Assembly Instructions for
7ft Waterfall Module.
Fasteners.
Tools Needed:
(I) Hammer
(I) Power drill
(I) Level
*Suggested 18
guage Brad Gun
with 1-1/4 brad
nails will make
install easier.
Parts
(6) 2-1/2" Phillps
List:
screws for attaching
to wall.
(3) 1-1/4" Joining
Screws to attach to
other modules.
(4) 1-1/4" Shelf
screws.
(130) Nails
(6) Drywall Inserts
Waterfall 7
Advertisement
Related Manuals for Apex Digital Waterfall 7
Summary of Contents for Apex Digital Waterfall 7
- Page 1 Assembly Instructions for Waterfall 7 7ft Waterfall Module. Fasteners. Parts (6) 2-1/2” Phillps List: screws for attaching to wall. Tools Needed: (3) 1-1/4” Joining Screws to attach to (I) Hammer other modules. (I) Power drill (4) 1-1/4” Shelf (I) Level screws.
- Page 2 Assembly Instructions for 7ft Waterfall Module. Racking IB-Waterfall 7 84” (1) Custom Ladder 76-1/2” (1) 1x2 Side Trim 11/16” + 24 + 11/16” w/mitered ends (1) Custom Ladder Note the BACK spacerbar is determined by the nails showing from the 1x2 side used...
- Page 3 Front Spacerbar Middle Ladder Step 2 Step 2: (Attaching 39” middle ladders) Take the five 39” middle Right End ladders and place each ladder Ladder into the spacerbar slots and from the FRONT on Left all three front spacerbars. End Ladder Step 1 Step 1: (Attaching first two front spacebars) Front Spacerbar...
- Page 4 Step 6 Step 5 Custom Step 5: (Attaching spacerbars to Step 6: ( Placing Custom Ladder opposite side) tabletop) Ladder Veneer Take all remaining spacerbars Place the tabletop Table and attach in the same place as onto the base of front side.
- Page 5 Step 8 Cont.: Placement of Waterfall Near Other Racks VOID WATERFALL...
- Page 6 Fastener Placement Guide (130) nails —Nail one at every (6) screws point where for securing the front the tabletop and back if desired. — spacerbars Fasten from intersect a underneath ladder as shown.
