PNO4 Installation Manual Addendum
We suggest using a mobile device instead of the PNO4 unit.
1 Open your smart device to Settings then Wi-Fi.
2 Tap the QRS4
Wi-Fi & enter password qrsmusic & Join.
##
3 Open a web browser, Safari or Chrome, and enter 10.3.2.1 in the address bar,
"Search or enter website" and then tap go.
4 The QRS
MANAGE USERS
5 To skip creating a QRSConnect account, Select ADMIN now.
If a profile has been created, then tap the PROFILE.
6
QRS
logo to return to the Home screen.
Tap the red
The PNO4 doesn't have to be linked to the Internet to finish the setup procedures but, you
can update the software and the music if it has Internet access.
1 Tap
System Setups
2 Select your shop's Wi-Fi, enter the Wi-Fi password & tap Connect.
3
You will see
CURRENTLY CONNECTED TO:
Wi-Fi NAME ON CHANNEL ##, WITH A SIGNAL OF
-## DBM
IP: ###.###.#.## BCAST: ###.###.#.## MASK 255.255.255.0
IF YOU DON'T SEE THE IP, BCAST and MASK, then the unit hasn't connected to the router.
Usually caused by entering the wrong password or password type.
Verify that the Network Mode is DHCP Client.
The system is now linked to Wi-Fi and has access to the Internet for operating system and music
updates. There are now two ways to connect to the PNO4 system; via the QRS Wi-Fi or the shop
Wi-Fi. Smart devices, laptops or computers that are connected to your Wi-Fi have access to the
PNO4 system via the QRS Finder App or the IP address that the router has assigned to PNO4.
Wi-Fi logo
4
Tap the
to display the Ethernet Standalone & Wireless "Home"
The 10.3.2.1 is the QRS Wi-Fi and Client is your home Wi-Fi.
If the PNO3 had a Ethernet cable connected to the router or extender an IP address would
appear under ETHERNET SETTINGS.
Jot down the Client IP address displayed on the Screen:______________
Home
PNO4 Installation Manual Addendum
QRS Music Technologies, Inc.
Connecting to the System
Verify that the Power LED is ON.
Connect to QRS Wi-Fi & Add Profile
"Who's Playing?" page will open.
Select ADD PROFILE to create a customer profile.
You will be asked to create a QRSConnect account.
The information entered and recordings available at QRSConnect.com.
A QRSConnect account will be necessary to use Sessions or QRSTV.
QRSConnect allows users to connect and collaborate on music projects.
Link PNO4 to Wi-Fi
/ Network / Wireless Client and Connect to Client Wi-Fi.
Profile
System Settings
Revision Date: 202410011
1
qrsmusic.com
Make note of IP # before
going to the next page.
File System Version 1.18
800.247.6557
#####
