Philips 24PHD5565/77 Service Manual

Philips 24PHD5565/77 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TPS20.1L
LA
Chassis name
Platform
Model name
24PHD5565/77
TPS20.1L LA
MSD92L
Published by Doris.zheng /SC 2042 Quality
Subject to modification
3122 785 21230
2020-Oct-13
2020
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24PHD5565/77 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips 24PHD5565/77

Summary of Contents for Philips 24PHD5565/77

  • Page 1 Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 3: Product Information

    ·720p-50Hz, 60Hz Supported TV mounts ·1080i-50Hz, 60Hz ·1080p-50Hz, 60Hz To mount the TV, please purchase a Philips TV mount or any TV mount compliant with the VESA standard. To prevent damage to cables and connectors, Multimedia be sure to leave a clearance gap of at least 2.2 •...
  • Page 4 Model No. RequiredPixel Required Mounting Screws Pitch (mm) 24PHD5565 100 x 200 4 x M4 (Minimum 12 mm, Maximum 14mm)

  • Page 5: Precautions, Notes, And Abbreviation List

    Refer to the diversity tables for the correct values. two pins of the Mains/AC Power plug. • The correct component values are listed on the Philips • Check the cabinet for defects, to prevent touching of any Spare Parts Web Portal.
  • Page 6 To avoid wear-out of tips, switch “off” unused equipment or reduce heat. • Mix of lead-free soldering tin/parts with leaded soldering tin/parts is possible but PHILIPS recommends strongly to avoid mixed regimes. If this cannot be avoided, carefully clear the solder-joint from old tin and re-solder with new tin.

  • Page 7: Abbreviation List

    possible dangerous impact, others of quite high potential Board-Level Repair are of limited current and are sometimes held in less BTSC Broadcast Television Standard regard. Committee. Multiplex FM stereo sound • Always respect voltages. While some may not be system, originating from the USA and dangerous in themselves, they can cause unexpected used e.g.
  • Page 8 G-TXT Green TeleteXT distance is 6.5 MHz. L' is Band I, L is all H_sync to the module bands except for Band I High Definition LG.Philips LCD (supplier) Hard Disk Drive Loudspeaker HDCP High-bandwidth Digital Content Protection: LVDS Low Voltage Differential Signalling A “key”...
  • Page 9 Serial Peripheral Interface bus; a 4-wire module, implementing the CA system for a synchronous serial data link standard host (e.g. a TV-set) S/PDIF Sony Philips Digital InterFace Power On Reset, signal to reset the uP SRAM Static RAM PSDL Power Supply for Direct view LED...
  • Page 10 Software 640 × 480 (4:3) SWAN Spatial temporal Weighted Averaging Variable Level out: processed audio Noise reduction output toward external amplifier SXGA 1280 × 1024 Vestigial Side Band; modulation method Thin Film Transistor WYSIWYR What You See Is What You Record: record Total Harmonic Distortion selection that follows main picture and TMDS...

  • Page 11: Mechanical Instructions

    3. Mechanical Instructions 3.1 Cable Dressing ECN9901 MAIN BOARD+POWER BOARD (1052) CN9901 CN408 CN401 CN601 ECN408 Cable dressing ECN601 ECN401 ECN601 LOUDSPEAKER LOUDSPEAKER (1184) IR BOARD (1184) (1056) ECN401 Back cover view...

  • Page 12: Assembly/Panel Removal

    3.2 Assembly/Panel Removal 3.2.1 Rear Cover Warning: Disconnect the mains power cord before removing the rear cover. 1. Remove all fixation screws [1] and [2] that secure the Back cover assy. 2. Unplug the connector that marked by red box below from SSB, and then remove the cable from the clips. 3.

  • Page 13: Stand Removal

    3.2.3 Stand removal 1. Remove the fixation screws [1] that secure the stand. 2. Take the stand bracket out from the set. 3.2.4 Small Signal Board (SSB) Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the SSB. 1.

  • Page 14: Lcd Panel

    3.2.5 Speakers 1. Gently release the tapes that secure the speaker cables. 2. Unplug the speaker connector from the SSB. 3. Take the speakers out. When defective, replace the both units. 3.2.6 LCD Panel 1. Remove the SSB as described earlier. 2.

  • Page 15: Service Modes

    4. Service Modes 4.1 Service Modes The Service Mode feature is split into following parts: Factory Mode.  Customer Service Mode (CSM).  Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. Some features are: Make alignments (e.g.
  • Page 16 How to Exit the Factory mode Select EXIT_FACTORY from the menu and press the “OK” button.  Note: When the TV is switched “off” by a power interrupt, or normal switch to “stand-by” while in the factory mode, the TV will show up in “normal operation mode”...

  • Page 17: How To Exit Csm

    How to Exit CSM To exit CSM, use one of the following methods. Press the MENU/HOME button on the remote control transmitter.  Press the POWER button on the remote control transmitter.  Press the POWER button on the television set. ...

