Owners Manual
Assembly Instructions
CART BOILER
Models: LCBR90KD • LCBR150KD
WARNING
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE
OR OPERATE THIS PRODUCT.
Adult assembly required. Keep screws and parts out of reach of children.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
LCBR90KD-LCBR150KD • 102924

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCBR90KD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LOCO COOKERS LCBR90KD

Summary of Contents for LOCO COOKERS LCBR90KD

  • Page 1 Owners Manual Assembly Instructions CART BOILER Models: LCBR90KD • LCBR150KD WARNING READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children. KEEP THIS MANUAL FOR FUTURE REFERENCE.
  • Page 2 • Extinguish any open fl ame. Main Max. Input Rating: • If odor continues, keep away from the appliance and immediately call your fi re MODEL LCBR90KD = 73,000 BTU/H department. MODEL LCBR150KD = 146,000 BTU/H Failure to follow these instructions could Certifi...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings 2, 4-7 Parts Diagram Parts List Hardware Assembly Instructions/Features 11-23 Operating Instructions 24-26 Care and Maintenance Troubleshooting Warranty Information lococookers.com...

  • Page 4: Warnings

    WARNINGS SAVE THESE INSTRUCTIONS • THIS APPLIANCE IS NOT FOR FRYING • Keep the fuel supply hose away from any heated TURKEYS. THIS APPLIANCE IS ONLY surface(s). INTENDED FOR HEATING WATER . . . NOT OIL • This appliance is not intended for commercial OR GREASE.
  • Page 5 • Never drop food or accessories into hot cooking LCBR90KD liquid. Lower food and accessories slowly into the cooking liquid in order to prevent splashing Burner or overfl ow. When removing food from the appliance, care shall be taken to avoid burns Orifi...
  • Page 6 WARNINGS: LP TANK DANGER 5. When the appliance is not in use, the gas must be turned off at the supply cylinder. 1. Do not store a spare LP gas cylinder 6. Storage of an appliance indoors is permissible only if the cylinder is under or near this appliance.
  • Page 7 WARNINGS: LP TANK LP TANK FILLING: LP Tank Leak Test Procedure: • Use only licensed and experienced dealers. • Use a clean paint brush and a 50/50 soap and water solution. • LP dealer must purge tanks before fi lling. •...

  • Page 8: Parts Diagram

    PARTS DIAGRAM NOTE: Wash all parts that will come into contact with food with warm soapy water. Rinse and towel dry. LCBR90KD LCBR150KD...

  • Page 9: Parts List

    PARTS LIST Part # Description Qty Part # Description Front Leg Assembly Cooking Pot Assembly Rear Leg Assembly Drain Valve (pre-installed/non-removable) Lower Right Panel Lower Left Panel Lid Chute Assembly Lower Heat Shield Match Holder Small Heat Shield Folding Front Shelf Wheel Cart Handle Axle...

  • Page 10: Assembly Hardware

    ASSEMBLY HARDWARE M6x16 Screw M6x12 Screw M4x10 Screw M8x35 Screw M8x45 Screw M8 Hex Nut M8 Axle Bolt AA Battery M6x22 Screw Tie Wire M6x13 Screw M5x12 Screw M4x10 Screw Tools required: Phillips head screwdriver • Adjustable wrench (Not included)

