- Page 1 Manual Gas multi-tool DES-45M Applies for: Code Model 103205 DES-45M Motor Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Contents Technical data CAUTION Fuel requirements To gain the best performance of General safety warnings for motor tools the tool, prolong the duty life, make the Warranty valid if Safety warnings for the use of string necessary, and to avoid hazards trimmers of fatal injuries please read and understand this Manual before... -
Page 3: Technical Data
WARNING Trying to start the gas brushcutter without mixing oil into the fuel will cause a faulty motor. Use ACES-2,ACES-5 or ACES-20 TRUPER EXPERT oil caps** to measure the mix. Mix 4 capfuls oil per each gasoline liter. A wrong mix may cause the gas brushcutter to throw a rod... -
Page 4: General Safety Warnings For Motor Tools
General motor tool safety warnings for motor tools Keep your work area clean, tidy and well lit. Wear adequate protective safety accessories. CAUTION CAUTION Cluttered and dark areas may cause accidents. Wear eye protection, dust mask, non-skid safety shoes, helmet and ear plugs. These safety gears reduce the risk Never use the tool in explosive areas or in the presence of injury. -
Page 5: Safety Warnings For The Use Of String Trimmers
Safety warnings for the use of string trimmers • In extreme weather confirm there is no ice forming and Fuel handling condensation in the gas brushcutter. • Confirm the visibility and light conditions are adequate • Never smoke near fuel, or in the gas filling up zone or when preparing the oil mix, nor when operating the to be able to see clearly. -
Page 6: Parts
Parts Starter handle Fuel tank Cover exhaust Choke lever Spark plug cover Fuel tank filter Extension shaft Engine Primer Allen bulb keys Wrench Switch Throttle Spark Throttle lock plug key Control handle Auxiliary Harness ring handle Fuel mixing bottle Shaft Shaft Harness Extension... -
Page 7: Assembly
Assembly Shaft Connection Guard • Remove the retaining pin (A) and insert the end of the • Loosen the guard fastening screws, align the guard holes shaft (B) from the working head into the clamp. with those of the clamp mounted on the cutting head, and •... -
Page 8: Blade Installation
Assembly Blade installation NOTE • Before installing the cutting element, disassemble any previously installed elements. • Insert the Allen wrench (5) on the side of the plate (1), apply pressure to lock the shaft, and turn the safety nut (4) clockwise using the wrench (6) to remove the pre-assembled element. -
Page 9: Fuel Supply
Fuel supply • Follow the safety guidelines for fuel handling (page 5). • Wait for the engine to cool completely before refueling. • Place the tool on a flat surface, leaning it as indicated in the diagram. • Clean around the fuel tank cap to prevent contamina- tion. -
Page 10: Operation
Operation Cutting line reel and blade CAUTION • Remember that as the operator of the trimmer, you are responsible for your safety and that of those near the work area. Follow all safety guidelines (pages 4 and 5) before operating the brush cutter. •... -
Page 11: Chain Saw
Chain saw CAUTION • Use heavy-duty protective gloves to handle the chain safely and prevent cuts. Oil tank cap Sheath Cutting chain Cutting bar Shaft Chain Chain sprocket Assembly of the bar and chain retaining bolt cover 1. Unscrew the nut (A) and remove the cover (B). 2. -
Page 12: Chain Tensioning
Chain saw Chain tensioning • Turn the chain tension screw until it is snug against the hand. If the chain jams or is difficult to move, slightly loosen bar with no slack and the drive links inserted into the bar the mounting nut and turn the tension screw only 1/4 turn. -
Page 13: Operation (Chain Saw)
Operation (chain saw) Preparation CAUTION • Use appropriate protective clothing and equipment. • Start the engine. • Put on the harness. • Never position yourself under the branch you are cutting; be cautious of falling branches. Note that a branch can swing back toward you after hitting the ground! Working position •... -
Page 14: Maintenance (Chain Saw)
Maintenance (chain saw) Top Plate Top Plate Top Plate Top Plate Cutting Edge Cutting Edge WARNING • Before doing any maintenance, turn Depth Depth off the tool. Gauge Gauge • Make sure to wear heavy-duty CAUTION protective gloves. Rivet Sharpening the cutting chain Heel Heel Basic... -
Page 15: Guide Bar Maintenance
Maintenance (chain saw) Chain Depth Gauge Cutting Link 0.6 mm Depth Depth Gauge (0.025”) Gauge • The chain has cleaning teeth (Depth Gauge) placed in front of each tooth. Their design avoids getting too deep into the wood getting pinched and causing kickback. •... -
Page 16: Angle Adjustment
Hedge trimmer Shaft CAUTION • Use protective heavy-duty gloves when Cutting angle handling the blades to ensure safety and prevent cuts. Angle lock adjustment grip lever CAUTION • Turn off the engine and wait until the blade comes to a complete Cutting stop before making any adjustments or blades... -
Page 17: Operation (Hedge Trimmer)
Operation (hedge trimmer) Working conditions • Do not attempt to cut branches larger than 13 mm in diameter (A) with the tool. Cut branches to 10 cm below the 10 cm cutting height using branch cutters before using the tool (B). •... -
Page 18: Maintenance (Hedge Trimmer)
Operation (hedge trimmer) Overhead cut with inclined bar. CAUTION • Any working position above head height can be exhausting. To minimize the risk of accidents, work in these positions for short periods. Adjust the angle of the bar to the maximum so that the unit can be held in a lower and less exhausting position (with a harness) while still providing adequate vertical reach. -
Page 19: Maintenance
Maintenance • Before inspecting, cleaning, or servicing the tool, turn off the engine, wait for all moving parts to come to a stop, disconnect the spark plug cable, and separate it from the spark plug. Otherwise, serious injuries and/or equipment damage may occur. -
Page 20: Troubleshooting
Maintenance After Every Every Every Every Periodic maintenance each use 25 hr of use 50 hr of use 150 hr of use 250 hr of use General cleaning Air filter cleaning Lubrication of the cutting head gear case Carburetor cleaning* Spark plug inspection and adjustment* Fuel tank cleaning** Fuel filter replacement**... -
Page 21: Authorized Service Centers
In the event of any problem contacting a Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800-018-7873 to get information about the nearest Service Center. DE TODO PARA LA CONSTRUCCIÓN FIX FERRETERÍAS... -
Page 22: Warranty Policy
It includes the costs of transportation of the product that derive from its fulfillment of its service network. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
