paratech 22-895400G3 Operation And Maintenance Manual

Adjustable pressure regulator
Hide thumbs

Advertisement

Table of Contents

OPERATION AND MAINTENANCE MANUAL
5,500-300 PSI (379,2 – 20,6 BAR) ADJUSTABLE
5,500-150 PSI (379,2 – 10,3 BAR) PRESET
(PART NUMBERS: 22-895401G3 & 22-895401DG3)
5,500-180 PSI (379,2 – 12,4 BAR) PRESET
(PART NUMBERS: 22-895401G3-180 & 22-895401DG3-12)
Paratech Incorporated
P.O. Box 1000, Frankfort, IL 60423 USA
Customer Service: 800.435.9358
Phone: 815.469.3911 Fax: 815.469.7748
www.paratech.com E-mail: paratech@paratech.us
PRESSURE REGULATOR
(PART NUMBERS: 22-895400G3 & 22-895400DG3)
PRESSURE REGULATOR
PRESSURE REGULATOR
Paratech Europe, Branch of Paratech Inc.
P.O. Box 174, 5260 Odense S, Denmark
www.paratech.com Email: Paratech@paratech.dk
FOR
02 SEP 2024
22-895433

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 22-895400G3 and is the answer not in the manual?

Questions and answers

Related Manuals for paratech 22-895400G3

Summary of Contents for paratech 22-895400G3

  • Page 1 OPERATION AND MAINTENANCE MANUAL 5,500-300 PSI (379,2 – 20,6 BAR) ADJUSTABLE PRESSURE REGULATOR (PART NUMBERS: 22-895400G3 & 22-895400DG3) 5,500-150 PSI (379,2 – 10,3 BAR) PRESET PRESSURE REGULATOR (PART NUMBERS: 22-895401G3 & 22-895401DG3) 5,500-180 PSI (379,2 – 12,4 BAR) PRESET PRESSURE REGULATOR (PART NUMBERS: 22-895401G3-180 &...
  • Page 2 II - EXCEPTIONS EXCEPTIONS AUTHORIZED BY NONE Ken Nielsen Chief Operating Officer Paratech Incorporated 1025 Lambrecht Road Frankfort, Illinois 60423-7000 SIGNATURE OF PUBLICATIONS QUALITY ASSURANCE OFFICER DATE SIGNATURE ON FILE QAP20/002/B...
  • Page 3 Change Record Signature of Change Date Title or Brief Description Validating Officer 02 SEP 24 ADDED TO MANUAL: 22-895401G3-180 AND 22-895401DG3-12 SIGNATURE ON FILE QAP20/003/B QAP20/003/...
  • Page 4 Figure Title Page Pressure Regulators, Assembled....................Figure 4-1 22-895400G3 Adjustable Pressure Regulator Exploded View......... 4-1 Figure 4-2: 22-895400DG3 Adjustable Pressure Regulator Exploded View……………………. 4-2 Figure 4-3: 22-895401G3-180 180 Regulator, ALB G3 Preset CGA Exploded View………….. 4-3 Figure 4-4: 22-895401G3 Regulator, AL0B G3 Preset CGA Exploded View…......4-4 Figure 4-5: 22-895401DG3-12 Regulator 12 ALB G3 Preset DIN Exploded View.....

  • Page 5: Basic Safety Precautions

    (Page 4-1) requiring pressure reading(s), certain qualified personnel use proper tools and calibrated test gauges that are accurate to within ±2% of the indicated reading. If not available, return a pressure regulator requiring servicing to Paratech. (Page 4-1)

  • Page 6: Equipment Description

    1-2.2 22-895400G3 & 22-89540DG3, 300 psi ( 2 0 , 7 b a r ) Adjustable P r essure Regulators. For use with rescue support systems and portable pneumatic impact tools. outlet pressure up to 300 psi (20,7 bar).
  • Page 7 STRUT PRESSURE REGULATOR CGA STRUT PRESSURE REGULATOR DIN 22-895400G3 22-895400DG3 PRESET AIR LIFTING BAG PRESET AIR LIFTING BAG REGULATOR G3 CGA REGULATOR G3 DIN 22-895401G3 22-895401DG3 PRESET AIR LIFTING BAG PRESET AIR LIFTING BAG REGULATOR G3-180 CGA REGULATOR G3-12 DIN...

