SmartSol
LK 150 Access
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cerbos SmartSol LK 150 Access and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LK Armatur Cerbos SmartSol LK 150 Access

Summary of Contents for LK Armatur Cerbos SmartSol LK 150 Access

  • Page 1 SmartSol LK 150 Access INSTRUCTION MANUAL...
  • Page 2 These Assembly and Operating Instructions are an integral part of the product. > Read Assembly and Operating Instructions carefully before using the product. > Keep them in a safe place during the product‘s service life. Translation from the German original edition ©emz 2015 - Subject to modifi cations. The contents and representations of these Assembly and Operating Instructions are the intellectual property of emz-Hanauer GmbH &...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Table of contents Page Important fundamental information Symbols used Description Dimensions Technical Data Designation of the components Operation of the controller Display Opening the terminal cover Wall-mounting Connection to power supply Data interfaces Hydraulic systems Functions for boiler control Thermostat functions Commissioning mode Automatic mode...

  • Page 4: Important Fundamental Information

    IMPORTANT FUNDAMENTAL INFORMATION These instructions describe installation, commissioning, operation, repair and disassembly of the differential temperature controller smart Sol for solar thermal plants. For operation of the entire plant, the technical documentation of all the components used such as solar collectors, boiler, tank, pumps, mixers and valves etc.

  • Page 5: Symbols Used

    SYMBOLS USED When handling the differential temperature controller smart Sol and the entire plant, please make sure that the following safety provisions in the Assembly and Operating Instructions are complied with! Danger! Immediate danger for assets, life and limb! Important! Important information compliance with which is essential! Note! Useful information regarding handling of the device and the plant!

  • Page 6: Description

    DESCRIPTION The differential temperature controller smart Sol is an independent electronic controller for surface-mounting which is used for the control of solar thermal plants. The controller is equipped with a robust three-part plastic housing which can only be opened by means of tools (screw driver PH2). Operation is effected by means of only two control elements;...

  • Page 7: Dimensions

    DIMENSIONS 115 mm 46 mm 5mm/9mm 26 mm 57,5 mm 57,5 mm 173 mm 120 mm 5 mm 27 mm...

  • Page 8: Technical Data

    TECHNICAL DATA Intended Use The differential temperature controller may be used exclusively as controller for the con- trol of solar thermal plants. It must be operated within the scope of all the specifi cations described. Installation and set-up of the controller may only be performed by specialists. The fi...
  • Page 9 TECHNICAL DATA Max. cross sections to be connected Cable end sleeve: 0.25 to 0.75 mm Single-wire 0.50 to 1.50 mm Fine-wired 0.75 to 1.50 mm Interfaces TS1 / TS2 / TS3 / TS4 Design 2 spring-type terminals each Assignment as inputs Admissible temperature probe Temperature sensor Pt 1000 Optional assignment of...

  • Page 10: Designation Of The Components

    DESIGNATION OF THE COMPONENTS Rotary encoder with OK button Display esc button Housing cover Housing base For better accessibil- ity to the Vortex plug connector, it is possible to rip out the lug from the cover plate of the housing. Spare fuse Fuse Vortex plug connector...

  • Page 11: Operation Of The Controller

    OPERATION OF THE CONTROLLER The entire set-up and operation of the differential temperature controller smart Sol is effected via only two control elements on the device front. All settings and interrogations are effected via the rotary encoder. To fi nd a required menu item, turn the rotary encoder to ›scroll‹ through the menu - the selectable option appears on a coloured background on the display.

  • Page 12: Display

    DISPLAY For indication of the operating mode and for communication in case of set-up, malfunction, modifi cation and evaluation, the differential temperature controller smart Sol is equipped with a coloured full graphics display which is permanently backlit. The display is active as long as there is supply voltage on the controller. After a preset time (30 - 255 s), backlighting is dimmed to 10%.

  • Page 13: Opening The Terminal Cover

    OPENING THE TERMINAL COVER Danger! Mortal danger due to electrocution! Whenever work is performed on the open terminal cover, all poles of the power supply must be disconnected reliably and protected against being switched on again! Release the lock screw. Swing terminal cover forward ...

  • Page 14: Wall-Mounting

    WALL-MOUNTING Important! The device corresponds to protection type IP 20 - make sure the appropriate prerequisites exist on the envisaged place of installation. Do not use the housing base as drill template. A device with damaged housing must not be operated! Fasten the top securing bolt so that a space of 2 to 3 mm is created between the wall and...

