- Page 1 LCD Controller Instructions Version：Ver.1.0...
-
Page 2: Statement
Statement Dear user friend, thanks for choosing Shanghai Xixun Electronic Technology Co., Ltd. (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product. - Page 3 Update Record Version Details Date Ver.1.0 Initial Sep 2020 Note:The document is subject to change without prior notice.
-
Page 4: Table Of Contents
Catalogue Statement ............................2 Copyright ............................. 2 Trademark ............................2 Overview ............................... 1 Functions And Features ........................... 2 Interfaces ............................... 3 Technical Parameters ..........................4 Software Operation Procedures ......................6 Hardware Connection Diagram ......................7 Software Connection ..........................8 LedOK System Parameters ........................9 LED full screen width and height settings ................ -
Page 5: Overview
Overview L20 board integrates multimedia decoding, LCD driver, Ethernet, HDMI, WIFI, 4G, Bluetooth, supports most of the current popular video and picture format decoding, supports HDMI video output/input, dual 8/10-bit LVDS Interface and EDP interface, can drive various TFT LCD displays, greatly simplify the system design of the whole machine,... -
Page 6: Functions And Features
USB data import and other functions; Convenient management: The user-friendly playlist background management software is convenient for advertising playback management and control. it is easy to understand the playback situation through Play log; Software: LedOK Express. www.sysolution.net... -
Page 7: Interfaces
Interfaces www.sysolution.net... -
Page 8: Technical Parameters
Supports multiple playback modes such as loop, timing, and insertion Network 4G, Ethernet, support WiFi/Bluetooth, wireless peripheral expansion Support Video Support MP4 (.H.264, MPEG, DIVX, XVID) format Playback USB2.0 2 USB host, 4 USB sockets Interface Mipi Camera 24 pin FPC interface, support 1300w Camera (optional) www.sysolution.net... - Page 9 1, support 1080P@120Hz, 4kx2k@60Hz output Output HDMI Input HDMI input，30pin FPC custom interface Audio and Support left and right channel output, built-in dual 8R/5W power video output amplifier RTC real time Support clock Timer Switch Support System Support SD card/computer update Upgrade www.sysolution.net...
-
Page 10: Software Operation Procedures
Software Operation Procedures www.sysolution.net... -
Page 11: Hardware Connection Diagram
Hardware Connection Diagram www.sysolution.net... -
Page 12: Software Connection
If it is connected by a network cable, please open the "RJ45 Cable directly connected" in the lower left corner of the software interface. www.sysolution.net... -
Page 13: Ledok System Parameters
LED full screen width and height settings Click Terminal control and select the controller，go to Advanced parameters and input password 888 to enter setup interface. In the advanced configuration interface, enter the LED screen width and height parameters and click "Set" to prompt success. www.sysolution.net... - Page 14 www.sysolution.net...
-
Page 15: Ledok Configuration Network
IP parameters of the selected control card. Control card access network priority wire network. When selecting wireless WiFi or 4G network access, the wired network must be unplugged, and the IP address of the sending card is obtained automatically. www.sysolution.net... -
Page 16: Method 2: Wifi Enabled
At this time, you can log in to the cloud platform www.m2mled.net to send the program. Tips If the WiFi cannot go online, you can troubleshoot the following situations: Check whether the WiFi antenna is tightened; www.sysolution.net... -
Page 17: Method 3: 4G Configuration
Status button, and then select "Operator" to get the corresponding APN information, if the operator cannot be found, you can check the "Custom" checkbox, Then manually enter the APN information. After setting the 4G parameters, wait for about 5 minutes for the control card to www.sysolution.net... - Page 18 Whether the status of the control card is normal, and whether the available flow of the control card in the current month is greater than 0M; Check whether the 4G signal strength is above 13, and the 3G/4G signal strength can be obtained through "Network Status Detection". www.sysolution.net...
-
Page 19: Aips Cloud Platform Register
AIPS Cloud Platform Register Cloud platform account registration Open the cloud platform login interface, click the registration button, input information according to the relevant prompts and click submit. After receiving the confirmation email, click the link to confirm and complete the registration. www.sysolution.net... -
Page 20: Cloud Platform Account Binding
Cloud platform account binding Enter the web server address and company ID and click Save. The foreign server address is: www.ledaips.com www.sysolution.net... -
Page 21: End Page
If necessary, the online customer service will communicate with you in time. The industry experience will definitely give you a satisfactory answer, Shanghai Xixun sincerely looks forward to the follow-up cooperation with you. Best regards Shanghai XiXun Electronics Co., Ltd. March 2022 www.sysolution.net... - Page 22 - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. www.sysolution.net...