  • Page 8: Controls And Indicators

    2-2. CONTROLS AND INDICATORS. 2-2.1 CONTROLS. The only controls on the pressure regulator are the On/Off valve assembly on all regulators. There is a pressure adjusting knob on two adjustable regulators 22-895400G3 and 22- 895400DG3. There are no other controls on the 4 preset r e g u l a t o r s 2 2 - 895401G3, 22-895401DG3 150 psi (10,3 bar) and 22-895401G3-180, 22-895401DG3-12 180 psi (12.4 bar).
  • Page 9 • 22-895400G3 and 22-895400DG3 Pressure Regulators Only. Turn the pressure adjusting knob to obtain the desired regulated pressure to the system apparatus. Make the final adjustment in the increase direction to provide the most accurate and consistent pressure settings. •...
  • Page 10 RIC Number Length, Depth, Height Feet³ Nomenclature Pounds Unit Number Inch (Centimeter) (Meter³) (Kilograms) Adjustable L: 6.7 (17,0) .014 Pressure 22-895400G3 D: 4.0 (10,2) (1,5) (0,0004) Regulator H: 4.6 (11,7) Adjustable L:8.1 (20,6) .014 Pressure 22-895400DG3 D: 4.0 (10,2) (1,7)

  • Page 11: Troubleshooting

    System Equipment Not Improper pressure setting (Preset Return Preset Regulator to Operating Properly. Pressure Regulators). Paratech for Repair. Defective discharge Pressure Gauge Test discharge Pressure Gauge (Adjustable Pressure Regulators). and replace as required. Defective Seal. Replace Seal on the Nipple.

  • Page 12: Exploded Views

    4-1. EXPLODED VIEWS Figure 4-1 22-895400G3 Adjustable Pressure Regulator Exploded View ITEM 22- P/N DESCRIPTION ITEM 22- P/N DESCRIPTION 895396 BODY, STRUT REGULATOR G3 890935 SPRING PIN 3/32 X 5/16 S.S. 895413 CARTRIDGE HOUSING, REG. 550174 O-RING AS-013 (7/16X.070) BN70 895412 SEAT, MAIN, CARTR.
  • Page 13 Figure 4-2: 22-895400DG3 Adjustable Pressure Regulator Exploded View ITEM 22- P/N DESCRIPTION ITEM 22- P/N DESCRIPTION 895396 BODY, STRUT REGULATOR G3 890935 SPRING PIN 3/32 X 5/16 S.S. 895413 CARTRIDGE HOUSING, REG. 550174 O-RING AS-013 (7/16X.070) BN70 895412 SEAT, MAIN, CARTR. REGULATOR 890489 O-RING 5/16X.070 POLYURETH.
  • Page 14 Figure 4-3: 22-895401G3 Regulator, ALB G3 Preset CGA Exploded View ITEM DESCRIPTION ITEM 22- P/N DESCRIPTION 895423 BODY, REGULATOR G3 PRESET ALB 550174 O-RING AS-013 (7/16X.070) BN70 895413 CARTRIDGE HOUSING, REG. 890489 O-RING 5/16X.070 POLYURETH. 90 895412 SEAT, MAIN, CARTR. REGULATOR 895218 Ø1.25 INT RETAINING RING SS 895513...
  • Page 15 Figure 4-4: 22-895401DG3 Regulator ALB G3 Preset DIN Exploded View ITEM 22- P/N DESCRIPTION ITEM 22- P/N DESCRIPTION 895410 890489 O-RING 5/16X.070 POLYURETH. 90 BODY,REGULATOR DG3, PRESET ALB 895413 CARTRIDGE HOUSING, REG. 895218 Ø1.25 INT RETAINING RING SS 895412 SEAT, MAIN, CARTR. REGULATOR 796V48 Ø1"...
  • Page 16 Figure 4-5: 22-895401G3-180 180 Regulator, ALB G3 Preset CGA Exploded View ITEM 22- P/N DESCRIPTION ITEM 22- P/N DESCRIPTION 895423 BODY, REGULATOR G3 PRESET LB 550174 O-RING AS-013 (7/16X.070) BN70 895413 CARTRIDGE HOUSING, REG. 890489 O-RING 5/16X.070 POLYURETH. 90 895412 SEAT, MAIN, CARTR.
  • Page 17 Figure 4-6 22-895401DG3-12 Regulator 12 ALB G3 Preset DIN Exploded View ITEM DESCRIPTION ITEM 22- P/N DESCRIPTION 895410 BODY,REGULATOR DG3, PRESET ALB 890489 O-RING 5/16X.070 POLYURETH. 90 895413 CARTRIDGE HOUSING, REG. 895218 Ø1.25 INT RETAINING RING SS 895412 SEAT, MAIN, CARTR. REGULATOR 796V48 Ø1"...