  • Page 15: Connection To Power Supply

    CONNECTION TO POWER SUPPLY Danger! Mortal danger due to electrocution! Whenever work is performed on the open terminal cover, all poles of the power supply must be disconnected reliably and protected against being switched on again! The differential temperature controller smart Sol is connected to the power supply via three groups of spring-type terminals which are visible once the terminal cover is opened.
  • Page 16 CONNECTION TO POWER SUPPLY Connection of a switching valve to RO1/RO2 Connection diagram for a switching Connection diagram for a switching valve without power supply to RO2: valve with power supply to RO2: L‘ Valve Valve Connection of a switching valve to REL Connection diagram for a switching Connection diagram for a switching valve without power supply to REL:...
  • Page 17 CONNECTION TO POWER SUPPLY Volumetric fl ow sensor: Measurement of solar radiation (heat quantity): The solar yield is calculated from the fl ow rate and the differential temperature. The differential temperature is the difference in the temperature of the collector sensor and the solar circuit return line sensor.
  • Page 18 CONNECTION TO POWER SUPPLY Important! Depending on whether HE pumps are used as solar or heating pumps, they are supplied with proportional or inverted control signals. (Both analogue and PWM control.) 10V analog/ 100% PWM 9-10 mm The strain relief device can only ensure solid clamping if the cables are not stripped to a length of over 35 mm.

  • Page 19: Data Interfaces

    DATA INTERFACES The solar controller has the following data interfaces: The cut-outs at the left of the housing base accommodate a USB port as well as a slot for a storage medium (Micro SD card). These interfaces are used, for example, for reading of error messages or log data or loading of software updates.

  • Page 20: Hydraulic Systems

    HYDRAULIC SYSTEMS Note! Defi ne structure and design of the plant already when planning the entire solar thermal system and align the design with the one of the hydraulic systems of the controller! If you want to complete an existing system or replace the existing controller, please make sure that smart Sol is compatible with the existing confi...

