SERVICE MANUAL

(GWH09AGB-K6DNA1B/I + GWH09AGB-K6DNA1B/O)

(CB385N02300 + CB385W02300)

(GWH12AGC-K6DNA1A/I + GWH12AGC-K6DNA1A/O)

(CB385N02400 + CB385W02400)

[ PULAR SERIES ]

GWH09AGB-K6DNA1B set

CB385002300 set

GWH12AGC-K6DNA1A set

CB385002400 set

ORIGINAL INSTRUCTIONS, VER. 01 10-02-2021

Table of Contents

Need help?

Do you have a question about the GWH09AGB-K6DNA1B set and is the answer not in the manual?

Questions and answers

Summary of Contents for Gree GWH09AGB-K6DNA1B set

Page 1 SERVICE MANUAL [ PULAR SERIES ] GWH09AGB-K6DNA1B set (GWH09AGB-K6DNA1B/I + GWH09AGB-K6DNA1B/O) CB385002300 set (CB385N02300 + CB385W02300) GWH12AGC-K6DNA1A set (GWH12AGC-K6DNA1A/I + GWH12AGC-K6DNA1A/O) CB385002400 set (CB385N02400 + CB385W02400) ORIGINAL INSTRUCTIONS, VER. 01 10-02-2021...
Page 2: Table Of Contents
Service Manual Part : Technical Information Ⅰ 1. Summary Indoor Unit A1 Panel Outdoor Unit GWH09AGA-K6DNA1A/O GWH12AGB-K6DNA1A/O GWH09AGB-K6DNA1B/O GWH12AGC-K6DNA1A/O GWH18AGD-K6DNA1D/O GWH18AGD-K6DNA1A/O GWH24AGD-K6DNA1C/O GWH24AGD-K6DNA1A/O Technical Information...
Page 3 Service Manual Remote Controller YAP1F7(WiFi) ON/OFF MODE I FEEL T-ON T-OFF TEMP CLOCK LIGHT WiFi SLEEP Model list: Indoor Unit Outdoor Unit Remote Model Product Code Indoor Unit Model Outdoor Unit Model Product Code Controller Product Code CB385001000 CB385N01000 GWH09AGA-K6DNA1A GWH09AGA-K6DNA1A/I GWH09AGA-K6DNA1A/O CB385W01000 CB385001002...
Page 4: Specification Sheet
Service Manual 2. Specifications 2.1 Specification Sheet Model GWH09AGA-K6DNA1A GWH12AGB-K6DNA1A Product Code CB385001000/CB385001002 CB385001700/CB385001702 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 2500 3200 Heating Capacity 2800 3400 Cooling Power Input Heating Power Input Cooling Power Current Heating Power Current Rated Input...
Page 5 Service Manual Model of Outdoor Unit GWH09AGA-K6DNA1A/O GWH12AGB-K6DNA1A/O Product Code of Outdoor Unit CB385W01000 CB385W01700 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer/Trademark CO.,LTD CO., LTD Compressor Model FTz-AN075ACBF-A FTz-AN088ACBF-A Compressor Oil FW68DA FW68DA Compressor Type Rotary Rotary L.R.A. 20.00 Compressor RLA 3.00 3.60...
Page 6 Service Manual Model GWH18AGD-K6DNA1A GWH09AGB-K6DNA1B Product Code CB385001900 CB385002300 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 4600 2700 Heating Capacity 5200 2800 Cooling Power Input 1355 Heating Power Input 1340 Cooling Power Current 3.51 Heating Power Current 3.32...
Page 7 Service Manual Model of Outdoor Unit GWH18AGD-K6DNA1A/O GWH09AGB-K6DNA1B/O Product Code of Outdoor Unit CB385W01900 CB385W02300 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer/Trademark CO.,LTD CO., LTD Compressor Model QXF-A120zH190A FTz-AN075ACBF-A Compressor Oil RB68EP FW68DA Compressor Type Rotary Rotary L.R.A. 18.00 20.00 Compressor RLA 5.00...
Page 8 Service Manual Model GWH12AGC-K6DNA1A GWH24AGD-K6DNA1A Product Code CB385002400 CB385001500 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 3200 6200 Heating Capacity 3400 6500 Cooling Power Input 1631 Heating Power Input 1645 Cooling Power Current 4.15 Heating Power Current 3.86...
Page 9 Service Manual Model of Outdoor Unit GWH12AGC-K6DNA1A/O GWH24AGD-K6DNA1A/O Product Code of Outdoor Unit CB385W02400 CB385W01500 ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer/Trademark CO., LTD CO., LTD Compressor Model FTz-AN088ACBF-A GTD141UKRF8JT6G Compressor Oil FW68DA ACS-68R Compressor Type Rotary Rotary L.R.A. 20.00 Compressor RLA 3.60...
Page 10 Service Manual Model GWH18AGD-K6DNA1D GWH18AGD-K6DNA1D CB385008300 Product Code CB385008302 CB385008301 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 4600 4600 Heating Capacity 5200 5200 Cooling Power Input 1355 1355 Heating Power Input 1340 1340 Cooling Power Current...
Page 11 Service Manual Model of Outdoor Unit GWH18AGD-K6DNA1D/O Product Code of Outdoor Unit CB385W08300 Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD Compressor Model FTz-AN108ACBD Compressor Oil FW68DA or equivalent Compressor Type Rotary L.R.A. Compressor RLA Compressor Power Input Overload Protector Throttling Method Capillary Operation Temp 16~30...
Page 12 Service Manual Model GWH24AGD-K6DNA1C GWH24AGD-K6DNA1C CB385008600 Product Code CB385008602 CB385008601 Rated Voltage 220-240 220-240 Power Rated Frequency Supply Phases Power Supply Mode Outdoor Outdoor Cooling Capacity 6200 6200 Heating Capacity 6500 6500 Cooling Power Input 1786 1786 Heating Power Input 1645 1645 Cooling Power Current...
Page 13 Service Manual Model of Outdoor Unit GWH24AGD-K6DNA1C/O Product Code of Outdoor Unit CB385W08600 Compressor Manufacturer/Trademark ZHUHAI LINDA COMPRESSOR CO., LTD Compressor Model FTz-SM151AXBD Compressor Oil FW68DA Compressor Type Rotary L.R.A. Compressor RLA 6.06 Compressor Power Input 1330 Overload Protector Throttling Method Capillary Operation Temp 16~30...
Page 14: Capacity Variation Ratio According To Temperature
