SIP Hardwood 4 Drawer
Leicestershire
LE12 9NH
Workbench
United Kingdom
Please read and fully under-
stand the instructions in this
SIP Code 01460
manual before operation.
Keep this manual safe for
.
future reference
For help or advice please contact your distributor, or SIP directly :
Tel.: 01509 500400 Email: sales@sip-group.com
customerservice@sip-group.com
www.sip-group.com
1
Advertisement
Related Manuals for SIP 01460
Summary of Contents for SIP 01460
- Page 1 Please read and fully under- stand the instructions in this SIP Code 01460 manual before operation. Keep this manual safe for future reference For help or advice please contact your distributor, or SIP directly : Tel.: 01509 500400 Email: sales@sip-group.com customerservice@sip-group.com www.sip-group.com...
-
Page 3: Contents & Accessories
CONTENTS & ACCESSORIES Note: The maximum weight the table can take is 100kgs. Note: If any parts are missing, contact you distributor. -
Page 4: Main Parts Identification
CONTENTS & ACCESSORIES Cont... MAIN PARTS IDENTIFICATION Item Description Shelf Sides Left Hand Side Support Right Hand Side Support Shelf Table Top Draw Assembly Vice Clamp Assembly Metal Peg / Dog Wooden Peg... - Page 5 ASSEMBLY INSTRUCTIONS Fig.1 • Put Screw Inserts (S) into Shelf Sides (A). (Fig.1) Fig.2 • Connect Side Support (B) & (C) together with 1 x Shelf Side (A). • Use fixings 2 x (Q) & 2 x (N). (Fig.2)
- Page 6 ASSEMBLY INSTRUCTIONS Cont... Fig.3 • Slide in Shelf (D) . (Fig.3) Fig.4 • Place remaining Shelf Side Support “A” into position. • Secure using fixings 2 x (N) & 2 x (Q). (Fig.4)
- Page 7 ASSEMBLY INSTRUCTIONS Cont... Fig.5 • Refer to Fig.5. • Fit completed assembly (Fig.4) on to the Table Top (F). Making sure that the Table Top is face down. • Fix into position using 2 x (O) & 2 x (Q) on the left and repeat using 2 x (O) &...
-
Page 8: Drawer Assembly
ASSEMBLY INSTRUCTIONS Cont... DRAWER ASSEMBLY Fig.6 • Refer to Fig.6 • Join together panels (H) & (J) using screws (T). • Slide in Draw Bottom (I) and retain in place using screws (T). • Repeat for all four drawers. • Fix drawer handles. - Page 9 ASSEMBLY INSTRUCTIONS Cont... FITTING THE VICE Fig.7 • Line up the threaded bar and the 2 x support bars of the Vice Assembly (K) with the 3 holes on the side of the workbench.
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT Please dispose of packaging for the product in a responsible YOUR DISTRIBUTOR, OR SIP manner. It is suitable for recycling. Help to protect the envi- DIRECTLY ON: ronment, take the packaging to the local amenity tip and TEL: 01509 500400 place into the appropriate recycling bin.
