INSTALLATION,
OPERATION
AND MAINTENANCE
MANUAL
SWITCH ELECTRIC SERIES
Approved for Indoor and Outdoor Use
AC 120V 60Hz 1,465W (5,000 BTU's)
(2,930W 10,000 BTU's capable)
Switch 44
Switch 56
120lbs (54.5kg)
150lbs (68kg)
Switch 96
230lbs (104.3kg)
PLEASE READ THESE INSTRUCTIONS COMPLETELY BEFORE OPERATING THE ECOSMART™ FIRE.
FAILURE TO FOLLOW THEM COULD CAUSE A HEATER MALFUNCTION RESULTING IN SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
WARNING: ALL ELECTRIC HEATERS HAVE HOT AND ARCING OR SPARKING PARTS INSIDE. DO NOT
USE IT IN AREAS WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE OR ARE STORED.
THIS FIREPLACE MEETS THE CONSTRUCTION AND SAFETY STANDARDS OF H.U.D. FOR
APPLICATION IN MANUFACTURED HOMES WHEN INSTALLED ACCORDING TO THESE INSTRUCTIONS.
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
Keep this owner's manual for future references. If you sell or give this product away,
make sure this manual accompanies this product.
Switch 68
175lbs (79.4kg)
Switch 120
280lbs (127kg)
5023705
Switch 80
200lbs (90.7kg)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWITCH ELECTRIC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EcoSmart SWITCH ELECTRIC Series

Summary of Contents for EcoSmart SWITCH ELECTRIC Series

  • Page 1 Switch 96 230lbs (104.3kg) 280lbs (127kg) PLEASE READ THESE INSTRUCTIONS COMPLETELY BEFORE OPERATING THE ECOSMART™ FIRE. FAILURE TO FOLLOW THEM COULD CAUSE A HEATER MALFUNCTION RESULTING IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. WARNING: ALL ELECTRIC HEATERS HAVE HOT AND ARCING OR SPARKING PARTS INSIDE. DO NOT USE IT IN AREAS WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE OR ARE STORED.

  • Page 2: Important Instructions

    ENGLISH Important Instructions When using electrical heaters, basic precautions should always be WARNING: Improper installation, adjustment, alteration, service followed to reduce the risk of fire, electric shock and injury to persons, or maintenance can cause injury or property damage. Refer to including the following: this manual.

  • Page 3: Table Of Contents

    Table of Contents Preparation Installation and Assembly Built-in Installation 3 Sided Installation (Bay) Fully Recessed Installation (Left/Right Corner) Fully Recessed Installation (Single Sided) Half Recessed Installation Outdoor Installation Requirements Hardwiring Installation Installing Media Glass Installation Operation Remote Control Fireplace Touch Control Panel Important Warnings Care and Maintenance Replacement Parts List...

  • Page 4: Preparation

    ENGLISH Preparation Parts and Hardware Bracket (1) Canyon (1) Fireplace (1) Owners Manual (1) Remote (1) Front Glass (6) Screws Driftwood Logs Set (2-4) L-Metal (Depend on Model) (2) Metal Side Smoke Acrylic Clear Acrylic (2) Side Glass (2) Suction Cups Mounting Panels Crystals Pkg...

  • Page 5: Installation And Assembly

    Installation and Assembly DRYWALL STOPS DRYWALL STOPS 24 7/8” 632 mm (all models) Width varies (see chart below) 11 9/16” 294 mm (all models) Dimensions and Specifications Model Viewing Area Firebox Dimensions Framing Dimensions Switch 43 1/4” W x 15 7/8” H x 5 5/16” D 44 1/16”...
  • Page 6 ENGLISH Installation and Assembly This product includes a GLASS panel. Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this fireplace.

  • Page 7: Built-In Installation

    Built-in Installation Optional Built-In styles shown below. See “Partial Recess Installation” or “Wall Mounted Installation” for additional mounting styles. Switch Bay (3 Open Sides) Switch Left Corner (2 Open Sides: Front and Left Corner) Switch Right Corner (2 Open Sides: Front and Right Corner) Switch Single Sided (1 Open Side)

  • Page 8: Sided Installation (Bay)

    ENGLISH Built-in Installation 3 Sided Installation (Bay) 1. Prepare the framed opening according to the chart on page 3. 5. Mask the exposed fireplace during the drywall process. Install drywall to the drywall stops on the perimeter of the fire box. For more *Provide appropriate dedicated circuit for hardwire install at the top information on the drywall stops see the Product Guide on page 3.

  • Page 9: Fully Recessed Installation (Left/Right Corner)

    Built-in Installation Fully Recessed Installation (Left/Right Corner) 1. Follow steps from the 3-sided installation instructions. 4. Wire fireplace (see page 3) for maximum heating power (10,000 BTUs) see page 13 for optional wiring. 2. Remove the corresponding drywall stops according to your installation (in the example, the drywall stops on the left end would 5.

  • Page 10: Fully Recessed Installation (Single Sided)

    ENGLISH Built-in Installation Fully Recessed Installation (Single Sided) 1. Follow steps from the 3 sided installation instructions. 5. Mask the exposed fireplace during the drywall process. Install drywall to the drywall stops on the perimeter of the fireplace. For 2. Remove the drywall stops on both sides of the fire unit. more information on the drywall stops see the Product Guide on page 3.

  • Page 11: Half Recessed Installation

    Built-in Installation Half Recessed Installation 1. This installation is optimized for a 2x4 framed wall. Prepare the 5. Mask the exposed viewing area of fireplace during this process. framed opening according to the height and width of the chart on Install drywall, tile or material of your choice to the drywall stops on page 3.

