Owner's Manual
Read the instructions before use. This
appliance must be installed in accordance
with such regulations as are in force.
Questions, problems, missing parts. Please call our customer service
department at 1-888-909-3888, 7:30AM - 4:30PM PST, Mon. - Fri..
R
15" Square Gas Fire Pit
Model No.: SRGF12023
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
●
Extinguish any open flame.
●
If odor continues, leave the area
●
immediately.
After leaving the area, call your gas
●
supplier or fire department.
Failure to follow these instructions
could result in fire or explosion,
which could cause property damage,
personal injury, or death.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING:For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
INSTALLER: Leave this manual with
the appliance.
CONSUMER: Retain this manual for
future reference.
SKU#LGF06-0014
Advertisement
Table of Contents
Related Manuals for Bali SRGF12023
Summary of Contents for Bali SRGF12023
- Page 1 15” Square Gas Fire Pit Model No.: SRGF12023 SKU#LGF06-0014 DANGER FIRE OR EXPLOSION HAZARD If you smell gas: Shut off gas to the appliance. ● Extinguish any open flame. ● If odor continues, leave the area ● immediately. After leaving the area, call your gas ●...
-
Page 2: Carbon Monoxide Hazard
Installation and service must be performed by a qualified installer, service agency or gas supplie r. SPECIFICATIONS Product name 15” Square Gas Fire Pit Model No. SRGF12023 Input 26,000 Btu/h (7.62kW) Fuel Propane 20-lb. LP - gas cylinder Gas Supply 11.0 in. -
Page 3: Warnings And Cautions
WARNINGS AND CAUTIONS IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with either the Natural Gas and Propane Installation Code, CSA B149.1, or the Propane Storage and Handling Code, CSA B 149.2. This appliance requires 20 lb (9 kg) LP gas supply cylinder. - Page 4 WARNINGS AND CAUTIONS Use only a cylinder supply system arranged for vapor withdrawal, and the cylinder must include a collar to protect the cylinder valve. DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH.CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS.
- Page 5 WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution before using: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This appliance is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection.
-
Page 6: Exploded View
EXPLODED VIEW PARTS Part Description Quantity 1 pc Gas Fire Pit Support Pad 4 pcs 1 bag Glass Beads 1 pc Cylinder Block Wire... - Page 7 ASSEMBLY INSTRUCTIONS Choose a good,clear assembly area and get a friend to help you to unpack and set up your fire pit. Step 1 Take the gas fire pit from the packaging. Install four support pads(B) first as Fig.1 Note: The support pad stands at the bottom can be adjusted when come across uneven ground.
- Page 8 ASSEMBLY INSTRUCTIONS Step 3 Open the cylinder door first.Unscrew Battery Compartment Cap the battery compartment cap on the control panel, install one AAA battery (not include) with anode end of battery located towards the battery compartment cap. Step 4 Place glass beads(C) (Max.6.6lb) onto the burning area of the gas fire pit.
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION Two or more people are helpful an easier installation. LOCATION Your fire pit must be installed on flat, stable surface, away from any combustible materials or construction. SET-UP 1.Place fire pit on any level, outdoor, non-combustible surface. NOTE:Do not place the appliance on grass or dirt. -
Page 10: Operation
OPERATION WARNING: DO NOT ATTEMPT TO OPERATE THE APPLIANCE UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN PROPERTY DAMAGE, SERIOUS INJURY, OR DEATH. WARNING!!! WARNING Do not use an open flame to check for leakage. FOR YOUR SAFETY: Do not smoke during testing. - Page 11 OPERATION WARNING:DO NOT ATTEMPT TO OPERATE THIS HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS. FAILURE TO DO SO CAN RESULT IN PROPERTY DAMAGE,SERIOUS INJURY,OR DEATH. Before Lighting The gas fire pit should be thoroughly inspected before each use, and by a qualified service person at least annually. If relighting a hot gas fire pit, always wait at least 5 minutes.
- Page 12 OPERATION CAUTION:AVOID INHALING FUMES EMITTED FROM THE GAS APPLIANCE'S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES.THE GAS APPLIANCE SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: The burner may be noisy when initially turned on.
-
Page 13: Locating Heater For Use
LOCATING HEATER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS FIRE PIT WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This gas firepit is primarily used for the Figure 7 heating of outdoor patios, decks, spas, pools and open working areas. -
Page 14: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your WARNING: gas fire pit, make sure you perform the following FOR YOUR SAFETY ; maintenance activities on a regular basis: DO NOT touch or move gas appliance for at least 45 minutes Keep exterior surfaces clean. -
Page 15: Maintenance And Storage
MAINTENANCE AND STORAGE NOTE: Store the fire pit indoors during the winter if it will be subjected Wait until the appliance is to freezing temperatures. cool before covering. Disconnect and remove the cylinder from the appliance before the appliance can be stored indoors. STORAGE Turn the control knob to "OFF"... -
Page 16: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE MEASURES OBSERVED Gas odor Gas leak Check all gas connections Check gas supply pressure. Delayed ignition Low gas pressure. Clean burner parts - see manual. Clogged or dirty burner ports. “CLEANING AND MAINTENANCE” section. Incorrect burner Incorrect gas supply or pressure Check gas supply pressure. -
Page 17: Warranty Information
WARRANTY INFORMATION The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer/purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
