- Page 1 PTM-11/22/33 Series UHF Mono Mode Single / Dual / Quad Wireless In-Ear Monitor System USER MANUAL...
-
Page 2: Important Safety Instructions
Licensing of PHENYX PRO wireless microphone equipment is the user's responsibility, and licensability depends on the user's classification and application, and on the selected frequency. PHENYX PRO strongly urges the user to contact the appropriate telecommunications authority concerning proper licensing, and before choosing and ordering frequencies. -
Page 3: Fcc Information
FCC Information IC Statement This device complies with part 15 of the FCC This device contains license-exempt transmitter(s)/ rules. Operation is subject to the following two receiver(s) that comply with Innovation, Science and conditions: Economic Development Canada's licence-exempt (1) This device may not cause harmful interfer- RSS(s). -
Page 4: Table Of Contents
Thank you for purchasing the Phenyx Pro PTM-11/22/33 Series. For the best results and the utmost satisfaction with your new unit, please read this manual carefully to ensure proper operation, and keep it for future reference. For more information, please visit our store: www.phenyxpro.com Table of Contents System Description.........................6... -
Page 5: System Description
System Description System overview The Phenyx Pro PTM-11/22/33 Series provides a convenient audio monitoring experience. No matter where you stand or how loud the rest of your band and the environment are, you can hear your crystal-clear monitor mix on stage while moving and dancing as you like. The beginner-friendly mono design immerses you in your content and frees you from wire entanglement on stage. -
Page 6: Functions Of Parts
Functions of Parts Transmitters PMT-11 ① ② ③ ④ ⑤ ⑥ ⑦ L/MONO L/MONO LOOP OUT INPUTS ⑧ ⑨ ⑩ PMT-22 ⑦ ① ⑤ ⑥ ④ ③ ② PTM-22 GROUP CHANNEL GROUP CHANNEL VOL 1 VOL 1 SYNC.1 SYNC.2 L/MONO L/MONO L/MONO L/MONO... - Page 7 • Front panel ① Volume control: Adjust the input level of the audio signal from microphones, mixers, and other devices. ② IR window: For infrared synchronization setup. *NOTE: Please short press (tap) the Sync button to initiate IR synchronization (The "Sync" indicator will flash on the LCD during the sync process and disappear when the synchronization is finished or fails due to a timeout).
-
Page 8: Bodypack Receiver
Bodypack receiver PMR-2 ⑤ ⑥ ① ② ③ ④ ⑧ VOL. ⑦ ⑨ MUTE PHONES ⑩ OFF MAX ① Antenna ② PHONE jack ③ Power knob: Twist the knob to power the receiver on and off, and also to increase/decrease the volume. -
Page 9: Operation Guidance
Operation Guidance Step 1: Connect the transmitter and power it up 1 - Use 1/4" TS cables to connect the monitor/auxiliary outputs of the mixer or other signal-sending devices to the transmitter inputs. *NOTE: There are stereo inputs and outputs for the transmitter to mix different audio sources, but there is no stereo function that the transmitter sends signals to bodypack receivers. -
Page 10: Step 2: Turn On The Receiver
Step 2: Turn on the receiver 1 - Install fresh batteries with the correct polarity. 2 - Connect an earphone to the bodypack receiver. 3 - Twist the power knob to power on the bodypack and adjust the volume. MUTE Step 3: Set up the transmitter Short press (tap) the Group button and Channel button to select the desired frequency to operate. -
Page 11: Troubleshooting
Troubleshooting Problem Solution • Select another frequency to try again. • Place the transmitter higher or move it to another place. • Check the volume levels at the transmitter/receiver and Distorted audio/static noises verify that it is not too loud. •... -
Page 12: Specification
Specification • System Frequency Range 530 MHz-580 MHz; 902 Mhz-928 MHz (Depends on local regulations) Transmitter Output Level 10 dBm Operating Range 50 m/164 ft Audio Frequency Response 50 Hz-16 KHz (+/-3 dB) Harmonic Distortion <1% (+/-30 KHz deviation) Dynamic Range >90 dB Operating Temperature -10℃... - Page 13 • 500MHz Frequency Version Frequency List Group 1: 530.05 — 532.3 MHz Group 2: 532.55 — 534.8 MHz PMT-11 Group 3: 535.05 — 537.3 MHz Group 4: 537.55 — 539.8 MHz Group 5: 540.05 — 542.3 MHz Group 1: 530.05 — 532.3 MHz Group 2: 532.55 —...
- Page 14 • 900MHz Frequency Version Frequency List Group 1: 902.35 — 904.6 MHz Group 2: 904.85 — 907.1 MHz PMT-11 Group 3: 907.35 — 909.6 MHz Group 4: 909.85 — 912.1 MHz Group 5: 912.35 — 914.6 MHz Group 1: 902.35 — 904.6 MHz Group 2: 904.85 —...
-
Page 15: Technical Support & Warranty Information
If you are receiving a system that is defective or you have any questions regarding operation or warranty cover, please contact us at support@phenyxpro.com with any questions or concerns and a Phenyx Pro representative will contact you to provide assistance. You can also reach out to us through Facebook page: www.- facebook.com/phenyxusa/ or our official website: www.phenyxpro.com. - Page 16 Made in China Manufacturer: Guangzhou VILAN Technology CO., LTD. Address: No.101 Wanggangdexing Road, Baiyun District, Guangzhou, China www.phenyxpro.com After-sales Service E-mail: support@phenyxpro.com ; info@phenyxpro.com...