  • Page 21: Hydraulic System

    HYDRAULIC SYSTEM 1 Collector sensor 1 Tank 1 Solar circuit pump 1 Tank sensor 1, bottom Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom...
  • Page 22 HYDRAULIC SYSTEM 2 Collector sensor 1 Tank sensor 1, Tank 1 Solar circuit pump 1 Tank sensor 1, bottom Connection to Collector sensor 1 power supply heating boiler con- nection according to Solar circuit pump 1 Tank sensor 1, bottom page 45-46 Tank sensor 1, top...
  • Page 23 HYDRAULIC SYSTEM 3 Collector sensor 1 Charging area valve Tank sensor 1, Solar Tank 1 circuit pump 1 Tank sensor 1, bottom Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Tank sensor 1, top Charging area valve...
  • Page 24 HYDRAULIC SYSTEM 4 Collector sensor 1 Tank sensor 1, Solar Tank 1 circuit pump 1 Tank sensor 1, bottom Charging area valve Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Tank sensor 1, top Charging area valve...
  • Page 25 HYDRAULIC SYSTEM 5 Collector sensor 1 Heat exchanger sensor Solar circuit Tank 1 pump 1 Heat exchanger Tank pump sensor 1, bottom Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Heat exchanger sensor Heat exchanger pump...
  • Page 26 HYDRAULIC SYSTEM 6 Collector sensor 1 Tank sensor 1, Heat exchanger sensor Solar circuit Tank 1 pump 1 Heat exchanger Tank pump sensor 1, bottom Connection to Collector sensor 1 power supply heating boiler con- nection according to Solar circuit pump 1 Tank sensor 1, bottom page 45-46 Tank sensor 1, top...
  • Page 27 HYDRAULIC SYSTEM 7 Collector sensor 1 Bypass sensor Tank 1 Solar circuit pump 1 Tank sensor 1, bottom Bypass valve Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Bypass sensor Bypass valve...
  • Page 28 HYDRAULIC SYSTEM 8 Collector sensor 1 Tank sensor 1, Bypass sensor Tank 1 Solar circuit pump 1 Tank sensor 1, bottom Bypass valve Connection to Collector sensor 1 power supply heating boiler con- nection according to Solar circuit pump 1 Tank sensor 1, bottom page 45-46 Tank sensor 1, top...
  • Page 29 HYDRAULIC SYSTEM 9 Collector sensor 1 Tank sensor 1, Transfer pump Tank 1 Tank 2 Solar circuit pump 1 Tank Tank sensor 2, sensor 1, bottom bottom Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Tank sensor 1, top Transfer pump Tank sensor 2, bottom...
  • Page 30 HYDRAULIC SYSTEM 10 Collector sensor 1 Tank 1 Tank 2 Solar circuit pump 1 Tank Tank sensor 1, sensor 2, bottom bottom Note: Priority charging has been set to T2 in the factory. Solar circuit pump 2 Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom...
  • Page 31 HYDRAULIC SYSTEM 11 Collector sensor 1 Tank sensor 2, Tank 1 Tank 2 Solar circuit pump 1 Tank Tank sensor 1, sensor 2, bottom bottom Note: Priority charging has been set to T2 in the factory. Solar circuit pump 2 Connection to Collector sensor 1 power supply...
  • Page 32 HYDRAULIC SYSTEM 12 Collector sensor 1 Tank 1 Tank 2 Tank Tank Solar circuit sensor 1, sensor 2, pump 1 bottom bottom Note: Priority charging has Tank switching valve 1 been set to T2 in the factory. Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom...
  • Page 33 HYDRAULIC SYSTEM 13 Collector sensor 1 Tank sensor 2, Tank 1 Tank 2 Tank Tank Solar circuit sensor 1, sensor 2, pump 1 bottom bottom Note: Priority charging has Tank switching valve 1 been set to T2 in the factory. Connection to Collector sensor 1 power supply...
  • Page 34 HYDRAULIC SYSTEM 14 Collector Collector sensor 1 sensor 2 Tank 1 Tank Solar circuit Solar circuit sensor 1, pump 1 pump 2 bottom Connection to Collector sensor 1 power supply Solar circuit pump 1 Tank sensor 1, bottom Collector sensor 2 Solar circuit pump 2...
  • Page 35 HYDRAULIC SYSTEM 15 Collector Collector sensor 1 sensor 2 Tank sensor 1, top Tank 1 Tank Solar circuit Solar circuit sensor 1, pump 1 pump 2 bottom Connection to Collector sensor 1 power supply heating boiler con- nection according to Solar circuit pump 1 Tank sensor 1, bottom page 45-46...
  • Page 36 HYDRAULIC SYSTEM 16 Note: Heating return tempera- Collector sensor 1 ture increase only possible at the REL output! Tank sensor 1, top Tank sensor 1, Solar Tank 1 bottom circuit pump 1 Return line sensor Three-way valve, return temperature increase Connection to Collector sensor 1 power supply...
  • Page 37 HYDRAULIC SYSTEM 17 1 Collector sensor 2 Heat Swimming exchanger pool sensor sensor Solar circuit pump 1 Heat exchanger pump Collector rever- sing valve Collector sensor 1 Connection to power supply Collector reversing valve Heat exchanger sensor Solar circuit pump 1 Connection according to page 16 Swimming pool sensor...
  • Page 38 HYDRAULIC SYSTEM 18 1 Collector sensor 2 Heat Swimming exchanger pool sensor sensor Solar circuit Solar circuit pump 1 pump 2 Heat exchanger pump Collector sensor 1 Connection to power supply Heat exchanger pump Connection according Heat exchanger sensor Solar circuit pump 1 to page 16 Attention ! Maximum...
  • Page 39 HYDRAULIC SYSTEM 19 Collector sensor Heat Swimming exchanger pool sensor sensor Tank sensor 1, Tank 1 bottom Solar circuit pump 2 Heat exchanger pump Solar circuit pump 1 Note: Priority charging has been set to T1 in the factory. Collector sensor 1 Connection to power supply Heat exchanger pump...
  • Page 40 HYDRAULIC SYSTEM 20 Collector sensor Heat Swimming exchanger pool sensor sensor Tank sensor 1, Tank 1 bottom Solar circuit pump 1 Accumulator re- Heat exchanger pump versing valve 1 Note: Priority charging has been set to T1 in the factory. Collector sensor 1 Connection to power supply...

  • Page 41: Functions For Boiler Control

    FUNCTIONS FOR BOILER CONTROL The functions for boiler control are accomplished via the potential-free relay contact which is connected accordingly to the relevant interface of the heating boiler. The individual functions are assigned the following priorities: Anti-legionella priority 1 11 14 12 recharge suppression priority 2 reheating...
  • Page 42 FUNCTIONS FOR BOILER CONTROL Disable recharge The effi ciency of a solar plant increases as the recharge of the tank from the boiler decreases. Consequently, „disable recharge“ means that recharging of the water tank is blocked by the boiler. Recharge suppression during solar yield The recharge function of the heating boiler is suppressed while a solar circuit pump is operating.
  • Page 43 FUNCTIONS FOR BOILER CONTROL Note! For boilers without control input, the functions for boiler control can be accessed by the simulation of temperature values. To enable reheating or anti-legionella functions, the corresponding boiler temperature must be increased at the boiler control. The differential temperature controller smart Connection provided at the Sol regulates the boiler control functions by...

  • Page 44: Thermostat Functions

    THERMOSTAT FUNCTIONS The controller’s free outputs can be used as thermostats for various applications. Settings must be made to this effect in professional mode under ›1.3.1 Thermostat‹. Control signals can be defi ned as temperature thermostat, timer, timer thermostat or temperature comparator. T OFF T ON Temperature thermostat ›Heating‹:...

