TS10 scooter sample test instructions
Dear customer,
Thank you for testing TS10 shared scooter.The following instructions may
be helpful for your test.
1. Unpacking & Assembly
1) When you unpack the box, you need to install the pole and handlebar first;
2) Then you need to find the Front drum brake sheath and spring from the tool bag to
install the front brake cable and adjust the front brake cable. P.S.: We had to loosen
the front brake cable as we needed to loosen the front riser and handlebar while
packing. Hope you can understand.
3) Open the battery cabin cover, remove the battery pack, take a fuse from the tool
bag and insert it into the battery. P.S.: For transportation safety, we removed the
battery fuse when packing the scooter. The battery won't work until you insert a
fuse.
You can watch the video tutorial through this link,
https://drive.google.com/drive/folders/14eTjkLbLsrXOS0GEPiziIra-
MN8UF2Ac?usp=sharing
2. Install the sim card
1) Loosen the four screws on the side of the neck, remove the black plastic cover,
and you can see the IoT.
P.S.:① The screwdriver for loosening the screw is in the tool bag;
② To make it easier for customers to remove the black plastic cover, the factory
may only install two screws for you. In this case, the other two screws must be in the
tool bag.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TS10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FITRIDER TS10

  • Page 1 TS10 scooter sample test instructions Dear customer, Thank you for testing TS10 shared scooter.The following instructions may be helpful for your test. 1. Unpacking & Assembly 1) When you unpack the box, you need to install the pole and handlebar first;...
  • Page 2 2) Uncover the waterproof sticker on the iot, you can see the sim card slot. 3) Refer to the picture below, insert the sim card. Note: ① Before shipping, we have configured the firmware for iot according to the sim card APN you provided.
  • Page 3 When the white light is on, it basically means that the iot is connected to the network successfully, and you can start testing the iot and the scooter. White light: Always on→Connect to the base station; Turn off →Networking failure. Green light: Slow flash (on 0.2 seconds,off 1.8 seconds)→Searching for network signal;...
  • Page 4 {"a":1} is power on command.When you send {"a":1},you can turn on the scooter. ② For the iPhone, we recommend downloading MQTTool App; The tutorial is as follows,...
  • Page 5 During your test, if you have any questions, please do not hesitate to contact us in time. We will provide timely and professional 4S services.Thanks again! Hangzhou Feigu Technology Co.,Ltd. Fitrider shared scooter project team...
