USER'S MANUAL
DM0356
DM0357
MIRROR CABINET
WITH LED LIGHTING
OPTIONAL FUNCTION WITH SENSOR SWITCH/ TOUCH SWITCH/ ROCKER
SWITCH/ANTI-FOG/DIGITAL CLOCK/ BLUE BOOTH SPEAKER/
*Frost pattern may vary depending on model
Please read this manual carefully before installation and keep it properly.
Installation should be carried out by a qualified electrician.
Make sure the power supply is disconnected before installation.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LIVING AND HOME DM0356
Summary of Contents for LIVING AND HOME DM0356
- Page 1 USER'S MANUAL DM0356 DM0357 MIRROR CABINET WITH LED LIGHTING OPTIONAL FUNCTION WITH SENSOR SWITCH/ TOUCH SWITCH/ ROCKER SWITCH/ANTI-FOG/DIGITAL CLOCK/ BLUE BOOTH SPEAKER/ *Frost pattern may vary depending on model Please read this manual carefully before installation and keep it properly.
- Page 2 WARNING IMPORTANT FOR INSTALLATION IN BATHROOM - This product is suitable for installation in bathroom zones 2 and above as defined by the IEE Wiring Regulations. Please refer to the diagram provided below. - This product is for indoor use only. - This product requires a ground connection.
- Page 3 IMPORTANT FOR THE MIRROR - Never strike the mirror glass with hard or sharp objects. - Wipe the product with a soft, dry, non-abrasive cloth for best results. - Never use detergents or abrasive materials on the mirror's finished surface or exposed edges. - Avoid detergents containing ammonia, vinegar or chlorine.
-
Page 4: Before You Start
BEFORE YOU START 1. Check the wall to be installed carefully: a. Ensure that the wall is structurally sound, e.g. a strong and level clay brick wall, or a wall/frame that has been approved by a professional as meeting the installation criteria. b. - Page 5 INSTALLATION GUIDE 1. POSITIONING 1.1 Before installation, confirm that the specified wall is a load-bearing wall capable of supporting the weight of the cabinet. Ensure that any wiring in the wall is avoided when drilling to prevent damage during installation. 1.2 Measure the height and position of the cabinet on the wall.
- Page 6 DOUBLE DOOR CABINET 1.4. For models equipped with a sensor switch on the bottom right-hand side of the cabinet, ensure a minimum distance of 150 mm from the wall on the sensor switch side. Additional space may be required for different wall surfaces depending on the site conditions. It is recom- mended to carry out tests to determine the reaction distance of the sensor switch before posi- tioning the cabinet and drilling holes in the wall.
- Page 7 2.4 Connect the wires from the wall. SINGLE DOOR CABINET DOUBLE DOOR CABINET *Please refer to 3.1 content for electricity connecting details. 2.5 Place the cabinet in the designated location and secure the cabinet by mounting the screws to the wall. Ensure that the screws are securely tightened and correctly positioned and confirm that the cabinet is securely fastened in place.
-
Page 8: Other Notes
OTHER NOTES 1. The doors and cabinet are assembled with hinges (hinges may vary by design). After prolonged transport, there may be slight displacement between the mirror door and the cabinet. Use a tool to adjust the soft hinges to ensure that the mirror door is in the correct position. - Page 9 OPERATION GUIDE LED LIGHTING SWITCHES Different models of cabinets are equipped with different switches. 1. Sensor switch The sensor switch is typically located on the bottom right side of the cabinet or under the bottom right side (varies by model). See Section 1.4 for sensor switch installation guidelines.
-
Page 10: Bluetooth Speaker
TIME DISPLAY FUNCTION (for models with digital clock function) TIME DISPLAY BUTTONS: Located on the right side of the mirror door, there are two buttons, one labelled "H" for hour setting and the other labelled "M" for minute setting. 1). Press and hold the "H" button for two seconds to activate the hour adjustment mode. - Page 11 The theoretical range of the Bluetooth signal is ≤ 7 metres. However, the effectiveness of the Bluetooth signal may be affected by factors such as indoor wall obstructions, signal conditions, and the compatibility of connected devices in the installation environment. Therefore, the actual range may vary and should be determined by the specific environment.
-
Page 12: Circuit Diagram
CIRCUIT DIAGRAM CDC1: Models with anti-fog/sensor switch CDC2: Models with anti-fog/ touch switch/ shaver socket... - Page 13 CDC3: Models with anti-fog/ sensor switch/ shaver socket/digital clock CDC4: Models with anti-fog/ sensor switch/ shaver socket/ bluetooth...
