Assembly Instructions for
7ft QR Module.
Fasteners.
Tools Needed:
(I) Hammer
(I) Power drill
(I) Level
*Suggested 18
guage Brad Gun
with 1-1/4 brad
nails will make
install easier.
Parts
(8) 2-1/2" Phillps
List:
screws for attaching
to wall.
(6) 1-1/4" Joining
Screws to attach to
other modules.
(36) 1-1/4" Shelf
screws.
QR-7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Apex Digital QR-7
Summary of Contents for Apex Digital QR-7
- Page 1 Assembly Instructions for QR-7 7ft QR Module. Fasteners. Tools Needed: Parts (8) 2-1/2” Phillps List: screws for attaching (I) Hammer to wall. (I) Power drill (6) 1-1/4” Joining (I) Level Screws to attach to *Suggested 18 other modules. guage Brad Gun (36) 1-1/4”...
- Page 2 Assembly Instructions for 7ft QR Module. (1) Side (1) Back Panel Panel Angled 1-1/4”W 11-15/16”W 1 x 2 ends on x 84- x 84-13/16” QR-7 Vertical front. 13/16” Pieces Square ends on back (6) Quarter Round Shelves Quarter Round Pieces...
- Page 3 QR-7 mounted square to the wall or 13/16” Trim to another modular rack. The trim other rack. board is used to fill in the gap between the QR-7 and the wall. Back Panel Side Panel QR-7 Quarter Round Shelf...
- Page 4 Fastener Placement Guide (8) screws for attaching the panels to each other (36) screws for attaching the Closeup shelves to the panels. -Screw through backside of panels wherever there is a pre-drilled hole. A1 Closeup QR-7...
