Summary of Contents for Sherpa PEAK 2.2
- Page 1 DC OUTPUT DC INPUT 12V-30A(MAX) 12V-5A 12V-10A 32V~95V 12V~18V 700W(MAX) 100W(MAX) 12V-10A AC INPUT AC OUTPUT-2200W 100W 220V~240V-10A(MAX) Please read the user manual thoroughly before using...
-
Page 2: Table Of Contents
CONTENTS Box Contents ································ 01 Charging Times ································ 01 Specifications ································ 02 Function Overview ································ 03 How to use the PEAK 2.2 ····························· 04-10 Display Overview ································ 04 UPS Mode ································ 05 Adjusting Settings ···························· 05-06 Adding Extra Capacity ·······························... -
Page 3: Box Contents
9~10 Hours 5~6 Hours 3.5~4 Hours MC4 Solar Charging Cable The solar charging time depends on weather conditions and panel tilt. PEAK 2.2 has a built-in MPPT charge controller that supports 32-95V, 15A PV charging up to 700W. -
Page 4: Specifications
SPECIFICATIONS Capacity Battery Type Charging Time Protections Temperature Dimension Net Weight Over-Voltage, LiFePO4 Battery 0.9H to 80% 1536Wh 0℃~45℃/32°F~113°F Overheat, Retains 80%+ 1.8H to 100% (120Ah) L377*W237*H305 (Charging) 18kg Overload, Original Capacity -20℃~45℃/-4°F~113°F Short-Circuit, At 3500 Cycles (Discharging) Self-Recovery OUTPUT SPECS AC Out *2 USB-A *4 USB-C *2... -
Page 5: Function Overview
FUNCTION OVERVIEW ⑦ ⑧ ① ⑨ DC OUTPUT ⑩ DC INPUT ⑪ ② 12V-30A(MAX) ⑫ 12V-5A 12V-10A ③ 32V~95V 12V~18V 700W(MAX) 100W(MAX) 12V-10A AC INPUT AC OUTPUT-2200W ④ ⑬ 100W ⑤ 220V~240V-10A(MAX) ⑥ ⑭ ① ② ③ LCD Display DC 32V-95V Charging Port DC 12V-18V Charging Port ④... -
Page 6: How To Use The Peak 2.2
Temperature Alarm Icon AC Overload Alarm Icon The operating temperature range of PEAK 2.2 is -20~45°C. If it PEAK 2.2 can power most devices with power consumption outputs high power in a hot conditions for a long time, the high less than 2200 watts. -
Page 7: Ups Mode
UPS MODE The PEAK 2.2 supports UPS function. It can provide the loads (such as computers, data centres, telecommunication equipment) Near-instantaneous (8-20ms) protection from unexpected power interruptions from the main power supply. Note: Not suitable to specific applications that need transfer time under 8ms, such as servers and workstations. - Page 8 Setting 002 - AC output voltage: Short press DC to adjust voltage to 220 or 230V. Short press AC to go to the next option. Setting 003 – No-load auto shut off timer (default OFF). The unit detects when there is no AC load and starts the timer for auto OFF to save energy.
-
Page 9: Adding Extra Capacity
After cascading the extra battery successfully, the display will show the total percentage of the host and the extra battery capacities. CHARGING THE PEAK 2.2 1. GX16MF-5 Charging Port: PV/DC (operating voltage) range 32V-95V, 700W maximum; Voc (open circuit voltage) of solar panel/array must be less than 95V or it will damage the unit. -
Page 10: Solar Charge Configurations
MC4 Solar Charging Cable*1 The Voc of a single solar panel should not exceed 95V, and the Vmp should be greater than 32V. Use two solar panels in series to charge the PEAK 2.2 MC4 Solar Charging Cable*1 The Voc of each solar panel should not exceed 48V, and the Vmp of each should be greater than 16V. Series wiring... - Page 11 SOLAR CHARGE CONFIGURATIONS Using multiple solar panels in parallel to charge the PEAK 2.2 (It is recommended to use solar panels of the same specification and model to obtain the best results.) MC4 Solar Charging Cable x 1 Y Branch MC4 Charging Cable(+) x 1 Y Branch MC4 Charging Cable(-) x 1 (NOTE ：...
- Page 12 CAUTION - THREE SOLAR PANELS IN SERIES CAN DAMAGE THE UNIT. *PV (GX16MF-5) Port will only accept 32V-95V Open Circuit voltage, exceeding 95V will damage the MPPT.
-
Page 13: Faqs
Q1 ： What kind of battery is used in PEAK 2.2 unit and what is its life expectancy? A ： PEAK 2.2 utilises high quality UL certified automotive LiFePO4 battery cells, it can retain 80% of its original capacity at 3500 complete charge cycles. -
Page 14: Disclaimer
In compliance with laws and regulations, Sherpa Tek Ltd reserves all rights for final explanation, and to change these terms and conditions at any time without prior notice. In the event that any revisions are made, the revised terms and conditions shall be posted on our website immediately, please visit our website to inform yourself of any changes. -
Page 15: Disposal
8. When using this product, please follow the ambient temperature guidelines in the user manual. If the battery temperature becomes excessively high, it can degrade the capacity as would exposure to an excessively low temperature environment. 9. Do not stack heavy objects on this product. 10. -
Page 16: Warranty Exclusions
9. Warranty period expired. 10. The battery model on the warranty certificate does not match the actual item. 11. Unauthorised alteration on the warranty certificate. 12. Product wear and tear from general use. CUSTOMER SUPPORT ： www.sherpapower.co.uk www.sherpapower.co.uk Sherpa Tek Ltd. - Page 18 www.sherpapower.co.uk...
