ASSEMBLY INSTRUCTIONS / INSTRUCTION D'ASSEMBLAGE

Thank you for purchasing this product from Mazin Furniture. Please take the time to read and follow the instructions below. Check that

you have all parts and hardware before assembly. Parts apparently missing are often found in the packing materials.

have all the parts listed, have your dealer contact us and they will be sent to you immediately.

Merci d'avoir acheté ce produit de Mazin Furniture. Veuillez lire et suivre les instructions ci-dessous. Vérifiez avant le montage que

vous avez toutes les pièces et fixations. Les pièces qui semblent manquer se trouvent souvent dans les matériaux d'emballage. Si

vous n'avez pas toutes les pièces de la liste, demandez à votre détaillant et nous vous les enverrons immédiatement.

JOELLE 9044VGY/VBU-3

SOFA/CANAPÉ

PARTS LIST / LISTE DE PIÈCES

2pcs

1pc

2pcs

1pc

Front Legs/Pied avant

Back Legs/pied arriére

Bolts/Boulon

Allen Key/Clé allen

Washer /Rondelle plate

Back Cushion/coussin de dos pour sofa et

causeuse

Pillows/Oreillers

Support Legs For Sofa Only/

Pied Support Pour Sofa

Sofa/Sofa

Page 1 of 2

If you do not

Need help?

Do you have a question about the JOELLE 9044VGY/VBU-3 and is the answer not in the manual?

Page 1 SOFA/CANAPÉ Thank you for purchasing this product from Mazin Furniture. Please take the time to read and follow the instructions below. Check that you have all parts and hardware before assembly. Parts apparently missing are often found in the packing materials.
Page 2 ÉTAPE 1 ÉTAPE 2 STEP 1 / STEP 2 / Please use bolts and tighten legs into pre-drilled holes - Please adjust the folding back frame - Veuillez ajuster le cadre Veuillez utiliser des boulons et serrer les pieds dans des arrière rabattable trous pré-percés ÉTAPE 3...
