Summary of Contents for Siemens LD11713TI
- Page 1 Page Size 16K ˜ 18.4 h 26mm ¯ DEEP COOKER HOOD OPERATION AND INSTALLATION INSTRUCTION LD11713TI LD11723TI LD15713TI LD15723TI LD16713TI LD16723TI...
- Page 2 If you have any doubt, please contact our local service center or dealer. If you need a Chinese user manual, please download it from Siemens website. Or you can send the E-mail to service department, or you can call up service hot line for free supply. Thanks! Siemens Home Appliance Chinese Website http://www.siemens-ha.com.cn...
-
Page 3: Table Of Contents
Page Size 16K ˜ 18.4 h 26mm ¯ Catalogue Important Information Package of New Cooker Hood…………….. ………………… 2 Disposal of Used Cooker Hood………….. ……………………2 Before You Begin …………………………………………… Product Introduction Technical Parameters …………………………………………3 Product Standard ………………………………………………3 Operation Instruction Safety Precautions …………………………………………... -
Page 4: Important Information
If there is any obvious damage to the cooker hood, DO NOT connect the cooker hood to the power supply. Please contact the local Siemens home appliance customer service center or distributor immediately. DO NOT disassemble this cooker hood. Repair work must be... -
Page 5: Product Introduction
Page Size 16K ˜ 18.4 h 26mm ¯ Product Introduction Technical Parameters Product model LD11713TI LD11723TI LD15713TI LD15723TI LD16713TI LD16723TI GB model CXW-200-D11713 CXW-200-D11723 CXW-200-D15713 CXW-200-D15723 CXW-200-D16713 CXW-200-D16723 Product Layout Rated voltage 220V ~ 50Hz Power motor 200W Light 2X25W... - Page 6 DO NOT let children or weak people use the cooker hood without attendance. If the light bulb of the cooker hood is damaged, please contact the Siemens customer service centre to replace the damaged light bulb to avoid short circuit. NEVER insert or remove an electric plug with wet hands.
-
Page 7: Operation Installation
Control panel Oil collector Light Control Panel Button “Light ” switch the light on and off. Button “Fan speed ” used to set the fan speed, turn on or off the blower. 2 speeds control. This instruction only applicable to: LD11713TI/LD11723TI... -
Page 8: Set Intermittent Ventilation
Page Size 16K ˜ 18.4 h 26mm ¯ Operation Instruction Button “light ” switch the light on or off. Button “Fan speed ” set fan speed. 2 speeds control Button “Delay ” set the delay shut off of the blower. Button “Fan switch ”... -
Page 9: Alarm Setting
“0” or press “Fan switch ” button, then the alarm is shut off. Setting of fan speed This instruction only applicable to LD11713TI/LD11723TI ˜ ˜ ˜ ˜ Start up the fan Adjust “fan speed ” button to position 1 or 2, the fan is started. - Page 10 Page Size 16K ˜ 18.4 h 26mm ¯ Operation Instruction Setting of fan speed This instruction only applicable to LD15713TI/LD15723TI ˜ ˜ ˜ ˜ Start up the fan 1.Press “fan switch ”button, the fan runs as the highest speed. It displays “ ”...
