- Page 1 Part No. 8206 Vehicle Battery Tester Instructions www.lasertools.co.uk...
-
Page 2: Specifications
Introduction Specifications The Laser Tools 8206 vehicle battery tester is a compact unit that accurately tests CCA testing: SAE, DIN, EN, IEC, CA Function: battery state, cranking voltage and charge voltage. Simply enter the battery details Battery voltage when engine is starting from the battery label and run the chosen test. - Page 3 Instructions Instructions Notes: Ref. Description CCA (Cold Cranking Amps): This is the rating to define a battery’s ability to start an LCD display screen engine in cold temperatures (it is easier to start an engine in a warm environment Increase button than in a cold one).
-
Page 4: Operation
Instructions Instructions Operation: Battery Test: Before testing a battery in a vehicle, ensure ignition is switched OFF and all Note: A freshly charged battery will show a higher than normal voltage; if this is electrical equipment is OFF. Close all doors, tailgate, etc. Ensure battery terminals the case, switch on the headlights for two or three minutes to allow the voltage to are clean. - Page 5 Instructions Instructions The CCA value of the battery can be found on the label on top of the battery (for In this example, the battery CCA SAE figure from the label on top of the battery has example 760 SAE/GS) or from the battery manufacturer’s web site if you know been entered into the tester (760).
- Page 6 Instructions Instructions Now start the engine. (Make sure gear is in neutral and hand brake is applied.) Now start the engine. (Make sure gear is in neutral and hand brake is applied.) The voltage displayed will decrease until the lowest voltage is measured. Increase engine speed to 3000-4000 RPM for 3-5 seconds;...
- Page 7 Common Euro-specification Batteries Common Euro-specification Batteries These are listed for information purposes only. Always follow the information on the battery label, or the battery manufacturer’s web site, to determine the accurate CCA figure for the battery before entering this figure into the tester.
- Page 8 Precautions Precautions • The tester is designed to test 12 volt automotive batteries only. • If battery acid contacts skin or clothing, wash immediately with soap and plenty of water. • A freshly charged battery will show a higher than normal voltage; if this is the case, switch on the headlights for two or three minutes to allow the voltage to •...
- Page 9 Our products are designed to be used correctly and with care for the purpose for which they are intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and the Tool Connection cannot be held responsible for any damage to personnel, property or equipment when using the tools.
