LOCO COOKERS LCFC2 Owner's Manual

Dual burner fry cart
Hide thumbs Also See for LCFC2:

Advertisement

Quick Links

Download this manual
Owners Manual
Assembly Instructions
Dual Burner Fry Cart
Model: LCFC2
WARNING
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE
OR OPERATE THIS PRODUCT.
Adult assembly required. Keep screws and parts out of reach of children.
INSTALLER: Leave this manual with the consumer. CONSUMER: Keep this manual for future reference.
LCFC2 • IM • 092024

Advertisement

loading
Need help?

Need help?

Do you have a question about the LCFC2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LOCO COOKERS LCFC2

Summary of Contents for LOCO COOKERS LCFC2

  • Page 1 READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children. INSTALLER: Leave this manual with the consumer. CONSUMER: Keep this manual for future reference. LCFC2 • IM • 092024...

  • Page 2: Safety Symbols

    DANGER This instruction manual contains important information necessary for the proper • Never operate this appliance assembly and safe use of the appliance. unattended. • Never operate this appliance within 10 ft Read and follow all warnings and (3.0 m) of any structure, combustible instructions before assembling and using material or other gas cylinder.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings 1, 3-6 Parts Diagram and Parts List Hardware Assembly Instructions 9-16 Operating Instructions 17-19 Care and Maintenance Troubleshooting Warranty Information WARNING Do not place an empty cooking pot on the appliance or allow a fi lled pot to boil dry while appliance is in operation. Use caution when placing anything in the cooking pot while the appliance is in operation.

  • Page 4: Warnings

    WARNINGS SAVE THESE INSTRUCTIONS • The installation must conform with local codes fi re department (911). A Type BC or ABC fi re or, in absence of local codes, with the National extinguisher may, in some circumstances, contain Fuel Gas Code, ANSI Z223.1/NFPA 54, Storage the fi...
  • Page 5 WARNINGS operation of this appliance. • Never attempt to attach this appliance to the self- contained LP gas system of a camper, trailer or • The appliance’s heat shields must always be in motor home. place during use. • Check burner/venturi tubes for insects and insect •...
  • Page 6 WARNINGS: LP TANK DANGER 5. When the appliance is not in use, the gas must be turned off at the supply cylinder. 1. Do not store a spare LP gas cylinder 6. Storage of an appliance indoors is under or near this appliance. permissible only if the cylinder is disconnected and removed from the 2.

  • Page 7: Lp Tank Filling

    WARNINGS: LP TANK LP TANK FILLING: LP Tank Leak Test Procedure: • Use only licensed and experienced dealers. • Use a clean paint brush and a 50/50 soap and water solution. • LP dealer must purge tanks before fi lling. •...

  • Page 8: Parts Diagram And Parts List

    PARTS DIAGRAM NOTE: Wash all parts that will come into contact with food with warm soapy water. Rinse and towel dry. Contact customer service if any parts are missing, damaged or if replacement parts are needed. customerservice@lococookers.com • lococookers.com...

  • Page 9: Assembly Hardware

    PARTS LIST Part # Description Qty Part # Description Thermometer Front Cart Brace Fry Pot Front Panel Small Fry Basket Cart Base Large Fry Basket Tank Retention Screw Cook Top Ignitor Burner Bracket/shield Control Panel Electrode Control Knob Bezel Burner Control Knob Valve/Hose/Regulator Assembly AA Battery...

  • Page 10: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Retention screw toward rear legs. Note: Right leg assembly has tabs for side shelf. Longer tubes on wheels face inward toward cart. Silver Black Silver = 2 Black Black = 2 Silver Note: Wheels are packaged inside of cook top.
  • Page 11 ASSEMBLY INSTRUCTIONS Screwdriver access holes Note: Do not fully tighten screws until all are in place. lococookers.com...
  • Page 12 ASSEMBLY INSTRUCTIONS Labeled Right Labeled Left...
  • Page 13 ASSEMBLY INSTRUCTIONS Remove wing nut and washer from burner and reuse to assemble burner bracket/ shield (6). Tabs on burner bracket align with slots on burner shroud. Holes on large burner shield align with posts on burner bracket. Back of cook top lococookers.com...
  • Page 14 ASSEMBLY INSTRUCTIONS Electrode Wires Correct Valve/Burner Engagement Burner Valve Plug electrode wires into back of ignitor.
  • Page 15 ASSEMBLY INSTRUCTIONS Angle shield into cart, above control panel and below front edge of cook top. lococookers.com...
  • Page 16 ASSEMBLY INSTRUCTIONS To lower side shelf: Lift and rotate downward. Repeat handle assembly on remaining two fry baskets 3 Thermometers clip to side of fry pots. Hardware J, K and L packaged separately Baskets rest on from hardware edge of pots for blister pack draining.
  • Page 17 ASSEMBLY INSTRUCTIONS WARNING Keep the ventilation openings of the cylinder enclosure free and clear from debris. See “OPERATING INSTRUCTIONS” for proper connection of regulator to Secure LP tank (sold separately) into LP tank valve. cart base with tank retention screw. lococookers.com...

  • Page 18: Operating Instructions

    OPERATING INSTRUCTIONS CONNECTING REGULATOR TO LP TANK: STEPS TO LEAK TEST: 1. Turn LP tank valve and all control knobs to 1. Place LP tank on a secure, level and stable the OFF position and make sure regulator is surface. tightly connected to LP tank.

  • Page 19: Burner Flame Check

    OPERATING INSTRUCTIONS INSTRUCTIONS FOR LIGHTING BURNERS: BURNER FLAME CHECK 1. Read all instructions before lighting. Only Light the burners and adjust the fl ames with light burners outdoors. the control knobs. Always check the fl ame prior to each use. The air dampers mounted on the 2.
  • Page 20 OPERATING INSTRUCTIONS DISCONNECTING REGULATOR FROM LP TANK: 1. Turn control knobs to the OFF position. 2. Turn LP tank OFF by turning hand wheel clockwise to a full stop. 3. Turn the coupling nut counterclockwise to loosen the connector. Loosen by hand only. DO NOT use tools.

  • Page 21: Care And Maintenance

    CARE AND MAINTENANCE PROPER CARE AND MAINTENANCE WILL steel wool. DO NOT spray oven cleaner on KEEP YOUR APPLIANCE OPERATING aluminum cooking pots to remove grease SMOOTHLY or soot as it will cause the fi nish to become dull. CAUTION If food remains stuck to the basket, place in hot water and allow to soak.

  • Page 22: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Burner will not light. Bad connection between the Make sure the regulator regulator and LP tank. coupling nut is fully tightened on the LP tank valve. The LP tank is empty. Refi ll LP tank at an authorized dealer or purchase new fi...

  • Page 23: Warranty Information

    LOCO LIMITED WARRANTY The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer/purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge (including regular shipping) for installation by the consumer for products that are covered by this Limited Warranty.
  • Page 24 LoCo - Crazy Good Cookers, Inc. 506 Manchester Expressway • Suite A2 • Columbus, Georgia 31904 800-391-0436 • Email: customerservice@lococookers.com Connect with us @lococookers • lococookers.com Made in China...