-
Page 11: Setting Of Delay Shutoff
Page Size 16K ˜ 18.4 h 26mm ¯ Operation Instruction Setting of delay shut off This instruction only applicable to LD15713TI/LD15723TI ˜ ˜ ˜ ˜ The delay shut off function is only available when the fan is running. Example after 3 minutes the cooker hood is turned off automatically. -
Page 12: Installation
Page Size 16K ˜ 18.4 h 26mm ¯ Installation Safety Precautions If your kitchen is under decoration, please DO NOT expose the cooker hood to outside as building materials, dusts, paints and the volatilized gas corrode and stain the surface of the cooker hood. -
Page 13: Installation Position & Height
Page Size 16K ˜ 18.4 h 26mm ¯ Installation Make sure the power supply system (current, voltage and connecting wires) in your house can bear the normal load of the cooker hood. NEVER use high-capacity fuses in the circuit. Choose the fuses listed in the appliance label. -
Page 14: Install Fasteners
Page Size 16K ˜ 18.4 h 26mm ¯ Installation Determine the installation position of the fixing members Install Fasteners (mounting rail and fixing bracket) on the wall following the steps 1/2/3/4 in the figure. Use a pencil or erasable mark pen to draw lines in case that the lines can not be erased after installation. -
Page 15: Connect Exhaust Pipe
Page Size 16K ˜ 18.4 h 26mm ¯ Installation Connect Exhaust Duct Each cooker hood is equipped with an expansion plastic exhaust duct with a diameter of 175 mm. The exhaust duct is 1.75 m long when completely stretched. Please connect one end of the exhaust duct to the outlet duct on the cooker hood and connect the other end of the exhaust duct to the common chimney duct or the drilling hole in the external wall (the diameter of the drilling hole is 180 mm). -
Page 16: Install Oil Collector
Page Size 16K ˜ 18.4 h 26mm ¯ Installation 5. If you need to connect the exhaust duct to the common chimney duct, DO NOT deeply insert the exhaust duct into the common chimney duct in case that the resistance increases when exhausting. -
Page 17: Exchange Light Bulb
Page Size 16K ˜ 18.4 h 26mm ¯ Cleaning ˆ ˆ ˆ ˆMaintenance & Repair Exchange light bulb Pull off the electric plug before cleaning or maintaining the cooker hood. Wear protection gloves when cleaning or maintaining the cooker hood, to prevent your fingers being hurt in cleaning. DO NOT flush the cooker hood directly with water. -
Page 18: Clean And Maintain Your Cooker Hood
Page Size 16K ˜ 18.4 h 26mm ¯ Cleaning ˆ ˆ ˆ ˆMaintenance & Repair Clean and Maintain Your Cooker Hood Pull off the electric plug before cleaning or maintaining the cooker hood. Wear protection gloves when cleaning or maintaining the cooker hood, to prevent your fingers being hurt in cleaning. -
Page 19: Abnormal Phenomena & Troubleshooting
Page Size 16K ˜ 18.4 h 26mm ¯ Cleaning ˆ ˆ ˆ ˆMaintenance & Repair Abnormal Phenomena & Dangerous!!! Troubleshooting Before calling service, check the possible explanations below. If these solutions fail, remove the electric plug of the cooker hood and contact the customer service centre. Abnormal Phenomenon Possible Explanations Troubleshooting... -
Page 20: Customer Service
Page Size 16K ˜ 18.4 h 26mm ¯ Customer Service Dangerous!!! Reminders When cleaning things around the cooker hood (such as ceiling, cabinet) which maybe touch the hoods, please wear protection glove or take other protection methods to prevent be injured. If your cooker hood works improperly, check the possible explanations in "Abnormal Phenomena &... -
Page 21: Warranty
Page Size 16K ˜ 18.4 h 26mm ¯ Customer Service In accordance with the “Regulations Regarding Responsibility for the Warranty Repair, Replacement or Return of Commodities”, the cooker hood is a home appliance, the main parts have a warranty period of three (3) years and the entire product has the warranty period of one (1) year. -
Page 22: Costumer Service Net
Page Size 16K ˜ 18.4 h 26mm ¯ Costumer Service Net – Wholly Owned Special Reminder Please contact us via our service hotline (400 8899 999), and we will pay the telephone fee for you. City Address P.O. Beijing 010-84212139 No.12 HePing Li Street, Dongchen District, BeiJing 100013 Room 2-3-101, Huaxin mansion, Xinkai Road, Hedong District,... - Page 23 Page Size 16K ˜ 18.4 h 26mm ¯ Customer Service Warranty Card...
- Page 24 Page Size 16K ˜ 18.4 h 26mm ¯ Material Number 9000206558 Edition Revise Date July 2006 Siemens Home Appliance Chinese Website: http://www.siemens-ha.com.cn 800 Consult Free Tel: 8008289828 Customer Service E-mail: Careline.China@BSHG.com...
