements
User manual Safety Requirements • Do not expose the equipment to high temperature or heat sources, such as ignition sources, heaters, etc. • Do not clean or soak the equipment with water, alcohol, or oil to avoid power leakage or battery pack leakage. •... -
Page 7: Chapter 2 Product Introduction
When connected to elevators and other control devices. • Any other critical systems. Chapter 2 Product Introduction 2.1 Model Designation EV DC Charger includes the following models: • HEVDC-12S2C5 • HEVDC-25S2C5 Fig.1-1 Model designation (example) HEVDC-12S2C5 Definitions Description Product series... -
Page 8: Description
User manual 2.2 Description EV DC Charger is a bidirectional DC/DC charging & discharging system and can be used with our Energy Controller, as well as battery pack Battery to charge and discharge power Battery of electric vehicles. 2.3 Product Appearance Description Charging connector holder for placing the charging connector Charging connector cable... -
Page 9: Label Description
User manual 2.4 Label Description Symbols Definition Danger! High Voltage High voltage exists inside the equipment when powered on. Do not open the casing when the equipment is running. Any maintenance or servicing operations must be performed by trained and skilled electrical engineers. Warning! Life at risk. -
Page 10: Typical Networking
I1. Backup Power Equipment I2. Non-backup Power Distribution Panel J. Power Sensor K. Power Grid L. Haier Smart Cube App M. Router N. Antenna O. CommMod • J features data collection from grid-connected points to realize zero power grid connection. For partial backup, J can be left un-configured. - Page 11 D. Power Equipment E. Distribution Panel F. Vehicle G. Power Sensor H. Power Grid I. Haier Smart Cube App J. Router K. Antenna L.CommMod It is recommended to use FE and WLAN for communication methods. After creating new systems, users must...
-
Page 12: Chapter 3 Location Requirements
User manual Chapter 3 Location Requirements The warranty applies when the equipment has been installed properly for its intended use and in accordance with the operating instructions. Installation Environment Requirements • Do not install the equipment in smoky, flammable, explosive, or corrosive environments. •... -
Page 13: Mounting Surface
• No water or electricity is routed inside the carrier to prevent drilling hazards during equipment installation. Energy Controller EV DC Charger can only be installed underneath the inverter. HEVDC-12S2C5，HEVDC-25S2C5 Energy Controller HEVDC-12S2C5，HEVDC-25S2C5 • There will be errors in the actual distance under different installation environments, and the figure is for... -
Page 14: Chapter 4 Equipment Installation And Connection
User manual Chapter 4 Equipment Installation and Connection Equipment installation and connection must only be completed by the installer certified by the Company. For more information, refer to EV DC Charging Module Installation Guide. Chapter 5 How to Use 5.1 LED Indicator Status The status of EV DC Charger is indicated by the DC charger indicator on the front of the inverter. -
Page 15: Haier Smart Cube Download And Login
User manual 5.2 Haier Smart Cube App 1. Download the app. Haier Smart Cube Haier Smart Cube Provide your email account to the installer for signing up. 3. After signing up your account, the installer will ask you to activate your account. -
Page 16: Binding Rfid Card
User manual 5.3 Binding RFID Card Go to "Setting"→" Charging Setting"→"Card Management" and bind your RFID Card. • If an error occurs when you bind the RFID Card, you can click and delete the RFID Card on the "Card Management" page. 5.4 Use of Equipment EV DC Charger supports app-managed charging mode, RFID Card-based charging mode, and unauthenticated charging mode. -
Page 17: App-Managed Or Rfid Card-Based Charging Mode (Recommended)
User manual 5.4.1App-managed or RFID Card-based Charging Mode (Recommended) 1.Install the charging connector in place. 2.Start charging on the equipment. • Method 1: App-managed charging mode Start charging from "Charger"→"Start." • Method 2: RFID Card-based charging mode Swipe the RFID Card. -
Page 18: Unauthenticated Charging Mode
User manual 5.4.2 Unauthenticated Charging Mode 1. On the "Setting"→"Charging Setting" page, turn "Authentication" off, that is, 2. Install the charging connector in place. • It should be noted that when the unauthenticated charging mode is enabled, any vehicles can use this equipment for charging. -
Page 19: Other Settings Of Haier Smart Cube
User manual 5.5 Other Settings of Haier Smart Cube For more information about the app settings, refer to Haier Smart Cube User Manual. Chapter 6 Routine Maintenance To ensure the long-term running of the equipment, you are advised to perform routine maintenance according to this section. - Page 20 20240509_V1.0...