  • Page 18: Check Software Version

    5. Software Upgrading, Error code and Panel Code 5.1 Software Upgrading 1. Put SW Bin file (e.g. PHILIPS_24PHD5565-77_LA_MSD92LCBWC1_715G9464_V2.003_20200717.bin) into the USB root directory, or rename it to CommonName (merge_tpv.bin). Turn on the TV. After the TV system is fully booted, plug the USB to TV. The TV will automatically pop up the upgrade menu.
  • Page 19 5.2.3 Method 3: Press RC HOME (MENU) to select the Settings menu, enter the second page of the Settings, and then select the "Software Version" item.

  • Page 20: Trouble Shooting

    Trouble shooting 2016年12月10日 2016/4/8 Picture-related Intermittent Ask Photo Picture ? problem ? Menu Smarkt Signal SW latest ? Backlight? issue function? issue SSB+LVDS+Panel Update SW LED working ? PSU/SSB Problem solved ? Sound ? PSU+ Panel Finish SW+SSB...
  • Page 21 Trouble shooting 2016年12月10日 2016/4/8 Audio/Sound- related Intermittent Sound ? problem ? Setting SW latest ? Mute ? issue issue Update SW Extra device Check extra connect? device Problem solved ? Factory setting Finish Sound back ? Setting issue SSB+SPK...
  • Page 22 6.Slow response to user interaction 7.Switches ON by itself 8.Switches Off by itself 9.Stuck in standby mode / unable to start up 10.Stuck on PHILIPS / ANDROID logo 11.CAM not recognized by TV 12.CAM authentication issue 13.Misc CAM issue 14.IP-EPG issues 15.BC-EPG issues...

  • Page 23: Electrical Diagram

    7.Electrical Diagram Block diagram Silicon Tuner MxL661-AG-R LVDS IF+/- DDR3-1600 1Gb/2Gb DEMOD SPIDF Out PC Audio in AUDIO AMP 5W SPK MSD92LCBW2 AD87010 CVBS / L / R 5W SPK HDMI1 CN501 Headphone HDMI2 w/ARC CN502 NOR/NAND CN102 FLASH Joystick KeyPad UART Remote Control...

  • Page 24: Power Supply

    7.2 Power Supply Power architecture of this platform. 7.3 Power tree Main Board Power System +12V_M B U601 AD87010 +12V_AUD For Audio Am plifier +12V_M B PANEL LVDS Pow er Q101 SM 4310PSKC U702 SY8234FCC +3.3V_Standby +5VSB U701 LD1117AG33AA3AR U401 M SD92LCBW2 For M SD92LCBW2 U403 M X25L6436FM 2I-08G For SPI Flas h...
  • Page 25 7.4 Power layout SSB L703 +5V_STB L702 +1.1V C731 +3.3V C121 +3.3V_TUNER Power SSB Top View Power SSB Bottom View...

  • Page 26: Ic Data Sheet

    8. IC Data Sheets 8.1 MSD92L (IC U401)
  • Page 27 8.2 AD87010-LG48NRY (IC U601)
  • Page 28 8.3 MxL661-AG-R (IC U102--Tuner)

