- Page 1 MAGUIRE PRODUCTS INC. Peristep 4-Roller Pump Model MS4 Peristaltic Liquid Color Pump INSTRUCTION MANUAL Copyright Maguire Products, Inc. 2019...
- Page 2 P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Rev: June 26, 2019...
-
Page 3: Accuracy Of This Manual
The information contained within this manual including any translations thereof, is the property of Maguire Products Inc. and may not be reproduced, or transmitted in any form or by any means without the express written consent of Maguire Products Inc. -
Page 4: Table Of Contents
M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Maguire Products Inc. Model MS4 PeriStep 4-Roller Pump ™ Table of Contents... -
Page 5: Principle Of Pump Operation
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Principles of Pump Operation The MAGUIRE PeriStep™... -
Page 6: Pump Tubing & Throughput Specifications
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r cycle of a peristaltic pump. The sun roller drives the planetary rollers by means of friction contact, providing a 5 to 1 speed reduction without a gear box. -
Page 7: Description Of Controls
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Description of Controls 1. ON/OFF Switch The power switch is simply the internal connection between the pump’s power cord and the pumps power supply. -
Page 8: Startup Procedure
NOTE: Adaptor Plates are available from MAGUIRE PRODUCTS that mount between the hopper and feed throat. This will allow easy insertion and removal of the color delivery tube into the feed throat of the process machine. -
Page 9: Boot-Up Screen
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r 5. Open the pump head by turning the hand screw counter-clockwise. Complete removal of the hand screw is not necessary. -
Page 10: Run Modes
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r In Extrusion Following mode the top window only shows the live extruder throughput (in Lbs or Kg per hour). -
Page 11: Continuous Mode
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r The tubing color setting corresponds to Maguire’s 3 different tube size options. This setting must match the actual tubing being used for accuracy. - Page 12 P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r (20 seconds after parameters are set, the pump will automatically save all settings, and return to the home screen.) Injection Molding (Cycle Mode) In Cycle mode, the MS4 will observe the time duration of screw signal between pin 1 and 2...
- Page 13 P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r (20 seconds after parameters are set, the pump will automatically save all settings, and return to the home screen.) Extrusion Following Mode In Extrusion following mode, a 0-10 VDC signal is fed into the pump over the red (+) and...
-
Page 14: Tube Selection Guide
“Grn”, which corresponds to 1/8” I.D. green tube sets. Any model MS4 pump is capable of running the 3 available tube color selections supplied by Maguire Products. The 3 different colors vary in size to enable a wider dosing range for this pump. -
Page 15: Throughput Offset Calibration
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r be compensated by slightly adjusting the Throughput offset calibration over time, or simply replacing the tube set altogether. -
Page 16: High Rate Notification
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r High Rate Notification If the unit is displaying a high rate notification, this means the pump is having trouble dosing enough liquid. -
Page 17: Changing Colors
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Changing Colors 1. Run the pump in REVERSE to empty the tube of color. 2. - Page 18 P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r 3. Once this is done and you are assured of a continuous air passage through the tubing, the tubing assembly should be removed from the pump head and color container and placed in a large utility sink.
-
Page 19: Exploded Views
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Exploded View of Pump Head Rev: June 26, 2019... -
Page 20: Internal Wiring Diagram
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Internal Wiring Diagram Rev: June 26, 2019... -
Page 21: Hookup Diagram
P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Hook-up Diagram Rev: June 26, 2019... -
Page 22: Warranty
MAGUIRE PRODUCTS neither assumes nor authorizes any other persons to assume for it any other liability in connection with the sale of its products. -
Page 23: Technical Support And Contact Information
Tamworth Staffordshire B775DY Tel: + 44 1827 265 850 Fax: + 44 1827 265 855 Email: info@maguire-europe.com Maguire Products Asia PTE LTD Main Office 15 Changi North Street 1 #01-15, I-Lofts Singapore 498765 Tel: 65 6848-7117 Fax: 65 6542-8577 E-mail: magasia@maguire-products.com.sg... - Page 24 P u m p M A G U I R E P R O D U C T S , I N C . M S 4 4 - R o l l e r Rev: June 26, 2019...