  • Page 45: Commissioning Mode

    COMMISSIONING MODE Important! For commissioning, the controller must be assembled correctly, all inputs and outputs must be connected and ready for operation, the strain relief device must be screw-fastened and the terminal cover closed! This is an explanation in terms of an example of commissioning of the differential temperature controller smart Sol;...

  • Page 46: Factory Settings

    COMMISSIONING MODE 0.2 Date setting Time 09:14 If there is an SD card with already saved Auto. Clock Change confi gurations in the device, the menu item „Choose fi le“ appears at the end. Choose scheme Select „Choose File“ and acknowledge with Free confi...
  • Page 47 COMMISSIONING MODE If you select „Choose system“, the graphic System 1 illustration of a hydraulic system is shown. Scroll through all available schemes using the rotary encoder, select the illustrated scheme by pressing the „OK“ button. Then, any parameters relevant for the se- lected scheme are queried.
  • Page 48 COMMISSIONING MODE 0.3 Outputs Heat exchanger p Some other output assignments offer further HE control signal options: e.g. pumps may be specifi ed as high- effi ciency pumps. Runs with solar pump Specifi c options can be selected for individual assignments.
  • Page 49 COMMISSIONING MODE 0.3 Outputs Solar pump 1 The HE control signal is specifi ed as: analogue solar pump / PWM solar pump / analogue HE control signal heating pump / PWM heating pump / Wilo Solar pump - Analog Type ST25/7 PWM.
  • Page 50 COMMISSIONING MODE 0.4 Inputs HE control signal Continue with „Sensors“ once all assigned inputs have been allocated. Sensor Next 04. 07. 2015 09:19 0.4.1 Volume fl ow Impeller 1 Vortex UI12 If the volume fl ow is measured with an impel- Heat quantities ler, „Impeller 1“...
  • Page 51 COMMISSIONING MODE 0.4.1 Volume fl ow Impeller 1 ... specify the unit as Imp/l or l/Imp as well Unit Imp/l as the corresponding factor with 1 to 100 Pulses/litre Imp/l or 0.1 to 10.0 l/Imp. Select the cor- 1Imp/l responding output. connected to Continue to scroll.
  • Page 52 COMMISSIONING MODE 0.4.1 Volume fl ow connected to Vortex UI12 Heat quantities Select „Heat quantities“. Next 04. 07. 2015 09:21 1.1.4 Heat quantities Heat qty. 1 Heat qty. 2 Diagram Week Select a heat quantity counter. Heat qty. 0kWh 04. 07. 2015 09:22 1.1.4.1 Heat qty.
  • Page 53 COMMISSIONING MODE 1.1.4.1 Heat qty. 1 Ret.line sens. the return line sensor and the supply line sen- Supp.line sens. sor must be specifi ed. Glycol type Specify the heat exchanger medium: water / propylene glycol / ethylene glycol / Tyfocor / Water as antifreeze protection.
  • Page 54 COMMISSIONING MODE 1.1.4 Heat quantities Display of the diagram Return by pressing the „esc“ key. 365d [kWh] 04. 07. 2015 09:24 0.4 Inputs HE control signal „0.4 Inputs“ is displayed again. Acknowledge your input by pressing „Next“. Sensor Next 04. 07. 2015 09:24 System 1 All hydraulic schemes which are possible due...

  • Page 55: Test Outputs

    COMMISSIONING MODE 0.7 Checklist Test outputs Holiday function „0.7 Checklist“ appears. Next Check the function by selecting „Test out- puts“. 04. 07. 2015 09:25 0.7.1 Test outputs „0.7.1 Test outputs“ appears. Select output, activate with „OK“, select „On“ on the rotary encoder and activate it with „OK“.
  • Page 56 COMMISSIONING MODE 0.7 Checklist Test outputs Holiday function Next Select the „Holiday function“. 04. 07. 2015 09:26 Various options can be selected 0.7.2 Holiday function for the holiday function. Tank recooling At lower ambient temperatures (e. g. at night), tank recooling tries Soft charge to dissipate heat via the collectors.
  • Page 57 COMMISSIONING MODE „0.8 Parameter“ appears 0.8 Parameter Setting the limit temperatures: T limit 1 60.0°C The tanks are only loaded until the maximum T max.tank 1 59.0°C temperature „T max. tank“ has been reached. T limit 2 60.0°C In case of imminent collector overheating, the tanks are loaded to „T limit“.
  • Page 58 COMMISSIONING MODE 1.5.3 Antifreeze pr... Activation and setting of the anti-freeze protective function for the collector. Activation Via ›T ON‹, enter the anti-freeze protection T ref 5.0°C temperature for water-fi lled plants. T ON 5.0°C If anti-freeze products are used, the type can be defi...

