BluPrints SAMPANN REGULAR User Handbook

SAMPANN REGULAR
USER HANDBOOK
Bluetooth Enabled 2-inch (58mm)
Mobile Thermal Printer
AVAILABLE IN 2 MODELS:
SAMPANN REGULAR 2600: 2600 MAH BATTERY
SAMPANN REGULAR 1200: 1200 MAH BATTERY
IVR: +91 8377856941
Email: services@bluprints.in
www.bluprints.in
Know Your Device
BluPrints presents Sampann Regular, a Bluetooth & USB Enabled
Thermal Printer with rechargeable battery and a 5V Charger, It is a
portable receipt printer for Printing on-the-go via all kinds of
USB/Bluetooth enabled devices.
What's on the Device
Sliding Switch: This is an On/Off Switch.
Mode Button:
Paper Feed - Single Press releases (feeds) paper
Mode – Continuous press for 1 second prints device Name, Battery
Status, Comm Mode, Font, Firmware
LED Indications on the LEFT Side:
GREEN – FOR POWER ON
RED – FOR ERROR CONDITIONS: (Note: 1 Blink = Half Second
ON, then OFF)
Bluetooth Not Working: Red LED Blinks once every 3 Sec
Battery is LOW: Red LED Blinks twice every 3 Sec
NO Paper: Red LED Blinks four times after every 3 Sec
Print Head getting Too Hot: Red LED Blinks eight times after
every 3 Sec. If multiple errors occur simultaneously, then the
number blinks will add up.
LED Indications on the RIGHT Side:
FIRST LED: Bluetooth LED, Blinks once BT is connected to App.
SECOND LED: Charging LED. This LED Glows while the Printer is
Charging. Once fully charged, this LED stops glowing. But if a
functioning charger is connected, it glows at least once.
Accessories
CHARGER: 5v 2A Power Adapter
BATTERY: Cylindrical 7.4V/ 1200 or 2600 mAH
CABLE USB For Printing & Charging
PAPER ROLL: 58mm Receipt Size
BELT ATTACHABLE CARRY CASE: Optional
Serial Number
Bluetooth Name: BTPrinter075862
Notes:
Above is an example of the naming convention. actual device name
would be mentioned on the device.
For Sampann Regular 1200, the S.No. will start with S1M
For Sampann Regular 2600, th S.No. will start with S2M
Getting Started
Once the printer is switched ON, RED LED blinks a few times while
configuring Bluetooth Baud Rate & default parameters of Printer.
Please wait for this process to be completed before using the Device.
If the Printer is not getting switched ON:
Check if the Battery is properly inserted.
Connect the charger to charge the Battery
Press MODE Button continuously for 1-2 Sec to get test print
In case print is very light even after connecting the charger, either
battery is faulty, or it is not connected properly to battery connector.
Mode Button shows following important information:
Bluetooth Name (e.g.BTprinter1234), which will show on your
Bluetooth Phone / tab / laptop.
Battery Status to see how much charge the battery has. In case of
low battery, please charge the device for 3 hours before use.
Firmware version
Communication: this shows Bluetooth/USB if both modes are
working properly. It will not show mode(s) that are not working.
Bluetooth Passwords for pairing (if required): 1234 / 0000.
DRIVERS / SOFTWARE / APPS ON WEBSITE
SOFTWARE DEVELOPMENT KIT (SDK)
USB DRIVER – 2 INCHES
WEB PRINT APPLICATION (AVAILABLE ON DEMAND)
DEMO APP – BLUPRINTS SMARTPRINT AVAILABLE ON GOOGLE
PLAYSTORE - https://play.google.com/store/search?
q=bluprints+smart+print&c=apps
USB NOT RECOGNIZED: If this message comes on laptop /desktop
while connecting USB cable to printer, restart the printer (using
ON/OFF switch). If still nor recognized, try with a different data cable.
https://bluprints.in/downloads
YEAR DEVICE NUMBER
S2M 24 07 5862
MONTH
