Respawn RSP-110V2 Assembly

ASSEMBLY
RSP-110V2
I N S T R U C T I O N G U I D E
E
F
E
A B
1. Lay out and identify components on a 3. Install casters (F) by pushing casters
nearby table or flat surface. into 5-star base (E) until seated.
2. Unfold 5-star base (E) and lay color side
down on flat surface.
INSIDE
ALIGNMENT
G H
11. Grab the seat back (A) and slide the seat 13. Locate the 3 screws (L), lock washers
tail inside the seat mechanism bracket. (I), and flat washers (J). Feed screw (L)
through lock washer (I) followed by
12. Line up the holes so that you can see
flat washer (J).
the threaded seat tail screw holes
through the seat mechanism holes. 14. Start with the center top screw and
hand thread 2-3 rotations. You can
adjust chair back, as needed, to align
the other screw holes. Screw in the
other two screws 2-3 rotations.
RESPAWNPRODUCTS.COM
A B C
(x1) (x1) (x1)
PACKAGE
CONTENTS
C
E
D
C
4. Turn 5-star base (E) back over.
5. Place gas cylinder assembly (C) into
center of 5-star base (E) and then
install gas cylinder cover (D). Place
5-star base assembly on the floor.
L
O
I
J
I
15. Tighten the 3 seat back attachment
screws thoroughly with the Allen
wrench (O).
16. Velcro seat back trim flaps to the
seat base.
D E F G
(x1) (x1) (x5) (x2)
B
H
D E
6. Place seat bottom (B), bottom side up, 8. Locate the 4 screws (M) and washers (J).
on a flat surface. Feed screw (M) through washer (J).
7. Locate seat mechanism (H) and center 9. Hand thread all 4 screws 2-3 rotations to
ensure the proper seating of mechanism.
seat mechanism over screw holes in the
Go back and tighten seat mechanism screws
seat bottom with seat back bracket facing
thoroughly with the Allen wrench (O).
out and over the edge of seat bottom.
G
C
O
K
J K
17. Find arms (G), there is a right and a 19. Install screw cover caps (N) into the
left arm, and affix arms to the chair
with screws (K).
18. Tighten all 4 arm screws thoroughly
with Allen wrench (O).
H I J K L M
(x1) (x3) (x7) (x4) (x3) (x4)
M
J
O
F
10. Turn over seat bottom so the seat
mechanism is facing down, grab the
5-star base assembly and align gas
cylinder with hole on seat mechanism
as shown.
N
N
L
20. Last step is to sit in your new chair to
arm screw holes. fully secure the gas cylinder to the
seat assembly and make sure chair
is fully functional.
YOU'RE FINISHED, ENJOY!
N O
(x4) (x2)
