  • Page 1 FUELING SYSTEMS CASE-MOUNTED WELDER O P E R A T O R G U I D E 408001008 r6 MODEL EF1-110V EF1-110V-A EF1-110V-10 EF1-110V-10-A...
  • Page 2 Copyright © 2023 Franklin Electric Co., Inc., Madison, WI 53718. All world rights reserved. No part of this publication may be stored in a retrieval system, transmitted, or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic, or other record, without the prior written permission of Franklin Electric.
  • Page 3: Table Of Contents

    Contents 1 Introduction ........................1 1.1 Documentation ......................1 1.1.1 Symbol Legend ....................1 2 Safety/Security ........................2 2.1 General Safety Information..................2 2.2 Welder Safety Information ..................2 2.3 Liability Restrictions ....................3 2.4 Hazard Assessment ....................3 2.5 Required Personal Protective Equipment (PPEs) ............3 3 Overview ...........................4 3.1 Component / Feature Identification &...
  • Page 4: Introduction

    • Information given in this document is given as a guide only. It is the installer's responsibility to ensure that correct and safe procedures are always followed. • This document and related documents are available from: Franklin Electric at www.franklinfueling.com. 1.1.1 Symbol Legend...
  • Page 5: Safety/Security

    Safety/Security General Safety Information • Only perform procedures in this document you are qualified and certified to perform. • Personnel working on or with energized equipment must be authorized by relevant regulatory bodies to carry out such work and must have the appropriate training.
  • Page 6: Liability Restrictions

    Liability Restrictions NOTE: All liabilities of the supplier are invalidated in the following cases. • The welder is used outside the indicated application area. • Non-UPP® fittings or pipe are used. • The operator has not been trained to use the welder or the UPP® system. •...
  • Page 7: Overview

    Overview UPP® electrofusion fittings are welded by the 110 volt case-mounted welder utilizing a constant, standard alternating current, provided by either a main connection or a generator. Generators must have a rated output of at least 2.8 kW (3.5 kVa) and power input must be between 93 and 127 volts at 40 to 70 Hz.
  • Page 8: Technical Specifications

    Shipping dimensions 420 mm (16.5") wide x 340 mm (13.4") deep x 180 mm (7") high Shipping weight EF1-110V = 12 kg (26 lb) EF1-110V-A = 12 kg (26 lb) EF1-110V-10 = 19 kg (42 lb) EF1-110V-10-A = 19 kg (42 lb) Power Supply Requirements An earth-spike (grounding rod) must be used with generators.
  • Page 9: Application

    Application The 110 volt case-mounted welder is designed to automatically weld UPP® Primary and Secondary Containment electrofusion fittings and Electrofusion Chambers. This is done by using color-coded welding leads as shown in Table 3. Table 3 – Weld and fitting/lead information. Welding Cable Size of Welding Current...
  • Page 10: Multiple Welds

    Multiple Welds In Primary mode, the welder can simultaneously weld up to three UPP® fittings, provided that: • The sum of the resistance values (circled number on UPP® fittings) does not exceed 10. • The UPP® fittings are connected to the welder in series using the bridging leads provided (see photos A &...
  • Page 11: Appendix

    Appendix Maintenance • There are no user serviceable parts inside the welding unit. • Damaged or defective products should be returned to an approved service agent for repair or calibration. • Welding unit and cables should be checked for damage or defects and parts repaired or replaced prior to each use.
  • Page 12: Fault Indicators

    5.2.2 Fault Indicators When an error has occurred during the weld cycle that will have an effect on the success of the joint, the red warning LED on the right side of the display will light up. Also one of the “weld progress” lights will light up at the same time to show what type of fault has occurred.
  • Page 13: Disposal

    Disposal The equipment and packaging should be sorted for environmentally friendly recycling. IMPORTANT: Do not dispose of this equipment into household waste! When no longer suitable for use, this equipment must be separately collected and sent for recycling. European Directive 2012/19/EU: The Waste Electrical and Electronic Waste Electrical and Electronic Equipment Regulations 2013.
  • Page 14 FUELING SYSTEMS 408001008 r6...
