Installation instructions

Heat recovery appliance

Ubiflux W300(+) / W400(+) / W450(+)

STORE NEAR THE APPLIANCE

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

Table of Contents

Need help?

Do you have a question about the Ubiflux W300(+) and is the answer not in the manual?

Questions and answers

Summary of Contents for ubbink Ubiflux W300(+)

Page 1 Installation instructions Heat recovery appliance Ubiflux W300(+) / W400(+) / W450(+) STORE NEAR THE APPLIANCE This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
Page 2: Table Of Contents
Table of contents Delivery............Maintenance ..........Scope of delivery ..........Filter cleaning ..........Accessories Ubiflux ........Maintenance ..........Application ............ Electric diagrams........10.1 Basic diagram ..........Version............10.2 Wiring diagram ..........Technical information ........Fan graphs ............. Electric connections accessories ..... Exploded view appliance ........ 11.1 Connections connectors .......
Page 3: Scope Of Delivery
Delivery Chapter 1 1.1 Scope of delivery Before starting installation of the heat recovery unit, check that it has been supplied complete and undamaged. The scope of delivery of the heat recovery unit Ubiflux includes the following components:  Heat recovery appliance type Ubiflux ...
Page 4: Accessories Ubiflux
Delivery Chapter 1 1.2 Accessories Ubiflux W300(+) / W400(+) / W450(+) Article description Article code Synthetic duct Ø160 mm / Length 2000 mm (box of 6) 100000188210 Synthetic duct Ø180 mm / Length 2000 mm (box of 4) 100000188206 Synthetic bend 90° Ø160 mm (box of 8) 100000188225 Synthetic bend 90°...
Page 5: Delivery
Delivery Chapter 1 Article description Article code Splitter RJ12 100000704643 sensor surface-mounted 400000120174 Transmitter wireless remote control 4 positions (with. battery) 100000888053 Receiver wireless remote control (for battery version) 100000888065 Kit wireless remote control 4 positions (1 transmitter & 1 receiver) 100000888089 Controlunit 100000888030...
Page 6 Delivery Chapter 1 G4 +F7 2x G4 G3 +F7 2X G3 G4 + Frame Article description Article code Filter kit 1 x F7 filter (1 pcs) 100000704562 G4 +F7 G3 +F7 2X G3 Filter kit 1x G3 & 1x F7 (1 pcs/ 1 pcs) 100000704564 RH-sensor 100000888078...
Page 7: Application
Application Chapter 2 The Ubiflux W300 / W400 / W450 is a ventilation unit with heat version. A left-handed version has the filters on the left behind recovery with a maximum ventilation capacity of 300, 400 or the filter door; a right-handed version has the filters on the right 450 m /h and low-energy fans.
Page 8: Version
Chapter 3 Version 3.1 Technical information Ubiflux W300 Supply voltage [V/Hz] 230/50 Protection degree IP30 Dimensions (w x h x d) [mm] 675 x 765 x 564 Duct diameter [mm] Ø160 External diameter condensate discharge [mm] Ø32 Weight [kg] Filter class G3 (F7 optional for supply) Fan setting (factory setting) Ventilation capacity [m Permissible resistance ducts system [Pa]...
Page 9 Version Chapter 3 Ubiflux W400 Supply voltage [V/Hz] 230/50 Protection degree IP30 Dimensions (w x h x d) [mm] 675 x 765 x 564 Duct diameter [mm] Ø180 External diameter condensate discharge [mm] Ø32 Weight [kg] Filter class G3 (F7 optional for supply) Fan setting (factory setting) Ventilation capacity [m Permissible resistance ducts system [Pa]...
Page 10 Ubiflux W450 Supply voltage [V/Hz] 230/50 Protection degree IP30 Dimensions (w x h x d) [mm] 677 x 765 x 564 Duct diameter [mm] Ø180 External diameter condensate discharge [mm] Ø32 Weight [kg] Filter class G3 (F7 optional for supply) Fan setting (factory setting)) Ventilation capacity [m Permissible resistance ducts system [Pa] 2 - 5...
Page 11: Fan Graphs
3.2 Fan graphs Fan graph Ubiflux W300 Note: The value stated in the circle is the capacity per fan (in Watt) Volumestroom [m³/h] Flow rate [m Fan graph Ubiflux W400 Note: The value stated in the circle is the capacity per fan (in Watt) Flow rate [m Ubiflux W300(+) / W400(+) / W450(+)
Page 12 Chapter 3 Version Fan graph Ubiflux W450 Note: The value stated in the circle is the capacity per fan (in Watt) Flow rate [m Ubiflux W300(+) / W400(+) / W450(+)
