MA0312-EA
ILLUSTRATION
PDM-10B
PDM-20B
• A sticker is affixed to the glass of the pedometer when you purchase it. Be sure to remove the sticker before
using the pedometer.
• Depending on the model of your pedometer, its configuration may differ somewhat from that shown in the
illustration.
Operation Guide PDM-10B/20B
GENERAL GUIDE
PDM-20B
PDM-10B
1 1 1 1 1 RESET button
5 5 5 5 5 RESET button
Press to reset the number of steps to "0" .
Press to reset the number of steps to "0" .
Pressing this button while the display is blank turns
6 6 6 6 6 SET button
on the display.
7 7 7 7 7 MODE button
Holding down this button turns off power.
8 8 8 8 8 Front panel
2 2 2 2 2 Front cover
9 9 9 9 9 Back panel
3 3 3 3 3 Back cover
4 4 4 4 4 Clip
0 0 0 0 0 Clip
A A A A A Cursor
OPENING THE PEDOMETER PANELS (PDM-20B)
Holding the front and back panels of the pedometer, release the catch on the top of the panels and then open them
as shown in the illustration.
AFFIXING THE PEDOMETER TO YOUR CLOTHING
• Clip the pedometer securely to your belt or the waistband of your slacks, skirt, training pants, etc.
• Take care that you hook the clip so your belt or waistband enters the clip as far as it will go. Improper attachment
of the pedometer or wearing it an angle can cause mistakes in the number of step count.
• Take care that you do not accidentally press the RESET button while you are attaching or removing the
pedometer. Accidentally pressing the RESET button will reset the number of steps to "0".
• Make sure that the two panels of the pedometer are securely closed while you are using it (PDM-20B).
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Casio PDM-10B
Summary of Contents for Casio PDM-10B
- Page 1 MA0312-EA Operation Guide PDM-10B/20B ILLUSTRATION GENERAL GUIDE PDM-20B PDM-10B PDM-10B 1 1 1 1 1 RESET button 5 5 5 5 5 RESET button Press to reset the number of steps to “0” . Press to reset the number of steps to “0” .
- Page 2 Operation Guide PDM-10B/20B TO SET YOUR CURRENT WEIGHT (PDM-20B) HOW THE PEDOMETER WORKS • This pedometer is intended for use while walking during normal daily life and during light jogging. 1. While the number of steps screen is displayed, press the MODE button twice to display the calorie screen.
- Page 3 Operation Guide PDM-10B/20B Battery Precautions BATTERY REPLACEMENT • Keep batteries out of the reach of small children. If a battery is accidentally swallowed, contact your physician Replace the battery whenever the figures on the display become dim and difficult to read.
