- Page 1 Android Control Card Y08 Instructions Version：Ver.1.1...
- Page 2 Statement Dear user friend ， thanks for choosing SHENZHEN SYSOLUTION TECHNOLOGY CO.,LTD (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product. We strive to be precise and reliable when writing the document，and the content may be modified or changed at any time without notice.
- Page 3 Update Record Version Details Date Ver.1.0 Initial 2020.09.27 Ver.1.1 Update content 2024.08.29...
-
Page 4: Table Of Contents
Catalogue Overview ..............................1 Functional Features ..........................3 Interfaces ..............................5 Technical Parameters ..........................7 Hardware Connection Diagram ....................... 10 Ledset2.3 Configuration ........................11 LEDOK Upload /Publish Program ....................16 Network Configuration ........................21 Wired Ethernet Configuration ..................21 WiFi Configuration ......................22 4G Setup ..........................23 AIPS Cloud Platform Register ......................25 Register For AIPS Platform ......................25 AIPS Cloud Programing ........................ -
Page 5: Overview
Sysolution Y08 is an outdoor small space screen dedicated control card, performance configuration series using industrial-grade quad-core processor, running frequency 1.5GHz, memory support 1GB + 8GB (compatible with 2GB + 16GB need to be customized) LPDDR3, industrial-grade relative to commercial-grade CPU performance is generally low, but the limit of the temperature difference can be reached -40 °... - Page 6 The software and platform are designed for stable operation and efficient maintenance. Painted with UV three-proof adhesive, national standard double 85 protection level, dust-proof, moisture-proof, anti-static, and anti-smoke. www.sysolution.net...
-
Page 7: Functional Features
1080P video hard decoding, 1GB of operating memory, 8GB of internal storage space, the user can use 4GB; The user terminal connects to the WiFi hotspot that comes with the Y08, the default SSID number is "SN number" and the default password is "12345678";... - Page 8 11. Support broadcasting programme by way of programme lists. 12. Support USB camera. 13. Expandable amplifier module R16 (optional), direct two 30W speakers for audio playback; 14. Supporting software: AIPS 4.0 cloud publishing platform, PC-based software LedOK Express, mobile app: LedOK lite. www.sysolution.net...
-
Page 9: Interfaces
Optional RL2 brightness sensor interface External testing sos, eme, busy, spa, acc 485 interface Baud rate 9600 TTL/232 interface Baud rate 9600 (two choices default TTL) Output GPS interface GNSS GPS/Beidou/Glonass Connector WIFI interface IEEE 802.11b/g/n 2.4G 4G interface 4G module interface www.sysolution.net... - Page 10 External operation indicator, external reset (optional and connector to be specified on order) HUB75 interface 8 x HUB75 signal outputs Power Red light always Normal indicator FPGA Red slow flash Normal operation Indicator Red slow flash Normal operation indicator www.sysolution.net...
-
Page 11: Technical Parameters
Technical Parameters Product Description features Main: Y08 (no 4G), Y08-CH (China 4G full network access), Y08-G (global Model access, recommended abroad) Y08: 170,000 dots, limiting resolution 1024(W)or 1024(H), custom Pixel resolution support Communication Network port, WiFi, USB stick, optional 4G module Cortex-A35 quad-core at 1.5GH... - Page 12 -China（China/India） FDD-LTE：B1/3/5/8 TDD-LTE：B38/39/40/41 Mandatory certification：SRRC/ NAL/ CCC Y08-CH TDSCDMA：B34/39 Other：WHQL WCDMA：B1/8 CDMA 1X/EVDO：BC0 GSM：B3/5/8 Carrier certification：AT&T/ T-Mobile/Rogers/ -North America（North TelusVerizon/AT&T (FirstNet)/T-Mobile/U.S. America） Cellular/Rogers/ Telus Y08-NA FDD-LTE ： Mandatory/conformance certification: ： FCC/ B2/4/5/7/12/13/17 IC/ PTCRB WCDMA： B2/4/5 Other：WHQL -Eurasia （EMEA/Korea/Thailand/ Carrier certification：Vodafone/Deutsche India and other Asian Telekom/SKT/ Telefónica...
- Page 13 -Latin America (Latin America /Australia / New Zealand） Mandatory/conformance certification ： GCF/ Y08-LA FDD-LTE：B1/3/5/7/8/28 FCC/ Anatel/ NCC/RCM TDD-LTE：B40 Other：WHQL WCDMA：B1/2/5/8 GSM：B2/3/5/8 -Global（Global） Carrier certification：Deutsche Telekom/ FDD-LTE： Verizon/ AT&T/ Sprint/U.S. Cellular/ Telus B1/2/3/4/5/7/8/12/13/ Mandatory/conformance certification：GCF/ 18/19/20/25/26/28 Y08-G CE/ FCC/ PTCRB/ IC/ Anatel/IFETEL/ SRRC/ TDD-LTE：B38/39/40/41...
