- Page 1 10” Rack cabinets WF10-2304-10B, WF10-2304-10S, WF10-2306-10B, WF10-2306-10S, WF10-2309-10B, WF10-2309-10S User’s manual Instrukcja obsługi Návod k obsluze Návod na obsluhu 2021/09...
- Page 2 Lanberg brand owners reserve the right to make changes to this manual at any time without notice. The products mentioned in this manual, including the documentation, are the property of the Lanberg brand owners and its licensors.
- Page 3 • Place the device on a stable, dry surface in a well-ventilated place. Leave at least 100 mm of free space around it to ensure adequate ventilation. • The device is designed to work only in a controlled environment (controlled temperature and humidity according to the data in the specification, indoors, without conductive pollution present [dust, flammable gases, corrosive substances, etc.]). Lanberg © 2015-2021...
- Page 4 2 pcs 2 pcs Item I Hinge 2 pcs 2 pcs Item J Front door lock 1 pc. 1 pc. Item K Self-tapping screw M4*8 36 pcs 40 pcs Item L Metal expansion plug 2 pcs 2 pcs Lanberg © 2015-2021...
- Page 5 (item K). (Item F), using the self-tapping screws (Item K). Step 4. Prepare the rear panel (Item E) and fasten it to the side panels (item B), using the self-tapping screws (Item K). Lanberg © 2015-2021...
- Page 6 Fasten the top hinge (Item K) and the front door to the top panel. Step 6. Prepare the plugs (Item H) and attach them to the top and the bottom cover, using the self-tapping screws M4*8 (Item K). Lanberg © 2015-2021...