  • Page 59: Solid Fuel Boiler

    COMMISSIONING MODE 1.3.2 Tube collector ... the pump delivery rate as a n solar 1 100% percentage value can be entered. t solar 2 The two time programs are n solar 2 performed one after the other. Continue via the menu item t start 06:00 ›Holiday function‹.

  • Page 60: Time Period

    COMMISSIONING MODE 1.3.10 Post Heatin... Max. temp. 55.0°C Use ›Boiler sensor‹ to assign the temperature Sensor boiler sensor which supplies the temperature value of the boiler. Time block 1 Up to six time blocks can Time block 2 be activated for reheating. Time block 3 04.
  • Page 61 COMMISSIONING MODE 0.9 End You have completed ›0.8 Parameter‹ reappears. commissioning! Acknowledge by pressing ›Next‹. ›0.9 End‹ appears. By ›Next‹, the controller changes over to ›Automatic mode‹. Next 04. 07. 2015 09:30 System 1 Commissioning is complete. From now on, the solar thermal plant is con- trolled automatically.

  • Page 62: Automatic Mode

    AUTOMATIC MODE System 1 In automatic mode, the screen displays the date, the time and the active hydraulic system. The current temperature is displayed for each temperature sensor. Pump operation and valve position are illus- trated on the animated display. There is no need for intervention by the fi...

  • Page 64: Operation Mode

    OPERATION MODE Note! The following illustration shows the structure of the control menu. The controller does not display any sub menus which are not required by either the selected scheme or by the activated options. 1 Main menu 1.1 Evaluation 1.1.1 Measured values 1.9 About 1.1.2 Service hours...
  • Page 65 OPERATION MODE System 1 On the controller, the user can make various settings and obtain information about states and processes. To this effect, press the button ›OK‹ in automatic mode. 04. 07. 2015 10:19 1 Main Menu Evaluation Settings ›1 Main menu‹ appears. Basic functions A list of subitems appears Effi...

  • Page 66: Measured Values

    OPERATION MODE 1.1 Evaluation Measured values ...›1.1 Evaluation‹ appears. Service hours Another selection level appears. CO2 savings Once the fi rst subitem Heat quantities ›Measured values‹ is selected, ... Message list 04. 07. 2015 10:20 1.1.1 Measured val..›1.1.1 Measured val...‹ appears. Coll 1 78.2°C Here, the temperatures and dates...

  • Page 67: Natural Gas

    OPERATION MODE ...›1.1.2 Service hours‹ appears. 1.1.2 Service hours The operating time of the activated plant Solar pump 1 112h components is displayed in hours. Solar pump 2 By actuating the menu item ›Reset‹, all counters are reset to zero. Reset The values are saved once per day, so that one day max.
  • Page 68 OPERATION MODE 1.1.4 Heat quantities ›1.1.4 Heat quantities‹ appears. Heat qty. 2 Up to two heat counters can be Diagram Week confi gured for the collection of the generated energy quantity. Heat qty. (calc.) The evaluation period can be selected via 108kWh the ›Diagram‹...
  • Page 69 OPERATION MODE 1.1.4.1 heat qty. 1 Return line sensor Return and feed sensors are assigned. Supply line sensor The fi lling can be defi ned as water, Tyfocor, propylene glycol or ethylene glycol. Glycol type ›Effi cient tank-charge‹ defi nes Water whether this heat quantity is used for effi...
  • Page 70 OPERATION MODE 1.10 Message list M05: ... the error message appears in plain text. Sensor short-circuit If necessary, take the appropriate measures. on TS3! Return to ›1 Main menu‹. Press ESC to return Continue with ›Settings‹. 04. 07. 2015 10:22 1.2 Settings Date/Time Language...
  • Page 71 OPERATION MODE 1.2.1 Date setting Date 04.07.2015 One group of fi gures each is activated and can be varied via the rotary encoder; Time 10:23 whenever ›OK‹ is pressed, the activation Auto. Clock Change jumps to the next group. Return to ›1.2 Settings‹. Continue with ›Language‹.
  • Page 72 OPERATION MODE If „Buzzer“ is activated, the controller also is- 1.2 Settings sues acoustic malfunctions and messages. Buzzer Before the SD card can be removed, ›Remove SD card safely‹ must have been selected. Rem.SD card safely With the „Save parameter“ function, the cur- Save parameter rent confi...
  • Page 73 OPERATION MODE 1.3.1 Thermostat R... Activation ...the appropriate activation screen is displayed. Return to ›1.3 Basic functions‹. Continue with ›Tube collector‹. 04. 07. 2015 10:25 1.3.2 Tube collector Activation ›1.3.2 Tube collectors‹ appears. This option is to be activated in case vacuum tube collectors are used.
  • Page 74 OPERATION MODE Edit Start ›Edit‹ appears. 19.07.2015 Here, the dates of your absence are Restore last value entered. Return to ›1.3 Basic functions‹. Factory settings Continue with ›Delta T control‹. 04. 07. 2015 10:26 ›1.3.5 dT control‹ appears. 1.3.5 dT control Here, parameters of the dT ON 1 8.0k...
  • Page 75 OPERATION MODE 1.3.8 Increase retu... ›1.3.8 Increase retu...‹ appears. Activation Parameters for return fl ow temperature T ON 8.0K increase can be defi ned here. T OFF 4.0K Ask a fi tter before making changes at this point. T min 15.0°C Return to ›1.3 Basic functions‹.
  • Page 76 OPERATION MODE 1.4.3 Disable recha..›1.4.3 disable recha...‹ appears. NLU at solar yield This option must be activated if tank recharge during solar charging is to be switched off Activ.time progr. depending on time or temperature. Activation T min. To this effect, the fi...

