Owner's Manual
Read the instructions before use. This
appliance must be installed in accordance
with such regulations as are in force.
Questions, problems, missing / replacement parts? Before returning to your retailer,
call our customer service department at 1-866-814-0585, 8 a.m. - 8 p.m., EST
Monday-Friday.
TM
52" RECTANGLE GAS
FIRE PIT
Model#SRGF11450
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING:
CAUTION:
Installer: Leave the instruction manual
to the user for future use.
Consumer: Please keep this manual
for future reference.
For Outdoor Use
Only.
Advertisement
Table of Contents
Related Manuals for Bali SRGF11450
Summary of Contents for Bali SRGF11450
- Page 1 52" RECTANGLE GAS FIRE PIT Model#SRGF11450 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.
-
Page 2: Warnings And Cautions
WARNINGS AND CAUTIONS CARBON MONOXIDE HAZARD DANGER This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING : Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. - Page 3 WARNINGS AND CAUTIONS IMPORTANT SAFETY INFORMATION The installation must comform with local codes or, in the absence of local codes, with the CAN/CGA-B 149.2, Propane Installation Code. This appliance requires 20 lb (9 kg) LP gas supply cylinder. The burner must be replaced prior to the appliance being put into operation if it is evident that the burner is damaged.
- Page 4 WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This appliance is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection.
- Page 5 Exploded View...
-
Page 6: Parts List
Parts List QUANTITY Lava rock 1bag Burner assembly Control knob Tabletop Right side panel Right hind leg Right foreleg Front panel Left foreleg Foot pad 4pcs Connecting tube assembly Rail mounting plate 2pcs Cylinder holder Caster 2pcs Cylinder locking bolt Sliding track 2pcs Back panel... - Page 7 ASSEMBLY INSTRUCTIONS 1. Place the lava rocks (2) onto the burner assembly (3). Put the lid (1) onto the tabletop(5) Note: Please remove the lid (1) when using fire pit. 2. Unscrew the battery compartment cap on the control panel, install one AA 1.5 V battery (not included) with anode end of battery located towards the battery compartment cap.
- Page 8 ASSEMBLY INSTRUCTIONS 3. Slide out the door, and place cylinder in the cylinder holder, then attach regulator to cylinder and turn clockwise by hand. Check your fire pit for leaks, see Check for leaks section. After that, push the door back to position.
-
Page 9: Safety Check
SAFETY CHECK Check for leaks Your gas fire pit has been checked at all connections at the factory for leakage. In transportation and handling some connections may have loosened. Follow these steps to check the hose/ regulator/cylinder connections: u q i l uid dish soap and 3 parts water. -
Page 10: Operation
OPERATION WARNING: DO NOT ATTEMPT TO OPERATE THE APPLIANCE UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN PROPERTY DAMAGE, SERIOUS INJURY, OR DEATH. WARNING!!! WARNING Do not use an open flame to check for leakage. FOR YOUR SAFETY: Do not smoke during testing. - Page 11 OPERATION WARNING:DO NOT ATTEMPT TO OPERATE THIS HEATER UNTIL YOU HAVE READ AND UNDERSTAND ALL PRECAUTIONS. FAILURE TO DO SO CAN RESULT IN ATION PROPERTY DAMAGE,SERIOUS INJURY,OR DEATH. Before Lighting The gas fire pit should be thoroughly inspected before each use, and by a qualified service person at least annually.
- Page 12 OPERATION CAUTION:AVOID INHALING FUMES EMITTED FROM THE GAS APPLIANCE'S FIRST USE. SMOKE AND ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES.THE GAS APPLIANCE SHOULD NOT PRODUCE THICK BLACK SMOKE. NOTE: The burner may be noisy when initially turned on.
-
Page 13: Locating Heater For Use
LOCATING HEATER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This gas fire pit is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas. -
Page 14: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : To enjoy years of outstanding performance from your WARNING: gas fire pit, make sure you perform the following FOR YOUR SAFETY ; maintenance activities on a regular basis: DO NOT touch or move gas appliance for at least 45 minutes after use. -
Page 15: Maintenance And Storage
MAINTENANCE AND STORAGE NOTE: Store the fire pit indoors during the winter if it will be subjected to Wait until the appliance is freezing temperatures. cool before covering. Disconnect and remove the cylinder from the appliance before the appliance can be stored indoors. STORAGE Turn the control knob to "OFF"... -
Page 16: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE MEASURES OBSERVED Gas odor Gas leak Check all gas connections Check gas supply pressure Low gas pressure Clean burner parts--see manual Clogged or dirty burner ports Delayed ignition "CLEANING AND MAINTENANCE" section Spent battery Change battery Incorrect burner Incorrect gas supply or pressure Check gas supply pressure...
