Respawn RSP-1063-BLK Installation Manual

Technical Data
1 stage
Column Stage
Max Loading Capacity 80KG
Height 725mm
Component List
Part
No. Qty
1 1
Table Board
Qty
No. Part No. Part Qty
2
3
2
2
Middle Crossbeam
Table Leg
No. Part Qty No. Part Qty
4 2 5 2
Left Crossbeam Right Crossbeam
No. Part Qty No. Part Qty
6 2 7 1
Table Foot Table Pad
INSTALLATION GUIDE
Item NO.: RSP-1063-BLK
Accessory List
Attention: The drawings below are for reference only, which might be slightly different from
the actual product. Any missing tools orinstallation issues, please contact customer service.
No. Image Spec
A
M6×16mm
B
M6 washer
C
M8×16mm
D
M8 washer
Hexagonal Wrench
5x5mm
E
Hexagonal Wrench
4x4mm
F
M6×10mm
G
ST4.8*16mm
H
M5 washer
I
St4.2x16mm
J
Gasket
7
1
3
4
2
6
Step 1
A
x8
E
4x4
Qty
8
16
8
Install table feet(6) and table legs(2)
together, use 4*4 wrench (E) to tighten
8
the screws (A).
1
1
16
Step 2
16
16
F
x8
4
B
2 x8
M6 washer
E
4x4
Step 3
C
x8
D
x8
5
M8 washer
E
5x5
Install the Table Feet(6)
2
6
E
3
B
F
4
E
A
5
Install the crossbeam(3) and crossbeam(4)
(5) together, use 4*4 wrench (E) to tighten
the screws (F).
E
D
C