  • Page 12: Outdoor Installation Requirements

    ENGLISH Outdoor Installation Requirements The Switch Electric Series have been tested and approved for installation outdoors under a patio cover and away from direct water contact or direct sun light. Switch Electric Series standard warranty applies if installed per instructions. All electrical wiring shall be to local building codes.
  • Page 13 Outdoor Installation Requirements Side Protection Side distance (SD) must be 50% (or more) of the height(H). If: H=6’ Then: SD=3’ minimum (6’ x 50%=3’) Note: H taken from bottom of fireplace. OVERHANG HEIGHT (H) SIDE DISTANCE SIDE DISTANCE (SD) (SD) SWITCH FX ©...

  • Page 14: Hardwiring Installation

    ENGLISH Hardwiring Installation A qualified electrician must wire this fireplace to a dedicated • Ensure power from the circuit breaker is off. 110 ~ 120 volt, 20 amps, circuit. • Remove the 2 securing screws from the junction box cover plate, located on the top left-hand, back- side of the appliance (Fig.
  • Page 15 Hardwiring Installation (Continued) 240 Volt Power (10,000 BTUs): This fireplace is equipped with the ability to optionally wire with 240 • Ensure that power from the circuit breaker is off. volts, which will supply 10,000 BTU’s of heat. • Remove the 2 securing screws from the junction box cover plate, located on the top left-hand, back- side of the appliance (Fig.

  • Page 16: Installing Media

    ENGLISH Installing Media 1. Before installing the front glass, evenly spread out the acrylic crystals along the ember bed. 2. Place the logs on top of the acrylic crystals. 3. The front glass can now be installed. #1 Log #2 Log #3 Log #4 Log #5 Log...

  • Page 17: Glass Installation

    Glass Installation Installing Side Glass Installing Front Glass 1. The unit has 2 channels, one on the top and one on the bottom 1. The unit has 2 channels, one on the top and one on bottom to hold to hold the side glass. the front glass.

  • Page 18: Operation

    ENGLISH Operation Methods of Operation Pairing Remote or Optional Wall Mounted Touch Control This electric fireplace can be operated by the Fireplace Touch Control Panel located on the UPPER right corner of the fireplace, or by the battery-powered Remote Control. Before beginning, read pairing instructions in its entirety.
  • Page 19 If the fireplace is on, this button will act as a reset and bring all Home colors back to the default EcoSmart Fire’s signature color. Heat This will cycle the heater between high, low and off . All zones of the fireplace will cycle through various demo Mode modes - 7 &...

  • Page 20: Fireplace Touch Control Panel

    ENGLISH Operation Fireplace Touch Control Panel Toggle Switch Manual Controls The fireplace has a main toggle switch located next to the manual The fireplace has manual controls located next to the toggle switch, in controls. The toggle switch is in front of the glass on the top right front of the glass on the top right side of the viewing area.

  • Page 21: Important Warnings

    Operation Important Warnings Temperature Limiting Control Note This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature, the heater will automatically turn When the heater is first turned on, a slight odor may be present. This Off.

  • Page 22: Care And Maintenance

    ENGLISH Care and Maintenance Cleaning Maintenance Always turn heater OFF from the breaker before Risk of electric shock! Do not open any panels! No cleaning, performing maintenance, or moving this user-serviceable parts inside! fireplace. Failure to do so could result in electric Always turn the heater OFF from the breaker shock, fire, or personal injury.

  • Page 23: Replacement Parts List

    Replacement Parts List Spare Parts, Part Switch 44 Switch 56 Switch 68 Switch 80 Switch 96 Switch 120 Ref. Numbers Front Glass ESF.1.A.P.SW.44.WS ESF.1.A.P.SW.56.WS ESF.1.A.P.SW.68.WS ESF.1.A.P.SW.80.WS ESF.1.A.P.SW.96.WS ESF.1.A.P.SW.120.WS Side Glass ESF.1.A.P.SW.SDG Acrylic Plastic ESF.1.A.P.SW.44. ESF.1.A.P.SW.56. ESF.1.A.P.SW.68. ESF.1.A.P.SW.80. ESF.1.A.P.SW.96. ESF.1.A.P.SW.120.APP Panel Step Motor ESF.1.A.P.SW.STM PTC Heater...
  • Page 24 ENGLISH Replacement Parts List Spare Parts, Part Switch 44 Switch 56 Switch 68 Switch 80 Switch 96 Switch 120 Ref. Numbers ESF.1.A.P.SW.44. ESF.1.A.P.SW.56. ESF.1.A.P.SW.68. ESF.1.A.P.SW.80. ESF.1.A.P.SW.96. ESF.1.A.P.SW.120. Log Set LOGS LOGS LOGS LOGS LOGS LOGS Metal Side Brace for ESF.1.A.P.SW.MSB Plastic Panel Metal Bottom Brace for Flame...

  • Page 25: Troubleshooting

    Troubleshooting Turn off the appliance completely and let it cool down before servicing. Only a qualified service person should service and repair this electric appliance. Problem Possible Cause Solution Breaker tripped or circuit has no Reset breaker, test circuit for power, check power power switch Internal component is frozen and needs to be...

  • Page 26: Faq's

    ENGLISH FAQ’s Q. How do you change the optional Wall Mount Touch Control to Q. How often do the batteries in the remote need to be replaced? Fahrenheit/Celsius? A. Annually, possibly more with heavy use. A. Long press on the up and down arrows on the fireplace to toggle between Fahrenheit and Celsius.
  • Page 27 © Copyright 2004 - 2024 MAD Design USA. All rights reserved. V2403...
  • Page 28 MAD Design USA 311 N. Robertson Blvd. Private Mail Box #932 Beverly Hills, CA 90211 T +1 (888) 590.3335 E info@mad-usa.com V2403 This product is distributed by EcoSmart Inc DBA MAD Design USA.
