Siera SAC 3600 User Manual

Fingerprint reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

S
A
C
3
6
0
0
S
A
C
3
6
0
0
U
s
e
r
'
s
M
a
n
u
a
l
U
s
e
r
'
s
M
a
n
u
a
l
www.sieraelectronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAC 3600 and is the answer not in the manual?

Questions and answers

Related Manuals for Siera SAC 3600

Summary of Contents for Siera SAC 3600

  • Page 1 ’ ’ www.sieraelectronics.com...

  • Page 2: Table Of Contents

    SAC 3600 Fingerprint Reader User’s Manual Contents Foreword ......................... - 2 - [Part I] Operating instruction on controller ..............- 3 - Chapter I SAC 3600fingerprint reader controller ............- 3 - I. Brief introduction ..................... - 3 - II. Drawings......................- 4 - III.

  • Page 3: Foreword

    SAC 3600 Fingerprint Reader User’s Manual Foreword Dear user, Thank you for choosing our product. Before installing and using the product, please read this manual carefully and understand the basic construction, performance, function, and basic knowledge about its installation, use, maintenance and system management.

  • Page 4: [Part I] Operating Instruction On Controller

    Fingerprint recognition will be used more widely for more and more assess systems. SAC 3600 fingerprint reader controller is a kind of fingerprint recognition device for door access system. The reading function transmits verified fingerprint information to access controller by the format of Wiegand26 or Wiegand34.

  • Page 5: Drawings

    SAC 3600 Fingerprint Reader User’s Manual II. Drawings ◆ ◆ ◆ ◆ LCD display Character matrix LCD display. ◆ ◆ ◆ ◆ Numerical setting keys Number keys 0~9 for setting; “*” key for return; “#” key for confirmation. ◆ ◆ ◆ ◆ Fingerprint scanner The device for registering fingerprint or collecting feature points during fingerprint analysis.

  • Page 6: Performance Indicators

    SAC 3600 Fingerprint Reader User’s Manual Level-9 safety grading, failing rate FRR≤0.0001%, speed of analysis ≤1 second. Safe! Rapid! Reliable! Adaptation to both fingerprint and inductive card, facilitating system upgrade of existing and new door access control. Human-computer interface with voice function, character matrix LCD display, visual and convenient.

  • Page 7: Configuration

    SAC 3600 Fingerprint Reader User’s Manual Format of output Wiegand26, Wiegand 34; relay normally opened/closed. Registration 30 cards; 3,800 fingerprints. capacity Logout IDs of last 10 analyses Relay contact 1A/DC12V Alarm function Temper alarm; on-site beeper and level output. Relay delay time...

  • Page 8: Specification On Displayed English Letters

    SAC 3600 Fingerprint Reader User’s Manual VIN (DC 9-12V input) GND (power supply grounding) Black WD0 (Wiegand output D0) Green WD1 (Wiegand output D1) White HOLD (Wiegand output interrupt, effective Brown low level) ALARM (alarm output interrupt, effective Yellow low level)
  • Page 9 SAC 3600 Fingerprint Reader User’s Manual 2. LST ID (browse card number) Card: XXXXXXXXXX (list registered ID cards in the device; press 9 and 0 to turn page) 3. DEL ID (delete card number) Card: XXXXXXXXXX (delete any registered ID card; press 9 and 0 to turn page;...

  • Page 10: Chapter Ii Setting

    SAC 3600 Fingerprint Reader User’s Manual Chapter II Setting I. Start Connect DC12V±2V/1A power supply that meets safety requirements to the power line of the device. The startup mode is entered. SelfTest SelfTest SelfTest SelfTest … … … … II. Standby image The standby status is entered after 1 second when the power supply is connected.

  • Page 11: Change Fingerprint (Chg Fp)

    SAC 3600 Fingerprint Reader User’s Manual Input the same ID and change a finger for registration. The number of fingerprints to register under a same ID is not limited and the user has the free choice for registration. To delete a user with several fingerprints registered, it is required to delete the ID only and then all the fingerprints’...

  • Page 12: Card Management

    SAC 3600 Fingerprint Reader User’s Manual IV. Card management Enter the subdirectory to choose 2. Card to enter the secondary menu, which includes: 1. REG ID (register ID card), 2. LST ID (browse ID card), 3. DEL ID (delete ID card), and 4.

  • Page 13: Selection Of Wiegand Protocol

    SAC 3600 Fingerprint Reader User’s Manual optional modes: 1. Normal (normal mode) and 2. Auto (automatic mode). 1 1 1 1 ． ． ． ． Normal Normal Normal Normal 2.Auto 2.Auto 2.Auto 2.Auto Under normal mode, the reader’s indicator light is off for standby status. To analyze fingerprint, press # key and the indicator is lit.
  • Page 14 SAC 3600 Fingerprint Reader User’s Manual opening. 01:FP: 01:FP: 01:FP: 01:FP: 0001 0001 0001 0001 Press 9/0 to turn up/down the pages for door opening record. The four-digit figure in the second row indicates the ID of opening the door.
  • Page 15 SAC 3600 Fingerprint Reader User’s Manual [Part II] Operating instruction of management tools...

  • Page 16: Chapter I Software Installation

    (the job number is any figure between 0001~9999). II. Software installation ①Start the computer. Insert the CD-ROM supplied with SAC 3600 to the driver. Wait. Then double-click the executable for setup. Click to continue.
  • Page 17 SAC 3600 Fingerprint Reader User’s Manual Click to continue. Click to select a specific path of installation (the default path is C:\Program Files\SM-Tool). Click to continue and the setup process is automatic. It takes about 15 seconds. Click to finish installation.

  • Page 18: Chapter Ii Operating Instruction

    SAC 3600 Fingerprint Reader User’s Manual Chapter II Operating instruction I. Opening of management tools Double-click the desktop icon “Fingerprint Manage Tools Advanced Edition” to open the management tools. II. Introduction of functional interfaces ◆ ◆ ◆ ◆ Serial port Select “Serial port number”, which refers to the RS232 port number for...
  • Page 19 SAC 3600 Fingerprint Reader User’s Manual ◆ ◆ ◆ ◆ Testing Select “All”, “Image sensing”, “Memory” and “Code”. Click check normal service of the hardware. ◆ Setting Such parameters as “Exposure coarse adjustment”, “Image gain” etc. could be adjusted for the reader.
  • Page 20 SAC 3600 Fingerprint Reader User’s Manual ◆ Image Choose a proper size of image, such as the “Original size”. Click shown as follows: ◆ ◆ ◆ ◆ User...
  • Page 21 SAC 3600 Fingerprint Reader User’s Manual Read user list You may read all fingerprint users in the fingerprint reader other than ID card users. User number Input the corresponding ID when to register or change any user. Register Input a new ID, put a finger on the fingerprint scanner, and click “Register”. The registration is successful in the left “User number”...
  • Page 22 SAC 3600 Fingerprint Reader User’s Manual Read user list Click this button to read data of all fingerprint users in the reader. Export table Export user data in the form of Excel spreadsheet and save for further reference of user information.
  • Page 23 SAC 3600 Fingerprint Reader User’s Manual Click “Delete all” and the system hints “Are you sure to delete all users?” Click “Yes” to delete all users, or “No” to quit. Return Click Return to return to the User management interface.

  • Page 24: Statement About Human Rights And Privacy

    SAC 3600 Fingerprint Reader User’s Manual Statement about human rights and privacy Dear user, First of all, thank you for choosing our fingerprint identification product. As a famous core technology provider for fingerprint recognition, we pay special attention to national laws and regulations in relation to human rights and privacy while conducting development and research constantly.