  • Page 77: Message List

    OPERATION MODE 1.5.5 Cooling funct. ›1.5.5 Cooling funct.‹ appears. Activation This option must be activated if, during a heat wave, the heat input exceeds the energy withdrawal. In this case, the controller cools the tank via the collectors, e. g. at night. Return to ›1.5 Protective functions‹.

  • Page 78: Access Code

    OPERATION MODE 1.7 Login Access code ›1.7 Login‹ appears. Here, the fi tter can enter his/her access code to perform further settings and changes. Return to ›1 Main menu‹. Continue with ›About‹. 04. 07. 2015 10:29 1.9 About HW version 8.00 ›1.9 About‹...

  • Page 80: Malfunction

    MALFUNCTION System 1 The „Attention“ symbol appears at the top right corner of the display. A fl ashing symbol indicates a pending mes- sage or an active safety function. A permanent symbol indicates that there is an active malfunction and the controller is in failure operation.
  • Page 81 MALFUNCTION Danger! Mortal danger due to electrocution! For troubleshooting on the plant, disconnect all poles of the power supply reliably and protect it them against being switched on again! 1.10 Service Wizard M02: ›1.10 Service Wizard‹ appears. Breakage of The malfunction appears in plan text - here: sensor on TS1! ›M02: Breakage of sensor on TS1!‹.
  • Page 82 MALFUNCTION 1.10 Service Wizard Please check the The controller here provides the troubleshoot- connection cable ing instruction to check the connection cable. to the sensor. Perform the measure in accordance with the recommendation. Next Acknowledge by pressing ›Next‹. 04. 07. 2015 10:33 1.10 Service Wizard Disconnect it...
  • Page 83 MALFUNCTION 1.10 Service Wizard Please replace Repair information appears. the cable. Perform the appropriate repair work. Exit the ›Service Wizard‹ Exit by pressing ›Exit‹. 04. 07. 2015 10:33 1.10 Service Wizard Could you detect a short-circuit / If the cause of the malfunction has not yet been determined, cable break? troubleshooting can be continued.
  • Page 84 MALFUNCTION 1.10 Service Wizard Please check Appropriate instructions appear the sensor for for each source of faults. plausible values. Perform the measure in accordance with the recommendation. Explanation Continue with ›Explanation‹. 04. 07. 2015 10:34 1.10 Service Wizard Disconnect it and measure A part of the information and instructions its resistor.
  • Page 85 MALFUNCTION 1.10 Service Wizard Is your measured value within After description of the troubleshooting this range? measure, the result determined by you is interrogated... 04. 07. 2015 10:34 1.10 Service Wizard Sensor is faulty and must be replaced..and the appropriate logical conclusion is made, the repair work displayed.

  • Page 86: Replacement Of Fuse

    REPLACEMENT OF FUSE Danger! Mortal danger due to electrocution! Before opening the terminal cover, disconnect the power supply reliably! To remove the device fuse, open the terminal cover. Above the right-hand group of terminals, the fuse base and a spare fuse are located.

  • Page 87: Professional Mode Is ›365

    PROFESSIONAL MODE Important! In professional mode, settings are made which require detailed knowledge of the heating and solar plant. Moreover, solid specialist knowledge regarding control engineering, hydraulics and solar thermal water heating is required! If a single parameter is changed, this may affect the safety, function and effi...
  • Page 88 PROFESSIONAL MODE 1 Main menu Evaluation Settings After having returned to ›1 Main menu‹, Basic functions the screen shows a list of subitems as in operation mode. Effi ciency functions Protective funct. 04. 07. 2015 10:32 1.1 Evaluation Measured values Service hours The menu ›1.1 Evaluation‹...
  • Page 89 PROFESSIONAL MODE 1.2 Settings Max.temp.shutoff After scrolling: Min. temperature - ›Min. temperature‹ Priority charging - ›Priority charging‹ Buzzer Call up menu item ›Temp. limitation‹. Rem.SD card safely 04. 07. 2015 10:33 If the temperature in tank 1 exceeds the 1.2.3 Temp.limitation value T limit 1, or if the temperature in tank 2 exceeds the value T limit 2, the solar Hyst...

