RevAMP ™
ELECTRIC AUTOMATED SIDE LOADER
OPERATION MANUAL
ISSUED JULY 2024
© 2024 The Heil Co.
WARNING
Failure to follow all instructions and safety precautions in
this manual, in the Service Manual, in other manufacturers'
manuals and on the safety decals attached to the product
could result in serious injury or death to operators or
bystanders and/or damage to property.
DO NOT operate this vehicle before you READ and
UNDERSTAND this Operation Manual, the Service Manual
for this unit, other applicable manufacturers' manuals, and
the safety decals on the product.
Each operator of this unit must read and understand all
directions in this manual before they first operate this
vehicle.
Keep this manual in the cab for new operators and to
remind all operators about safe use.
NOTICE
RevAMP units are electric bodies, powered by a high
voltage battery power source. Only those properly trained
and qualified on high voltage vehicle applications should
perform service. All users must be aware of the risks
associated with electric vehicles. IF YOU ARE NOT SURE
IF YOU ARE QUALIFIED, CONSULT YOUR
ORGANIZATION'S EHS FUNCTION BEFORE USE OR
PERFORMING ANY WORK. Please note that various
procedures are different from other Heil bodies due to the
electric nature of the RevAMP units – please read this
Operation Manual and related documents in full.
NOTE: This Operation Manual only applies to the Heil
RevAMP body. Heil is not the manufacturer of the chassis.
Please consult respective manual(s) from the applicable
chassis maker as well.
TP1REV-OM-0724