Service Manual 2.2 Capacity Variation Ratio According to Temperature Heating operation ambient temperature range is -15ºC~24ºC Cooling Heating Cooling Conditions Indoor:DB20°C Indoor air flow:Super High Condition Conditions Indoor:DB27°C WB19°C Pipe length:5m Indoor:DB27°C/WB19°C Indoor air flow:Super High Indoor air flow: High Pipe length:5m Pipe length:5m Outdoor temp.(°C)
Page 15: Noise Curve
Service Manual 2.4 Noise Curve Cooling: Heating: Indoor side noise when blowing Indoor side noise when blowing Turbo Turbo Ultralow Medium-high High Medium-high Medium-low Medium Ultralow Medium-low High Medium Indoor fan motor rotating speed Indoor fan motor rotating speed Outdoor side noise when blowing Outdoor side noise when blowing 09/12K Heating 09/12K Cooling...
Page 16: Outline Dimension Diagram
Service Manual 3. Outline Dimension Diagram 3.1 Indoor Unit AGA/AGB Φ55 Φ55 Φ55 Unit:mm Model 133.5 183.5 122.5 707.5 Φ55 Technical Information...
Page 17: Outdoor Unit
Service Manual 3.2 Outdoor Unit 09/12K GWH18AGD-K6DNA1D/O Unit:mm GWH18AGD-K6DNA1A/O Unit:mm Technical Information...
Page 18: Gwh24Agd-K6Dna1A/O
Service Manual GWH24AGD-K6DNA1A/O Unit: mm GWH24AGD-K6DNA1C/O Technical Information...
Page 19: Function And Control
Service Manual 6. Function and Control 6.1 Remote Controller Introduction Notice: This is a general use remote controller. It could be used for the air conditioner with multifunction. For the functions which the model doesn't have, if press the corresponding button on the remote controller, the unit will keep the original running status. After putting through the power, the air conditioner will give out a sound.
Page 20 Service Manual Notice: Set temperature range from remote controller: 16~30 (61- ). Fan speed: auto,quiet,low speed, low-medium Press this button continuously more than 2s, the main unit speed,medium speed,medium-high speed, high speed. will swing back and forth from left to right, and then loosen This mode indicator is not available for some models.
Page 21 Service Manual blinking. " " icon resumes displaying. Cancel T-ON: Unde The interval between two operations can't exceed 5s. the condition that T-ON is started up, press "T-ON " button to Otherwise, remote controller will quit setting status. Operation cancel it. for TIMER ON/TIMER OFF is the same.
Page 22: Function Introduction For Combination Buttons
Service Manual Notice: WiFi Under energy-saving function, fan speed is defaulted at When WiFi function is turned on, " WiFi " icon will be displayed auto speed and it can't be adjusted. on the remote controller; when WiFi function is turned off, Under energy-saving function, set temperature can't be "...
Page 23 Service Manual During cleaning, please make sure the room is well ventilated to avoid affecting the degree of comfort. Notice: The self-cleaning function can only work under normal ambient temperature. If the room is dusty, clean once a month; if not, clean once every three months. After the self- cleaning function is turned on, you may leave the room.
Page 24 GREE+ App Download Linkage Scan the QR code or search "GREE+" in the application market to download and install it. When "GREE+" App is installed, register the account and add the device to achieve long-distance control and LAN control of Gree smart home appliances.
Page 25 Service Manual 6.3 Ewpe Smart App Operation Manual Control Flow Chart Internet Cloud intelligent Cellular/ Home Wi-Fi home Other Wi-FI appliances Home wireless router Home Wi-Fi Operating Systems Requirement for Users smart phone: iOS system Android system Support iOS7.0 and Support Android 4.4 and above version above version...
Page 26 Service Manual 6.4 Brief Description of Modes and Functions Indoor Unit ● 1.Basic function of system (1)Cooling mode (1) Under this mode, fan and swing operates at setting status. Temperature setting range is 16~30 (2) During malfunction of outdoor unit or the unit is stopped because of protection, indoor unit keeps original operation status. (2)Drying mode (1) Under this mode, fan operates at low speed and swing operates at setting status.
Page 27 Service Manual (8)I feel control mode After controller received I feel control signal and ambient temperature sent by remote controller, controller will work according to the ambient temperature sent by remote controller. (9)Entry condition for compulsory defrosting function When turn on the unit under heating mode and set temperature is 16 C (or 16.5 C by remote controller), press “+, -, +, -, +, -”...
Page 28 Service Manual Outdoor Unit ● 1. Cooling mode: Working condition and process of cooling mode: ① When Tindoor ambient temperature≥Tpreset, unit enters into cooling mode. Indoor fan, outdoor fan and compressor start operation. Indoor fan operates according to set fan speed. ②...
Page 29 Service Manual 7. Auto mode Auto mode is determined by controller of IDU. See IDU logic for details. 8. 8 C heating Set temperature is 8 C. Display board of IDU displays 8 C. Under this mode, “Cold air prevention” function is shielded. If compressor is operating under this mode, fan speed will adjust according to auto fan speed;...
