Installation Guide
EV AC Charger
HEVAC-(7,11,22) T2C5
HEVAC-(7,11,22) T2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEVAC-7T2C5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Haier HEVAC-7T2C5

  • Page 1 Installation Guide EV AC Charger HEVAC-(7,11,22) T2C5 HEVAC-(7,11,22) T2...
  • Page 2: Copyright Notice

    Copyright Notice Copyright Notice • Copyright© 2024 Qingdao NaHui Intelligent Technologies Co.,Ltd. All Rights Reserved. • Description in this document may contain predictive statements regarding financial and operating results, product portfolio, new technology, configurations and features of product. Several factors could cause difference between actual results and those expressed or implied in the predictive statements.
  • Page 3: Table Of Contents

    Contents Contents Overview..................................3 Chapter 1 General Requirements...........................4 Chapter 2 Personnel Requirements ........................5 Chapter 3 Handling and Transportation Requirements..................5 Chapter 4 Storage Requirements...........................5 Chapter 5 Operating Requirements........................6 5.1 Routine Requirements..........................6 5.2 Equipment Installation ..........................7 5.3 Cable Connection ............................7 5.4 Equipment Maintenance and Replacement ....................8 Chapter 6 Introduction .............................
  • Page 4 Contents Contents 10.7 Installation of SIM Card..........................25 10.8 Installing Panel............................26 10.9 Installing Cable Holder and Placing Charging Connector..............27 Chapter 11 Power-on and New System Creation................... 28 Chapter 12 Downloading “Haier Smart Cube” App and Creating New System........29 。...
  • Page 5: Overview

    Important Notice Overview Introduction • This document describes the precautions for installing, operating, and maintaining of the EV AC Charger. Target readers • This document is intended for: • Trained and qualified installation personnel • Technical support engineer Sign Definition •...
  • Page 6: Chapter 1 General Requirements

    Important Notice Chapter 1 General Requirements Before installing, operating, and maintaining the equipment, familiarize yourself with this document. The "Danger ", "Warning", and "Caution" items described in this manual are only supplementary to all precautions. The Company shall not be liable for equipment damage or property loss caused by the following reasons: •...
  • Page 7: Chapter 3 Handling And Transportation Requirements

    Important Notice Chapter 3 Handling and Transportation Requirements • Wear personal protective equipment, such as protective gloves and safety shoes, when moving equipment. • Select a proper transport mode based on the weight of the equipment. • When using a forklift, place the fork knife in the middle of the equipment, and bind the fork knife according to the actual situation.
  • Page 8: Important Notice

    Important Notice Chapter 5 Operating Requirements 5.1 Routine Requirements Danger High voltage, danger: • Live operation of the equipment (including but not limited to installation, wiring, replacement, etc.) is prohibited. • Do not extend sharp objects or fingers into the equipment. •...
  • Page 9: Equipment Installation

    Important Notice 5.2 Equipment Installation Warning • When handling the equipment, be prepared to support the load in order to avoid slips and injuries. Drilling Safety • Do not drill holes on the equipment. • Wear safety goggles and protective gloves when drilling holes. •...
  • Page 10: Chapter 6 Introduction

    Installation Guide • Trained or experienced electrical personnel are required to operate the equipment. • Operators should be familiar with national/regional laws, regulations and standards, the structure and working principle of relevant systems. • Please read carefully the operating requirements and precautions in this document and Important Notice before operating.
  • Page 11: Chapter 7 Pre-Installation Check

    Installation Guide HEVAC-7/11/22 T2 • You are advised to connect cables through bottom routing holes (holes 3 and 5). • If cables are connected through top routing holes (holes 1 and 2), please install the equipment in a sheltered location to prevent water ingress after prolonged water accumulation on the top. Description Top routing hole for communication cable Top routing hole for AC input cable...
  • Page 12: Protective Equipment

    Installation Guide Protective equipment Safety hat Safety Dust mask Protective Insulating Insulating glasses gloves gloves shoes Installation tool Power drill Vacuum Wire cutter Crimp tool Crimping pliers Wire stripper cleaner Scissors Insulation screwdriver Heat shrinkable sleeve Heat gun Cable tie Digital torque open- Marker Rubber mallet...
  • Page 13 Users should prepare type B MCB compliant with IEC/EN 60898 with recommended specifications shown below. Users can omit this requirement if they have installed compliant AC switches. Model Number of Poles, MCB Rated Current, MCB HEVAC-7T2C5 1P+N 40 A HEVAC-7T2 HEVAC-11T2C5...
  • Page 14 Installation Guide Self-supplied Cables The grid power options include TT, TN-S, TN-C-S, and IT. Users can prepare cables according to their local grid power mode. Recommended Specification Cable Name HEVAC-7T2C5 HEVAC-11T2C5 HEVAC-22T2C5 HEVAC-7T2 HEVAC-11T2 HEVAC-22T2 Five-core/four-core copper Three-phase five- core cables for outdoor use...
  • Page 15: Chapter 8 Equipment Installation Creation

    Installation Guide Chapter 8 Equipment Installation Creation The warranty applies when the equipment has been installed properly for its intended use and in accordance with the operating instructions. Installation environment • Do not install the equipment in smoky, flammable, explosive, or corrosive environments. •...
  • Page 16: Installation Position

