ASSEMBLY RATING
The Assembly Rating is a 5-point system that shows the degree of effort needed in
assembling a specific product (with 1 being easy and 5 being difficult). For some
products, two people are recommended.
DIFFICULTE D'ASSEMBLAGE
Le vendeur Assemblee est un systeme à 5 points qui montre le degre d'effort
necessaire à l'assemblage d'un produit specifique (1 etant facile et 5 etant
relativement difficile). Pour certains produits, deux personnes sont recommandes.
DO NOT TIGHTEN SCREWS UNTIL EACH STEP IS COMPLETED
NE PAS SERRER LES VIS JUSQU'À CE QUE CHAQUE ÉTAPE EST TERMINÉ
ASSEMBLY INSTRUCTION
Instruction D'Assemblage
I
TEM NO/ARTICLE :
EASY
FACILE
page 1 of
6
SAGE 5201-48
DIFFICULT
DIFFICILE