Page 13: Exploded View Appliance
Version Chapter 3 6263-C plaatje2.pdf 4-3-2011 15:44:45 3.3 Exploded view appliance Rear view display cover 1 Service connector Computer connection for service purposes. 2 Display and 4 control buttons Interface between user and control electronics. 3 Control board Contains the control electronics for the basic functions. 4 Extract air filter Filters air flow from dwelling 5 Preheater...
Page 14: Connections And Dimensions
Chapter 3 Version 3.4 Connections and dimensions Ubiflux W300/W400/W450 3.4.1 Ubiflux right-handed version (W450 only in 4/0 version) Ubiflux Right-handed 2/2 Ubiflux Right-handed 4/0 1 = To dwelling 2 = To atmosphere 3 = From dwelling 4 = From atmosphere 5 = Electric connections 6 = Connection condensate discharge Ubiflux Right-handed 3/1 7 = Wall mounting bracket (note the correct position of the rubber strip, washers and caps) Ubiflux W300(+) / W400(+) / W450(+)
Page 15: Ubiflux Left-Handed Version
Version Chapter 3 3.4.2 Ubifl ux left-handed version (W450 only in 4/0 version) Ubifl ux left-handed 2/2 Ubifl ux left-handed 4/0 10 mm Mounting wall suspension kit Ubifl ux left-handed 3/1 Ubifl ux W300(+) / W400(+) / W450+...
Page 16: Operation
Chapter 4 Operation 4.1 Description The appliance comes plug and play and operates fully auto- The control system has three ventilation modes. The air flow matically. The extracted indoor air heats up the fresh, clean rate can be adjusted per ventilation mode. The constant vo- outdoor air.
Page 17: Installation
The appliance must be placed level. display cover so it can always be removed. 5.3 Connecting the condensate discharge The condensate discharge line for the Ubbink Ubiflux HR is fed through the lower panel. The condensate must be discharged through a drainpipe. The condensate discharge comes separately with the applian- ce and the installer must screw it into the underside of the ap- pliance.
Page 18 • Choose the location of the supply valves to prevent fouling the roof area and the sewage vent stack does not end under and draught. We recommend to use the Ubbink supply val- the tiles. ves.
Page 19: Electric Connections
Installation Chapter 5 5.5 Electric connections 5.5.1 Connecting the power plug The appliance can be connected to an easily accessible, Warning earthed wall socket with the plug that is mounted to the ap- The fans and control board carry a high volta- pliance. The electric installation must comply with the require- ge.
Page 20: Mounting Enthalpy Heat Exchanger
Chapter 5 Installation 5.6 Mounting Enthalpy Heat Exchanger (only for W300 / W400 units) Place the Enthalpy Heat Exchanger into the appliance. 10000888155 Place the frontcover and filter back. Close the filterdoor.  Close the condensate discharge with the supplied cap. Ubiflux W300(+) / W400(+) / W450(+) Ubiflux W300(+) / W400(+) / W450(+)
Page 21: Display Image
Chapter 6 Display image 6.1 General explanation control panel The LCD display shows what the operating situation of the ap- After operating the key ‘Menu’, the keys “+” or “-” can be used pliance is. Four control keys can be used to call up and modify to select from three different menus, including: settings in the control unit program.
Page 22: Operating Mode
Display Chapter 6 6.2 Operating mode In operating mode the display may simultaneously show 4 dif- ferent situations/values. 1 = Status fan situation, image coupled appliances (see § 6.2.1) 2 = Air flow rate (see § 6.2.2) 3 = Message text e.g. text filter situation, activation exter- nal switch contact etc. (see § 6.2.3) 4 = Fault symbol (see § 8.1 and § 8.2) 6.2.1 Status system fan This part of the display shows a fan together with a number.
Page 23: Message Text For Operating Mode
Chapter 6 Display 6.2.3 Message text for operating mode This part of the display may show a message text. The message text “Filter” always takes precedence over the other message texts. The following message text may appear during operating mode. Message text Description on display FILTER When the text “FILTER”...
Page 24: Settings Menu