  • Page 90: Professional Mode

    PROFESSIONAL MODE 1.2.6 Min.temperat... To increase effi ciency on charging Activation the tanks, the minimum temperature to be present at the collector in T min.Coll 1 20.0°C question is entered via ›T min. Coll‹. Hyst.Coll. 1 2.0K The relevant hysteresis value represents the difference between the switch-ON and switch-OFF temperature.
  • Page 91 PROFESSIONAL MODE 1.3 Basic functions ... and enhanced menus regarding the Commissioning - ›Holiday function‹ Delta T control - ›Delta T control‹ Fixed T control - ›Fixed T control‹ Increase return T - ›Increase return T‹ Post Heating Requ. Call up the menu item ›Thermostat‹. 04.
  • Page 92 PROFESSIONAL MODE 1.3.1 Thermostat R... Defi ne switch-ON/OFF temperature. T ON 40.0°C For the heating function, T ON must be < T OFF. T OFF 55.0°C For the cooling function, T ON must be > T OFF. t ON 1 00:00 Up to four time slots can be t OFF 1...
  • Page 93 PROFESSIONAL MODE 1.3.7 Output para... Tank ch.-over v 1 Boiler ›t tear-off‹ and ›n tear-off‹ defi ne how long and at which speed the t tear-off pumps are to run on starting. n tear-off 100% Select an output... Speed delta 04.
  • Page 94 PROFESSIONAL MODE 1.3.7 Solar pump 1 Algorithm ...to defi ne the required control algorithm as ›dT‹ or ›Fixed T‹. In case of plants with long piping or slow Overtravel time response, overtravel times for the solar circuit, pump and valve can be determined. n min.
  • Page 95 PROFESSIONAL MODE 1.3.2 Tube collector n solar 1 100% ... the pump delivery rate as a percentage value can be entered. t solar 2 The two time programs are n solar 2 performed one after the other. t start 06:00 Continue via the menu item ›Holiday function‹.
  • Page 96 PROFESSIONAL MODE Under ›n pump‹ set the 1.3.3 Holiday function pump speed in percent. n pump 100% Enter the hysteresis value by ›Hyst‹. Hyst. 5.0K If necessary, activate ›Soft charging‹ Soft charge ›dT‹ is used to defi ne the switch-ON temperature for the holiday function 5.0K as a difference from the preset...
  • Page 97 PROFESSIONAL MODE 0 Welcome You really want to Here, new commissioning start commission.? can be started - e. g. if a new hydraulic system is to be selected. => ›Commissioning mode‹ as of page 47. Continue with ›Delta T control‹. 04.
  • Page 98 PROFESSIONAL MODE 1.3.6 Fixed temp.c... If control algorithms have been Control 1 defi ned as ›Fixed T‹ under ›1.3.7 Output parameter‹, the Variant 1 appropriate outputs can be confi gured here. step-wise In case of the fi xed temperature control, the T fi...
  • Page 99 PROFESSIONAL MODE 1.3.10 Post Heatin... Activation ›Ref. temp.‹ is used to defi ne the set Ref. temp. temperature at the top tank sensor. 45.0°C Starting time If the temperature falls below ›Ref. temp.‹ 00:00 by ›Hysteresis‹, the control activates the End time 23:59 reheating cycle via the heating boiler until...
  • Page 100 PROFESSIONAL MODE 1.4.1 Low-Flow Activation T ON 60.0°C Here, the switch-ON temperature can be defi ned for low-fl ow plants. Continue with ›Quick-charging‹. 04. 07. 2015 10:38 1.4.2 Quick-charging Tank quick charging changes over from Activation dT control to fi xed temperature control. Sensors ›T ON‹...
  • Page 101 PROFESSIONAL MODE 1.4.3 disable rech... Activation T min. Select the minimum temperature via ›T min.tank‹. T min.tank 45.0°C 45.0°C Here, the effi ciency-optimized disable re- Activat.Tmin Float charge is enabled and activated - possible for all systems with heating boiler control. Continue to scroll.
  • Page 102 PROFESSIONAL MODE ›Effi cient tank charge‹ is activated and confi g- 1.4.4 Effi cient tank ch... ured here. The solar circuit pump is controlled according to the entered heat quantity. In Activation order to use this functionality, a heat quantity t del.after t ch.
  • Page 103 PROFESSIONAL MODE 1.5.2 Defrosting Activation ›Defrosting‹ can be used t defrosting to heat frozen collectors. 5min At the same time, the tank is cooled! Set the pump runtime. Continue with ›Antifreeze protect.‹. 04. 07. 2015 10:41 Note! The antifreeze protection function of the controller may prevent the heating system from damage which could be caused by freezing medi- um.
  • Page 104 PROFESSIONAL MODE 1.5.3 Antifreeze pr. T ON 5.0°C In the case of plants with two tanks, Glycol type the source of the anti-freeze protection heat must be selected by specifying Water ›Priority tank‹ or ›Secondary tank‹. Tank Continue with ›Anti-legionellae‹. Priority tank 04.