  • Page 11: Assembly Instructions/Features

    ASSEMBLY INSTRUCTIONS Small heat shields (6) mount under tabs on lower left panel (4) and lower right panel (3). Inside of cart lococookers.com...
  • Page 12 ASSEMBLY INSTRUCTIONS Longer section of wheel hub toward cart. Long side of bracket faces upward. Short side of bracket against panel.
  • Page 13 ASSEMBLY INSTRUCTIONS Feed regulator and hose through square hole in lower right panel. lococookers.com...
  • Page 14 ASSEMBLY INSTRUCTIONS Feed ignitor wires through large hole at bottom of right front leg. Electrode wires Ignitor wires After connections are complete, secure wires beneath cart with tie wire to avoid contact with ground.
  • Page 15 ASSEMBLY INSTRUCTIONS Repeat assembly procedure for front upper heat shield. lococookers.com...
  • Page 16 ASSEMBLY INSTRUCTIONS...
  • Page 17 ASSEMBLY INSTRUCTIONS lococookers.com...
  • Page 18 ASSEMBLY INSTRUCTIONS Open lid to rest on lid support.
  • Page 19 ASSEMBLY INSTRUCTIONS Slide Press lococookers.com...
  • Page 20 ASSEMBLY INSTRUCTIONS Positive (+) end of battery faces upward.
  • Page 21 ASSEMBLY INSTRUCTIONS Secure tank bracket in open position with hand screw. IMPORTANT: Make sure that gas hose is outside of center rail and below top rail of tank bracket. Secure hose to back of top rail with gas hose clamp (34) and two screws (N). lococookers.com...
  • Page 22 ASSEMBLY INSTRUCTIONS NOTE: LP Tank Not Included. Place LP tank onto tank bracket as illustrated, with tank valve opening facing to the rear. Rotate tank collar lock (35) to secure tank. Refer to: Operating Instructions - Connecting Regulator to LP Tank. Close tank bracket for Cart Boiler storage.
  • Page 23 Boiler Features Folding Front Shelf Bottle Opener Large 1.5” Drain Valve NOTE: LoCo Crazy Spoon and Wooden Paddle referenced below are sold separately. Slots for LoCo’s Crazy Spoon Storage Brackets (sold separately) Supports basket for hands-free draining and clean-out. Ideal for LoCo’s Crazy Spoon or Crazy Spoon wooden stirring...

  • Page 24: Operating Instructions

    OPERATING INSTRUCTIONS CONNECTING REGULATOR TO LP TANK: 2. Completely open LP tank valve by turning hand wheel counterclockwise. If you hear 1. Make sure LP tank is secured to tank a rushing sound turn gas off immediately. bracket with tank valve opening facing to This means there is a major leak at the the rear.
  • Page 25 OPERATING INSTRUCTIONS CAUTION 3. Open the LP tank valve fully by turning counterclockwise. If ignition does not occur in 5 seconds, 4. Turn the regulator control knob one rotation turn the regulator control knob OFF, wait 5 clockwise. minutes, then repeat the lighting procedure. If the burner does not light with the regulator 5.
  • Page 26 OPERATING INSTRUCTIONS DISCONNECTING REGULATOR FROM LP BOILING YOUR FOOD: TANK: Once the water comes to a rolling boil, wear 1. Turn regulator control knob protective gloves to prevent burns or scalding counterclockwise to the OFF position. while adding food to the basket. After food has been added, the approximate time for the water 2.

  • Page 27: Care And Maintenance

    CARE AND MAINTENANCE PROPER CARE AND MAINTENANCE WILL 6. To clean the burner tube/venturi, fi rst KEEP YOUR APPLIANCE OPERATING disconnect the regulator hose from the SMOOTHLY. CLEAN THOROUGHLY AFTER burner tube. Look inside the burner EVERY USE. tube for nests, webs or mud. To remove obstructions, use a fl...

  • Page 28: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Burner will not light. Bad connection between the Make sure the regulator regulator and LP tank. coupling nut is fully tightened on the LP tank valve. The LP tank is empty. Refi ll LP tank at an authorized dealer or purchase new fi...
  • Page 29 lococookers.com...

  • Page 30: Warranty Information

    LOCO LIMITED WARRANTY The appliance has been manufactured under the highest standards of quality and workmanship. We warrant to the original consumer/purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge (including regular shipping) for installation by the consumer for products that are covered by this Limited Warranty.
  • Page 31 lococookers.com...
  • Page 32 LoCo - Crazy Good Cookers, Inc. 506 Manchester Expressway • Suite A2 • Columbus, Georgia 31904 800-391-0436 • Email: customerservice@lococookers.com Connect with us @lococookers • lococookers.com Made in China...