    Installation Guide Installation position • Do not tilt or overturn the equipment to ensure that it is installed horizontally. • Do not install the equipment in a place easily touched by children. • Do not install the equipment in mobile scenarios such as RVS, cruise ships, and trains. •...
  • Page 17 Installation Guide Install the wall mounting fittings. Wall Install and secure the terminal block.
  • Page 18: Chapter 10 Cable Connection

    Installation Guide Chapter 10 Cable Connection 10.1 Routing AC input cables can be divided into three-phase five-wire system (L1/L2/L3/N/PE), three-phase four-wire system (L1/L2/L3/PE), single phase (L/N/PE), and two phases (L1/L2/PE), depending on grid power mode. This section describes the routing method using the three-phase five-wire system. Bottom Routing (recommended) Top Routing Install the water-proof connector at the bottom to the top before connecting cables.
  • Page 19: Ac Input Cable Connection

    Installation Guide 10.2 AC Input Cable Connection AThree-phase five-wire system Three-phase four-wire system (3 × 400 V) (L1/L2/L3/N/PE) (3 × 230 V) (L1/L2/L3/PE) Two phases (1 × 230 V) (L1/L2/PE) Single phase (1 × 230 V) (L/N/PE) • You are recommended to place the PE core at the lowest layer during routing. •...
  • Page 20 Installation Guide EVAC The stripping length (A) of cable insulation is determined by the EVAC port to which cables are connected. EVAC...
  • Page 21: Rs485/Do Signal Cable Connection

    Installation Guide 10.3 RS485/DO Signal Cable Connection Definitions of RS485 Ports and Connection Relationship with Power Sensor Connect one end of the RS485 signal cable to EVAC and the other end to Power Sensor. Definitions HMT-CT120A(SDM630 MCT 40mA) RS485_A RS485 signal_A+ RS485_B RS485 signal_B- For appearance and connection details of the Power Sensor, refer to the User Manual supplied with the product.
  • Page 22: Optional) Connection Of Pen Control Lines

    Installation Guide 10.4 (Optional) Connection of PEN control lines Definitions of MCB Ports and Connection Relationship with EVAC Smart PEN Breaker Definitions EVAC Smart PEN Breaker[1] Output N level Terminal C1 Output L level Terminal C2 Note [1]: The corresponding wiring terminal of the EVAC Smart PEN Breaker EVAC Smart PEN Breaker EVAC For information on the specific installation and wiring operation of the EVAC Smart PEN Breaker, please refer to...
  • Page 23 Installation Guide...
  • Page 24: Optional) Connection Of Linky Smart Meter Signal

    Installation Guide 10.5 (Optional) Connection of Linky Smart Meter Signal Definitions of Meter Ports and Connection Relationship with Linky Smart Meter TIC port of Linky Smart Meter Meter_IN Meter_OUT For information on the specific installation and wiring operation of the Linky smart meter, please refer to the user manual supplied with the product.
  • Page 25: Fe Signal Cable Connection

    Installation Guide 10.6 FE Signal Cable Connection Connect one end of the FE signal cable to EVAC and the other end to a router. TIC port of Linky Smart Meter Meter_IN Meter_OUT ① White orange ② Orange ③ White green ④...
  • Page 26: Installation Of Sim Card

    Installation Guide 10.7 Installation of SIM Card • Install the SIM card when 4G communication is enabled. • SIM cards are supplied by users and standard SIM cards are recommended (size: 25 mm×15 mm, capacity ≥ 64 KB, traffic ≥ 128 MB/month).
  • Page 27: Installing Panel

    Installation Guide 10.8 Installing Panel Check the following items against the provided table, tighten routing holes, and install the panel. Check Item The equipment is securely installed. AC cables and signal cables are properly connected without omission. Lock screws or terminals are installed in place without any looseness. Cutouts of cable ties are free of burr or sharp edges.
  • Page 28: Installing Cable Holder And Placing Charging Connector

    Installation Guide 10.9 Installing Cable Holder and Placing Charging Connector • This section applies only to HEVAC-7/11/22T2C5 Install the cable holder. Place the charging connector.
  • Page 29: Chapter 11 Power-On And New System Creation

    2. Observe the indicator status on the front panel of EVAC to understand the operating conditions. 3. When the indicator turns green and is steady on or breathing blinking, create a new system in the Haier Smart Cub app. Illuminated...
  • Page 30: Chapter 12 Downloading "Haier Smart Cube" App And Creating New System

    Installation Guide Chapter 12 Downloading “Haier Smart Cube” App and Creating New System Download the “Haier Smart Cube” app to initiate the creation of a new system for your equipment. Haier Smart Cube Haier Smart Cube...
  • Page 31 Installation Guide The following steps are different when the equipment has already been connected or not connected to the internet (that is, FE and 4G communication fault), as described below. Already connected to the internet: Set parameters as needed. Rated Household Circuit Breaker Manually locate the Perform upgrades Current >...
  • Page 32 Installation Guide Not connected to the internet (that is, FE and 4G communication fault): If the equipment has already been connected to the internet, click this button and go to the Create New System page and perform operations by referring to the description in the "already connected to the internet"...
  • Page 33 Installation Guide Disconnect from the WLAN hotspot After creating a new system, the installer should ask the owner to check the email sent from "NAHUI cloud" within 24 hours to activate the account, log in to the app, and bind the IC card.
  • Page 34 20240418_V1.0...
