OmniMetrix TrueGuard-2 DeepSea 4520 Installation Manual

Advertisement

Quick Links

1. Unpack the monitor and antenna. Check the integrated
cables for shipping damages.
2. Place the antenna vertically on the generator roof, ensuring
20 cm separation from people and other transmitters. Use
a drip loop to prevent water damage.
3. Attach the monitor to the engine controller. Mount
horizontally ideally, but vertical or upside-down is
possible—install vertically with cables down to prevent
water ingress.
4. Attach the antenna cable to the monitor's front and tighten
it.
5. Wiring instructions listed below on Table 1.
6. DSE Configuration Suite Software to configure Digital
Outputs (Table 2)
7. Allow 15 minutes for network login. Confirm installation by
calling OmniMetrix or access machine data via OmniView
web interface at https://webdata.omnimetrix.net.
OmniMetrix 4295 Hamilton Mill Rd., #100
Buford, GA 30518 770-209-0012
P a g e | 1
TrueGuard-2™
DeepSea 4520
Installation Guide
Deep Sea 4520 Controller
Deep Sea 4520 Controller (Back)

Advertisement

loading
Need help?

Need help?

Do you have a question about the TrueGuard-2 DeepSea 4520 and is the answer not in the manual?

Questions and answers

Summary of Contents for OmniMetrix TrueGuard-2 DeepSea 4520

  • Page 1 Deep Sea 4520 Controller Outputs (Table 2) 7. Allow 15 minutes for network login. Confirm installation by calling OmniMetrix or access machine data via OmniView web interface at https://webdata.omnimetrix.net. Deep Sea 4520 Controller (Back) OmniMetrix 4295 Hamilton Mill Rd., #100...
  • Page 2 In Auto Gray Low Fuel Alarm Table 2 If you have any questions, please call OmniMetrix Tech Support on 770-209-0012 or email at techsupport@omnimetrixconnect.com OmniMetrix 4295 Hamilton Mill Rd., #100 Buford, GA 30518 770-209-0012 P a g e | 2...
