Operation Guide PDM-10B/20B
HOW THE PEDOMETER WORKS
• This pedometer is intended for use while walking during normal daily life and during light jogging.
• As you walk or jog across a level surface, the pedometer detects the impact acceleration generated when your
foot hits the ground.
• If you hold the pedometer vertically and shake it up and down, you should be able to hear a rattling sound. This
is the sound of the pendulum inside the pedometer that is used for detecting movement. This sound indicates
that the pedometer is operating normally.
• Note that the pedometer cannot count steps correctly under the conditions described below. Avoid these
conditions whenever using the pedometer.
1. Irregular walking
• Walking where it is crowded
• Walking in sandals
• Shuffling your feet
2. Any activity other than walking or jogging
• Any activity that requires sudden standing or sitting
• Jumping, or extreme activities or sports
• Climbing or descending stairs or a steep slope
• Vibration while riding on a car, train, bus, etc.
* Never start on any exercise program without consulting your physician, especially if you are currently under the
care of a physician, or if you have any past history of heart problems.
CHANGING MODES (PDM-20B)
• Press the MODE button to cycle through the number of steps, distance, and calorie screens.
TO SET YOUR STRIDE LENGTH (PDM-20B)
1. Calculate your average stride length.
• In a safe place, mark your starting point. Walk normally for 10 paces, and mark where you stop. Measure the
distance between the two marks, and then divide by 10.
9
7
5
3
10
8
6
4
6 m
2. While the number of steps screen is displayed, press the MODE button once to display the distance screen.
3. Press the SET button to display the stride length setting screen.
4. While the stride length setting screen is on the display, use the SET button to specify the average stride length
you calculated in step 1.
• Each press of the SET button increases the displayed stride length by 1cm. You can set a value in the range
of 30cm to 180cm.
• Holding down the SET button changes the setting at high speed.
• The display will exit the stride length setting screen automatically if you do not perform any operation for a few
seconds.
5. After you are finished setting the stride length you want, simply wait and the pedometer will automatically exit
the stride length setting screen and return to the distance screen.
DIS
DIS
(km)
SET button
(km)
STRIDE
(cm)
SET
MODE
SET
MODE
RESET
RESET
60 cm
1
2
60 cm
DIS
(km)
STRIDE
STRIDE
(cm)
(cm)
SET
MODE
RESET
TO SET YOUR CURRENT WEIGHT (PDM-20B)
1. While the number of steps screen is displayed, press the MODE button twice to display the calorie screen.
2. Press the SET button to display the weight setting screen.
3. While the weight screen is on the display, use the SET button to specify your current weight.
• The display will exit the weight length setting screen automatically if you do not perform any operation for a
few seconds.
• Each press of the SET button increases the displayed weight by 1 kg. You can set a value in the range of
30 kg to 120 kg.
• Holding down the SET button changes the setting at high speed.
4. After you are finished setting your weight, simply wait and the pedometer will automatically exit the weight
setting screen and return to the calorie screen.
CALORIE
CALORIE
SET button
(kcal)
(kcal)
WEIGHT
(kg)
SET
MODE
SET
MODE
RESET
RESET
RESETTING THE PEDOMETER
(PDM-10B)
Press the RESET button to reset the number of steps to "0".
(PDM-20B)
Press the RESET button to reset the number of steps, distance, and calories to "0".
Note that the RESET operation does not affect the stride length and weight settings.
• Before starting a new pedometer measurement operation, be sure to reset to "0" first.
CALORIE
(kcal)
WEIGHT
WEIGHT
(kg)
(kg)
SET
MODE
RESET
2