Warning: Because changes may affect the proper performance of the appliance, changes of settings not described here require consultation with Ubbink. Incorrect settings may seriously affect the proper perfor- mance of the appliance! Use keys ‘-‘ and ‘+’ key to modify selected set value.
Page 25: Readout Menu
Chapter 6 Display 6.4 Readout menu The readout menu can be used to call up a number of 3. Activate the readout menu. current sensor values to obtain more information on the appliance's performance. Modifying values of set- tings is not possible in the readout menu. The readout menu can be displayed as follows.
Page 26: Service Menu
Display Chapter 6 6.5 Service menu The service menu shows the most recent 10 fault messages. 3. Activate the service menu. Use the ‘+’ and the ‘-’ key to scroll through the messages in In the event of a locking fault, the settings menu and the re- adout menu are blocked and only the service menu can be opened;...
Page 27: Putting Into Operation
Chapter 7 Putting into operation 7.1 Switching the appliance on and off There are two methods to switch the appliance on or off. - Switching on and off by inserting or pulling the power plug. - Switching on and off through software on the appliance display. Switching off: Switching on •...
Page 28: Setting The Air Quantity
Putting into operation Chapter 7 7.2 Setting the air flow rate The factory supplies the Ubiflux for the Ubiflux W300 flow rates set to 50, 100, 150 en 225 m /h and for the Ubiflux W400 / See the settings menu, §6.3, for changing the flow rates. W450 set to 50, 100, 200 and 300 m /h respectively.
Page 29: Fault
Chapter 8 Fault 8.1 Trouble shooting When the appliance control system detects a fault, it is indi- cated on the display with a spanner symbol, possibly together with a fault code. The appliance makes a distinction between a fault at which the appliance keeps running (limitedly) and a serious (locking) fault at which both fans are switched off.
Page 30 Fault Chapter 8 Fault Cause Action appliance Action installer code E100 Pressure sensor supply fan • Take the voltage from the appliance. - Switches to constant rpm control. defective. • Check the red pressure hoses (and - The preheater switches on at outdoor Red pressure hoses blocked pressure tubes) for fouling, kinking (non-locking...
Page 31: Maintenance
Chapter 9 Maintenance 9.1 Filter cleaning User maintenance is limited to periodically cleaning or repla- Place the filters back the same way as they were taken cing the filters. The filter only has to be cleaned when that is out. indicated on the display (it shows the text "FILTER”) or, if a multiple switch with filter indication is mounted, when the red LED at the switch lights up.
Page 32 Maintenance Chapter 9 9.2 Maintenance Installer maintenance includes cleaning the heat exchanger Remove the heat exchanger. Be careful not to damage the and fans. Dependent on the conditions, this must done about foam parts in the appliance. once every three years. Switch off the appliance on the control panel (Press the ‘-’ key for 5 seconds;...
Page 33 Chapter 9 Maintenance Remove 4 pressure hoses and 3 connectors from the 11 Clean the fans with a soft brush. board. Make sure the balancing weights do not shift! Slide the fan assembly out of the appliance. 12 Replace the separated part of the fan assembly and recon- nect the loose pressure hoses to the pressure tubes.
Page 34: Electric Diagrams
Electric diagrams Chapter 10 10.1 Basic diagram 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 Renovent Excellent 400 Renovent Excellent 300 Renovent Excellent 400 Renovent Excellent 300 Renovent Excellent 400 Renovent Excellent 300 Ubiflux W300 Ubiflux W300+ Renovent Excellent 400 Plus Renovent Excellent 300 Plus...
Page 35: Electric Connections Accessories
Electric connections accessories Chapter 11 11.1 Connections connectors Connector X1 eBus or. OpenTherm connector X1 Two-pole screw connector. Set ex factory as eBus connector; after modifying parameter 8 in the Settings menu, also suitable as OpenTherm connector (see §11.3). Only suitable for low voltage Note: For the eBus Application, this connector is polarity-specific. Not suitable for 230V! Connector X2...