  • Page 105: Adjusting Balance

    PROFESSIONAL MODE 1.5.5 Cooling funct. Hyst.tank 1 2.0K Hyst.tank 2 2.0K If the adjusting balance is activated, the heat dissipated via the collector is deducted t-ON 00:00 from the energy balance calculation. t OFF 07:00 Continue with ›Soft charge‹. Adjusting balance 04.
  • Page 106 PROFESSIONAL MODE 1.6 Monitoring The following items appear under ›1.6. Moni- Message list toring‹ next to the operation mode menus: DiffTemp - ›DiffTemp‹ Volume fl ow - ›Volume fl ow‹ - ›Coll.Emerg.OFF‹ Coll.Emerg.OFF - ›Sensor balancing‹ Sensor balancing Call up the menu item ›DiffTemp‹. 04.
  • Page 107 PROFESSIONAL MODE 1.6.3 Phi monitoring phi min.error 0.10l/min Here, the parameters for volume phi circulation fl ow monitoring are defi ned. Continue with ›Coll. Emerg.OFF‹. 1.00l/min t undercut 04. 07. 2015 10:44 ›T limit Coll. 1‹ or ›T limit Coll. 2‹ are used to 1.6.4 Emerg.

  • Page 108: Manual Mode

    PROFESSIONAL MODE 1.7 Login Access code Manual mode Firmwareupdate USB Continue with ›Manual mode‹. 04. 07. 2015 10:47 Note! After the selection of the ›USB fi rmware update‹, the display fl ashes every second. Use a USB cable to connect to a PC already installed with update software.
  • Page 109 PROFESSIONAL MODE...

  • Page 110: Disassembly/Disposal

    DISASSEMBLY/DISPOSAL Danger! Mortal danger due to electrocution! Before opening the terminal cover, disconnect all poles of the power supply reliably! For disassembly of the differential temperature controller smart Sol, reverse assembly procedure: - Disconnect the power supply. - Open the terminal cover. - Disconnect all cables.

  • Page 111: Warranty And Liability

    WARRANTY AND LIABILITY The differential temperature controller smart Sol was developed, manufactured and tested according to stringent quality and safety specifi cations and corresponds to the state of the art. The device is subject to the warranty period prescribed by law of 2 years after the date of sale. The seller shall eliminate all defects in material and workmanship which occur on the product during the warranty period and which impair the product‘s functionality.

  • Page 112: Commissioning Report

    COMMISSIONING REPORT Name of operator and place of installation: Date of commissioning: Installed hydraulic system: Collector surface, in total [m Tank sizes [l]: Anti-freeze agent Type/concentration: Particularities: The solar thermal plant with the differential temperature controller smart Sol has been installed and commissioned in an expert fashion. The owner / operator of the plant was informed in detail and instructed as regards the design, operation, handling, especially in connection with the differential temperature controller smart Sol.

  • Page 113: Service Request

    SERVICE REQUEST Error pattern/error description: Error message: Software version: Service Wizard executed: Screens: TS1: TS2: TS3: TS4: Wiring: RO1: Pump Valve RO2: Pump Valve REL: Service hours: RO1: RO2: REL: Equipment/Accessories/Options: Important! For repair or replacement of the controller, make sure that completed copies of the commissioning report and of the error report are included!

  • Page 114: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY The manufacturer LK Armatur AB Garnisonsgatan 49 SE-254 66 Helsingborg Sverige declares in its sole responsibility that the following product: Differential temperature controller smart Sol to which this Declaration refers, complies with the following directives and standards:...

  • Page 115: Index

    INDEX ccess code alfunction 80 ff. Active system Manual mode Antifreeze Maximum temperature Anti-blocking Menu structure Anti-legionella function 41/104 Message list Automatic mode Minimum temperature reak-out segments 10/15 peration of the controller Brightness Output parameter 92 f. able cross sections hi monitoring Cable diameter Priority charge...
