ILLUSTRATION OF HOW TO INSTALL THE CIRCUIT

Temperature probe
Power
plug
1
56
Controller
Circulating
pump
2 3 6 4 5
ATTENTION!
T2 should be inserted into the collector outlet.
Sight glass
Temperature
probe
1) Power
2) Electric water heater
3) Circulation pump
4) T1 tank temperature probe
5) T2 collector temperature probe
6) Sight glass
