Owners Manual

Assembly Instructions

BOILING KIT

Models: LCTSK42 • LCTSK60 • LCTSK80 • LCTSK90 • LCTSK100

WARNING

READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE

OR OPERATE THIS PRODUCT.

Adult assembly required. Keep screws and parts out of reach of children.

KEEP THIS MANUAL FOR FUTURE REFERENCE.

LCTSK42-60-80-90-100 • Boiling Kit • IM • 102324

Table of Contents

Need help?

Do you have a question about the LCTSK42 and is the answer not in the manual?

Questions and answers

Summary of Contents for LOCO COOKERS LCTSK42

Page 1 Owners Manual Assembly Instructions BOILING KIT Models: LCTSK42 • LCTSK60 • LCTSK80 • LCTSK90 • LCTSK100 WARNING READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children.
Page 2: Safety Symbols
DANGER This instruction manual contains important information necessary for the proper • Never operate this appliance assembly and safe use of the appliance. unattended. Read and follow all warnings and • Never operate this appliance within 10 ft instructions before assembling and using (3.0 m) of any structure, combustible the appliance.
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings 2, 4-7 Parts Diagram and Parts List Hardware Assembly Instructions 9-11 Operating Instructions 12-13 Care and Maintenance Troubleshooting Warranty Information WARNING Do not place an empty cooking pot on the appliance or allow a ﬁ lled pot to boil dry while appliance is in operation. Use caution when placing anything in the cooking pot while the appliance is in operation.
Page 4: Warnings
WARNINGS SAVE THESE INSTRUCTIONS • THIS APPLIANCE IS ONLY INTENDED FOR heated surface(s). HEATING WATER . . . NOT OIL OR GREASE. • This appliance is not intended for commercial • The installation must conform with local codes use. or, in absence of local codes, with the National •...
Page 5 Diameter liquid. Model Pot Capacity Dimensions • Never drop food or accessories into hot LCTSK42 42 Quarts W17.7”xL17.7”xH29.2” cooking liquid. Lower food and accessories LCTSK60 60 Quarts W18.9”xL18.9”xH32.5” slowly into the cooking liquid in order to...
Page 6 WARNINGS: LP TANK DANGER 5. When the appliance is not in use, the gas must be turned oﬀ at the supply cylinder. 1. Do not store a spare LP gas cylinder 6. Storage of an appliance indoors is under or near this appliance. permissible only if the cylinder is disconnected and removed from the 2.
Page 7 WARNINGS: LP TANK LP TANK FILLING: LP Tank Leak Test Procedure: • Use only licensed and experienced dealers. • Use a clean paint brush and a 50/50 soap and water solution. • LP dealer must purge tanks before ﬁ lling. •...
Page 8: Parts Diagram And Parts List
PARTS DIAGRAM NOTE: Wash all parts that will come into contact with food with warm soapy water. Rinse and towel dry. Part # Description Qty Part # Description Twist & Drain/Twist & Steam Basket Heat Shield Lid w/Lid Assist Hook Boiler Stand Cooking Pot Match Holder...
Page 9: Hardware
ASSEMBLY INSTRUCTIONS Tools required: Phillips head screwdriver • Adjustable wrench (Not included) Assembly Hardware M6x14 Screw M6 Flat Washer Do not fully tighten Venturi Tube screws at this time. Make sure venturi tube exits side of stand with two holes. Fully tighten screws.
Page 10 ASSEMBLY INSTRUCTIONS Fully tighten all four burner assembly screws after venturi shield is installed.
Page 11 ASSEMBLY INSTRUCTIONS TWIST & DRAIN 1. Lift the basket above the pot. 2. Rotate the basket 90 degrees. 3. Lower so that bottom tabs on basket rest on tabs inside pot for draining. TWIST & STEAM 1. Lower basket halfway into pot. 2.
Page 12: Operating Instructions
OPERATING INSTRUCTIONS CONNECTING REGULATOR TO LP TANK: 2. Completely open LP tank valve by turning hand wheel counterclockwise. If you hear 1. Place LP tank on a secure, level and stable a rushing sound turn gas oﬀ immediately. surface. This means there is a major leak at the 2.
Page 13 OPERATING INSTRUCTIONS 3. Ensure a BURNER FLAME CHECK minimum of 24 Light the burner and adjust the ﬂ ame with the inches (61 cm) regulator control knob. Always check the ﬂ ame separate the prior to each use. A blue ﬂ ame with little or no LP tank and the yellow ﬂ...
Page 14: Care And Maintenance
CARE AND MAINTENANCE PROPER CARE AND MAINTENANCE WILL steel wool. DO NOT spray oven cleaner on KEEP YOUR APPLIANCE OPERATING aluminum cooking pots to remove grease SMOOTHLY or soot as it will cause the ﬁ nish to become dull. CAUTION If food remains stuck to the basket, place in hot water and allow to soak.
Page 15: Troubleshooting
DETERMINING THE MAXIMUM FILL LEVEL WHEN USING A VESSEL WITHOUT A MAXIMUM FILL LINE: 1. Place your food into the basket. 2. Place the basket and food into the empty cooking vessel. 3. Fill the vessel with water just until the food is completely submerged. There must be a minimum of 3 inches (8 cm) between the water level and the top of the vessel.
Page 16: Warranty Information
LOCO LIMITED WARRANTY The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer/purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge (including regular shipping) for installation by the consumer for products that are covered by this Limited Warranty.

This manual is also suitable for:

Lctsk60 Lctsk80 Lctsk90 Lctsk100