  • Page 29: Circuit Diagrams

    9.Circuit Diagrams 9.1 715G9464 M+P Board 9-1-1 MSD92LCBW2 SPI & NAND HDMI CORE POWER DVDD_DDR POWER DDR POWER AVDD_DDR_CMD AVDD_DDR_DATA AVDD5V_MHL AVDD_MOD1 HDMI1-SCL AVDDL_DVI DVDD_DDR HDMI1-SCL HDMI1-SDA AVDD_DDR_DATA HDMI1-SDA AVDD_DDR_CMD AVDD3P3_ETH +1.5V_DDR I2SOUTC_BCLK HDMI1-HPD HDMI1-HPD +1.1V_VDDC VDDC AVDDL_DVI +1.1V_VDDC DVDD_DDR 60mA,15mil I2SOUTC_DATA HDMI1-ARC...
  • Page 30 9-1-2 NAND +3.3V_Standby +3.3V_NAND C409 C410 2.2UF 10V 100NF 16V...
  • Page 31 9-1-3 HDMI Inputs CN501 HDMI1-RX2P HDMID_5V HDMID_5V D2 Shield HDMI1-RX2N CEC/ARC HDMI1-RX1P D1 Shield HDMI1-RX1N HDMID_5V R506 R507 R588 HDMI_ARC C501 1UF 10V HDMI1-ARC HDMI1-RX0P 10K 1/16W 5% R505 D0 Shield HDMI1-RX0N HDMI1-CLKP R501 R508 1K 1/16W 5% 10K 1/16W 5% HDMID_HPD ARC_DEC CK Shield...
  • Page 32 9-1-4 AV/SPDIF/RJ45 CN101 Y_IN#1 Nearly Connector YPBPR_L_IN#1 R109 10K 1/16W 5% Y_IN#1 AV_IN YPBPR_AUL AV_IN ZD102 R107 YPBPR_R_IN#1 R111 10K 1/16W 5% YPBPR_AUR 75R 1/16W 1% R113 R114 RCA JACK ZD101 C101 ZD104 C110 Connected to connector GND 12K OHM 5% 1/16W 3.3NF 50V 3.3NF 50V 12K OHM 5% 1/16W...
  • Page 33 9-1-5 LVDS/USB/KEYPAD Outout LVDS Power +5VSB +12V_MB Panel_Vcc / 468mA R172 ∝ 24" R172 Panel=5V R173 0 OHM 1/8W For ≠ 28" R173 Panel=12V PANEL_VCC BCKM BCKM BCKP BCKP Q101 R150 C161 C145 C158 C148 R176 100NF 16V 150nF 16V 10UF 16V 10K 1/16W 5% 100NF 16V...
  • Page 34 9-1-6 Audio Amp/Headphone Output AMP_3V3 R633 I2SOUTC_DATA I2SOUTC_DATA PIN 7 I2SOUTC_WS R637 I2SOUTC_WS 0R05 1/16W PIN 6 R636 AMP_PDN I2SOUTC_BCLK I2SOUTC_BCLK I2SOUTC_DATA R621 SDATA R631 0R05 1/16W I2SOUTC_MCK I2SOUTC_MCK MI2C-SCL 33 OHM 1/16W R623 NC/10K 1/16W 5% I2SOUTC_MCK R630 33 OHM 1/16W NC/33 OHM 1/16W AMP-MUTE AMP-MUTE...
  • Page 35 9-1-7 System Power MAIN POWER 2014-03-06 Modified. 5V_SW R743 Change from 8.2K to 10K. For DQE Test Spec. BL_ON/OFF VBL_CTRL BL_DIM +3.3V_Standby +5VSB BL_DIM R722 BRI_ADJ BRI_ADJ BL_ON 4K7 1/16W 5% BL_ON PWR-ON/OFF R701 PWR-ON/OFF PS_ON R737 B ack Lig ht On / Off PS_ON BL_ON 1K 1/16W 5%...
  • Page 36 9-1-8 Tuner/Debug 3V3T R101 NC 1K 1/16W 1% FB108 D102 R127 Notch_On1 NC 1000R For tuner sensitivity : 20170614 NC BAR64-02V C137, L108  0 稼﹊ > 锣 BOM 穝 C136 NC 1.5K 1/16W C137 33pF 50V NC 1NF TU101 L108 3.3nH C197 NC 100NF 16V...
  • Page 37 9-1-9 AC Power PWR_12V 9,12 +12V T9102 BD9901 KBP208GL-C C9135 C9136 2N2 500V 2N2 500V POWER X'FMR FB9901 COLD D9131 TSD20H100CW 12VS 127R C9801 C9109 R9113 C9100 2.2NF C9131 C9132 C9133 C9134 82uF 450V 2.2NF D9105 1UF 50V 100nF 50V 470uF 25V 470uF 25V FR107G-A0...
  • Page 38 9-1-10 LED Driver L8602 D8601 12VS SR506-44 L8603 47uH VLED+ FB8601 D8602 127R SR506-44 C8601 C8605 C8603 C8606 C8607 330UF 35V R8603 R8604 100N 50V 1UF 50V 1UF 50V 330UF 35V 100K 100K R8612 33K 1/10W 1% R8605 Q8601 10 OHM 1% 1/10W CY S9240 32A R8619 D8603...

  • Page 39: 715Ga039 Ir/Led Panel

    9.2 E 715GA039 IR Board 9-2-1 IR&STB LED&Light sensor L i g h t S e n s o r DVD3V3 U222 DVD3V3 R 2 2 3 R 2 2 4 R 2 2 5 R 2 2 6 R 2 2 7 R 2 2 8 R 2 2 9 I I C...

  • Page 40: 715Ga966T Keyboard Control Panel

    9.3 E 715GA966T option board 9-3-1 Key...

  • Page 41: Styling Sheets

    10. Styling Sheets 10.1 5565 series 24” 1052 1184 1056 1050...

  • Page 42: Dismantling Procedure For Specific Handling Parts

    11. Dismantling procedure for specific handling parts As complete appliances, LCDs are deemed to be hazardous waste (e.g. 16 02 13*, 20 01 35*) in the EU according to the German Waste Catalogue Ordinance. These appliances may only be handled by authorized handling plants. LCDs must be stored in accordance with the requirements stipulated in Appendix VIII (1) or (2) of Directive 2012/12/EU and must, amongst other things, be stored in a weatherproof manner.
  • Page 43 These substances, mixtures and components shall be disposed of or recovered in compliance with Directive 2008/98/EC cathode ray tubes: the fluorescent coating has to be removed equipment containing gases that are ozone depleting or have a global warming potential (GWP) above 15, such as those contained in foams and refrigeration circuits: the gases must be properly extracted and properly treated.
  • Page 44 The diffusion panels can be accessed by lifting the inner casing, typically held in place with clips which can be removed with appropriate tools. The panel consists of several plastic sheets which can be processed. A final consideration is that of the back light which must be removed prior to processing.
  • Page 45 A Power cord or other external cables plugged into the back of the LCD can easily be removed by hand and/or screwdriver; 2 types of connection of power cord are typical as shown in the pictures. Capacitors > 25 mm are located in the power supply units and can be removed by nipper.
