- Page 1 SAC 2110 V2 Touch Standalone Access Control User Manual For more information visit www.sieraelectronics.com...
-
Page 2: Packing List
1. Packing List Name Quantity Remarks Touch Access Control SAC 2110 User manual mm, Special for keypad Screw driver Rubber plug , used for fixing Self tapping screws , used for fixing Star screws used for fixing Please ensure that all the above contents are correct. If any are missing please notify the supplier of the unit. -
Page 3: Specifications
Description Features Touch keypad, numbers backlight Can be used as a standalone keypad for PIN users Pin can be Modified by users Adjustable Door Output time, Alarm time, Door Open time Easy to install and program Built in buzzer Red, Orange and Green LEDS display the working status Fast Search speed: time between reading card and opening the door is less than 0.1S Specifications ±10%... -
Page 4: Installation
6. Installation Drill the holes on the wall according to the hole size of the back cover or install the cable box on the wall. And Fix the back cover firmly on the wall with t Thread the cable through the cable hole, connect the wire needed, wrap unused wire with insulating tape in case of short circuit Fix the front cover to the back cover with screw driver 7. - Page 5 pecial ower upply diagram:...
-
Page 6: Sound And Light Indication
9. Anti Tamper Alarm The unit uses a LDR (light dep the cover then the tamper alarm will operate. 10.Sound and Light indication Operation Status Red Light Green Light Light Buzzer Power on Bright Stand by Bright Press keypad Operation successful Bright Operation failed DiDiDi... - Page 7 To add a Pin user User ID number PIN # The ID number is any number between 1 & 2000. The PIN is any four digits between 0000 & 9999 with the exception of without exiting programming mode as follows: User ID no 1 # PIN # User ID no 2 # PIN #...
- Page 8 To delete a card user by user ID. This option User ID can be used when a user has lost their card To delete a card user by card number. Card number This option can be used when the user want Note users can be deleted continuously without exiting to make the change but the card has lost programming mode...
- Page 9 11.2 Door Settings Relay Output Delay Time To set door relay strike time Master code # 0 99 0-99 is to set the door relay time 0-99 seconds Master code # Master code # Master code # Master code # Master code # Master code # Master code #...
- Page 10 1 .The unit operating as a Wiegand Output Reader www.sieraelectronics.com...
- Page 11 Siera reserves the right to apply changes on the speci cations of the products at any moment without prior notice. The picture and images are as reference only, the product can vary from reality. Siera is a trademark belonging to the Siera Holding Group.