-
Page 14: Hardware Connection Diagram
Hardware Connection Diagram www.sysolution.net... -
Page 15: Ledset2.3 Configuration
1. Open Ledset2.3 software, enter Professional configuration mode and start smart settings. Note: If software can not detect Y08 controller, please turn off windows firewall and exit your anti-virus software. Open Ledok Express software and try to detect Y08 controller IP address. - Page 16 If LEDOK Express can not detect Y08 controller either, please check if Y08 running lights are all normal working status. if the Y08 working lights all fine but can not detect Y08 controller,please contact our after sales technician for help. (If Ledset2.3 detect Y08 controller correctly then please go on next steps) 2.
- Page 17 3. Choose driver IC and decode type according to the led module, input one led module width and height pixels www.sysolution.net...
- Page 18 4.Choose scan lines 5. Please watch the colors. www.sysolution.net...
- Page 19 6. Please click in the software one dot by one dot according to the flashing dot in the led module, click apply after finishing (Note:please do not press direction key in the keyboard or maybe the software will have bugs. ) www.sysolution.net...
-
Page 20: Ledok Upload /Publish Program
As shown in the figure, the top is the type of material that can be added, you can add video, pictures, text, digital clocks, analog clocks, etc., according to the need to choose, this article to pictures and videos as an example. www.sysolution.net... - Page 21 The default playback time of the added photo material is 10s, if you need to change the playback time, you can change it in the widget properties. www.sysolution.net...
- Page 22 Click the ‘+’at the top left to add a second material and the ‘X’ to delete the material page. When the program is finished, you can click ‘Play/Stop’ on the top to preview the program. You can close the preview by clicking the right mouse button. www.sysolution.net...
- Page 23 Click publish button after done all setup, and select the controller id and click send, 100% means send success. www.sysolution.net...
- Page 24 The finished program will present in the solution management. At this time, you can check the program and click "Edit" to enter the program page again to modify the program, and then follow the above steps to send the program. www.sysolution.net...
-
Page 25: Network Configuration
Network configuration，first is Wire，can setup the controller IP address. NOTES： Controller will get access to internet by wire as first priority. Must remove the LAN cable from controller if choose WIFI or 3G internet and choose automatically acquisition IP. www.sysolution.net... -
Page 26: Wifi Configuration
Wait for about 3 minutes，controller will come online. Please watch the“Internet”light， if it flashing regularly means online success ， go to AIPS platform (www.ledaips.com) and check it. NOTES： If could not scanning the WiFi， please try to turn on/turn off Software or WiFi Switch. www.sysolution.net... -
Page 27: 4G Setup
If the ‘internet’ light does not flash, check whether the APN is set correctly.If there is no error, you can reboot the controller and wait for it to go online. www.sysolution.net... - Page 28 NOTES： If controller can’t get online success，please checking following things： 4G antenna has plugged correctly? Y/M series controller，make sure the LAN cable removed. APN is correct or not？ (Consult with the carrier" available) SIM card has activate? SIM card has enough money and 4Gdata service? www.sysolution.net...
-
Page 29: Aips Cloud Platform Register
AIPS Cloud Platform Register Register For AIPS Platform Visit www.ledaips.com and choose Register to starting input related information，click done and verified the link sent by email，finish the register. Oversea address：www.ledaips.com www.sysolution.net... - Page 30 www.sysolution.net...
-
Page 31: Aips Cloud Programing
Click “add simple program” button and set correct screen width and height pixels and click OK. Input program name and select the material from left side ， here are 3 zones including material in the left side ， program editing in the middle and preview window in the right side. www.sysolution.net... - Page 32 Choose materials and set program name，can check preview in the right window. Can set the display duration time here，see screenshot in below： www.sysolution.net...
-
Page 33: Advanced Program
Will see program in the list after save. Advanced Program Advanced program including image， video， clock， text， audio and support more layers. Clcik “add advanced program” button and set correct screen width and height pixels，click ok. www.sysolution.net... - Page 34 Here are 4 zones including media group，time panel，preview and program property. Click “New layer ” button and select media file then add to the time panel，for example： select video file and add to time panel. www.sysolution.net...
- Page 35 Can set the program parameters，start and end time， www.sysolution.net...
- Page 36 Save and quit after setup all parameters and program name. Then jump to program list interface ， you can click green button of create task quickly and then select controller and send. www.sysolution.net...
- Page 37 Use the “Edit” button to modify the existing program. Add multi-line text，click the text (single or muti-text)and add to the time panel www.sysolution.net...
- Page 38 Setup parameters for text，including the start and end time. Setup the text color，font size and add more pages，please pay attention to our TIPS message in below，save and quit after finish. www.sysolution.net...
-
Page 39: Send Program
Send Program Click “create task quickly” button in the program list interface and will jump to the terminal interface directly. Select the controller and send program www.sysolution.net... - Page 40 In the bottom part of terminal interface ， will see program task then choose the program task and click send. www.sysolution.net...