Page 36 Chapter 11 Electric connections accessories E2365-A.pdf 26-1-2011 14:26:21 E2365-A.pdf 26-1-2011 14:26:21 E2365-A.pdf 26-1-2011 14:26:21 11.2 Connection examples multiple switch .pdf 26-1-2011 14:26:21 E2365-A.pdf 26-1-2011 14:26:21 A multiple switch can be connected to the modular connector X2 of the Ubiflux. This modular connector X2 is directly accessible at the rear of the display cover (see §11.1) without having to take it off.
Page 37 Electric connections accessories Chapter 11 11.3 Couple through eBus contact; all appliances equal air flow rate Important: Because of polarity sensitivity, always connect contacts X1-1 to X1-1 and contacts X1-2 to X1-2. Never connect X1-1 and X1-2. A maximum of 10 appliances (1 Master + 9 Slave max.) 230V 230V 230V...
Page 38 Chapter 11 Electric connections accessories 11.5 Wiring diagram postheater connection (only possible for Ubiflux +) The electrical connections of the postheater and the extra preheater are the same; the only difference is that the postheater has an ad- ditional temperature sensor that must be wired to connector X15. Please refer to the mounting instructions that came with the heater for more extensive information regarding installation of the postheater or the extra preheater.
Page 39 Electric connections accessories Chapter 11 11.5 Connection example geo heat exchanger (only possible for the Ubiflux +) Ⅰ A geo heat exchanger can be connected to the 30°C Ubiflux +. Ⅲ A geo heat exchanger can be connected to connec- tion no. 5 (GND) and no. 9 (+) of 9-pole connector X15;...
Page 40 Chapter 11 Electric connections accessories 11.7 Connecting external switch contact (only possible for Ubiflux +) An external switch contact (e.g. switch or relay contact) can be connected to the Ubiflux +. This external switch contact can be con- nected to connections no. 1 and no. 2 of 9-pole connector X15; this 9-pole connector is directly accessible at the rear of the top without having to dismount the display cover (see also §11.1).
Page 41 Electric connections accessories Chapter 11 11.8 Connection to 0-10 V input (only possible for Ubiflux +) The Ubiflux + can be equipped with an external provision with 0-10 volt control) (e.g. humidity sensor or CO sensor). This external provision can be connected to pins no. 3 and no. 4 of 9-pole connector X15; this 9-pole connector is directly accessible at the rear of the top without having to dismount the display cover (see also §11.1).
Page 42: Exploded View
Chapter 12 Service 12.1 Exploded view When ordering parts, in addition to the article code number Example (see exploded view), please state the type of the heat recovery Appliance type : Ubiflux W400 4/0 R appliance, the serial number, the year of production and the name of the part: Serial number : 420020113201...
Page 43 The mains cable has a print connector. When replacing it, always order a replacement mains cable Ubbink To avoid dangerous situations, a damaged mains should only be replaced by a qualified person! Modifications reserved Ubbink B. V. continuously strives after improvement of products and reserves the right to change the specifications without prior notice. Ubiflux W300(+) / W400(+) / W450(+) Ubiflux W300(+) / W400(+) / W450(+)
Page 44: Setting Values
Chapter 13 Setting values STEP FACTORY DISPLAY TEXT + DESCRIPTION ADJUSTING RANGE STEP SETTING SYMBOLS 50 m /h or 50 m Air flow rate Ubiflux W300 : mode 50 m /h or 50 m Air flow rate Ubiflux W400 : mode 50 m /h or 50 m Air flow rate Ubiflux W450 : mode Air flow rate Ubiflux W300 : mode 1...
Page 45 Setting values Chapter 13 STEP FACTORY SETTINGS DISPLAY TEXT + DESCRIPTION ADJUSTING RANGE STEP REN. EXC. “+” SYMBOLS 0 (= Extract fan off) 1 (= Absolute min. flow rate 50m 2 (= Flow rate mode 1) Extract fan mode 3 (= Flow rate mode 2) 4 (= Flow rate mode 3) switching input 1 5 (= Multiple switch) 6 (= Maximum flow rate)
Page 46: Declaration Of Conformity
DECLARATION OF CONFORMITY Manufacturers : Ubbink nv Address: Jan Samijnstraat 9 9050 Gentbrugge - Belgium Product: Heat recovery unit type: Ubifl ux W300 / W300+ Ubifl ux W400 / W400+ Ubifl ux W450 / W450+ The product described above complies with the following directives: 2006/95/EC (low voltage directive)
