FOREWORD
Dear Customer,
We hope you enjoy your new Leica Cine Play 1 smart mini projec-
tor. Please begin by reading this manual thoroughly to familiarize
yourself with the full scope of functions your projector has to offer.
Complete information about the Leica Cine Play 1 smart mini pro-
jector is available at
https://leica-smartprojection.com.
Leica Smart Projection GmbH
IMPORTANT NOTICE
Compatibility with third-party products, software, and services is
not guaranteed. We cannot be held liable for any damage or loss
caused by the operation or use with or connection to incompatible
devices or apps.
Recording and playback of content on this unit or any other device
may require permission from the owner of the copyright or other
rights to that content. It is your responsibility to ensure that the use
of this unit or any other device complies with the copyright laws ap-
plicable in your country. For more information on the relevant laws
and regulations, please refer to the applicable laws or contact the
owner of the rights to the content you wish to record or play back.
All rights reserved.
Direct current (DC): this symbol indicates that nominal
voltage marked with the symbol is DC voltage.
Please read the "Legal information" and "Safety informa-
tion" sections before using the projector for the first time to
prevent product damage, injuries, and other risks.
28
FOREWORD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cine Play 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Leica Cine Play 1

Summary of Contents for Leica Cine Play 1

  • Page 1 FOREWORD Dear Customer, We hope you enjoy your new Leica Cine Play 1 smart mini projec- tor. Please begin by reading this manual thoroughly to familiarize yourself with the full scope of functions your projector has to offer. Complete information about the Leica Cine Play 1 smart mini pro- jector is available at https://leica-smartprojection.com.

  • Page 2: Scope Of Delivery

    Here's how it works: →Visit: https://club.leica-camera.com →If you do not yet have a Leica account, you can create one here in just a few steps. →After logging into your Leica account, you will be redirected to the registration page for your new Leica product.

  • Page 3: Warranty Conditions

    SCOPE OF THE LEICA SP WARRANTY We grant the following Leica SP warranty for this Leica product, in- cluding the accessories contained in the original packaging. Please note that we do not provide a warranty for commercial use of our product.
  • Page 4 Leica SP Dealer. We reserve the right to ask you to submit the original receipt. IF YOUR PRODUCT NEEDS SERVICE, PLEASE CONTACT US WITH PROOF OF PURCHASE BEFORE SENDING IN...

  • Page 5: Legal Information

    LEGAL INFORMATION The terms HDMI and HDMI High-Definition Multimedia Interface and the HDMI logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. FOR DTS PATENTS, SEE HTTP://XPERI.COM/ DTS-PATENTS/. MANUFACTURED UNDER LI- CENSE FROM DTS, INC.

  • Page 6: Regulatory Information

    SIMPLIFIED EU DECLARATION OF CONFOR- MITYFOR GREAT BRITAIN: Leica Smart Projection GmbH declares herewith that radio equip- ment type “Leica Cine Play 1, Version GB” complies with The Radio Equipment Regulations 2017. The British Declaration of Conformity in its entirety is available at: https://leica-camera.com/en-int/downloads...
  • Page 7 [FOR PRODUCT UNDER PSTI REGULATIONS 2023] Leica declares that the product is in conformity with the Product Se- curity and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products) Regulations 2023. THE BELOW IS THE SUMMARY FOR THE SOC • Product Name: Leica Cinema TV/Monitor/Projector • Model Numbers: Leica Cine Play 1 (Art.
  • Page 8 DISPOSAL WEEE (directive on waste electrical and electronic equipment) European Directive 2012/19/EU This symbol on the product or on the pack- aging indicates that the product must not be disposed of with household waste. Instead, it is your responsibility dispose of your old unit at a collection point designated for the recycling of waste electrical and electronic equipment.

  • Page 9: Safety Remarks

    SAFETY REMARKS INTENDED USE AND AMBIENT CONDITIONS This unit is intended for the playback of video and audio signals in a home or office environment. It must not be used in rooms with high levels of humidity or dust concentration. • Do not expose this unit to rain, moisture, drips or splashes of water and do not place objects filled with liquids such as vases, cups, etc.

  • Page 10: General Information

    GENERAL INFORMATION The smart mini projector can fall and cause serious injury or death. Many injuries, especially to children, can be avoided by taking the following simple precautions: • Always use cabinets, stands or mounting methods recommended by the smart mini projector manufacturer. • Always use furniture that can safely support the smart mini pro- jector.
  • Page 11 POWER SUPPLY • Incorrect voltage can damage the unit. The unit must be connect- ed to a power supply with the correct voltage and frequency specified on the rating plate using the power cable supplied. • The power plug must be easily accessible, so that the unit can be disconnected from the power supply at any time.
  • Page 12 VENTILATION AND HIGH TEMPERATURES • The unit must be set up in a well-ventilated location. Ensure that there is at least 20 cm of clearance on all sides for air circulation. 20 cm 20 cm 20 cm • The underside of the unit where the swivel bracket is located must be kept clear.

  • Page 13: Cleaning And Care

    VOLUME • Loud music and noises can cause irreversible damage to your ears. Avoid extreme volume levels, especially over long periods of time and when using headphones. • If you hear a booming noise in your ears, turn down the volume or temporarily remove your headphones.
  • Page 14 PACKAGING • Keep anti-moisture material and plastic bags out of the reach of children. • Plastic bags can cause suffocation and the anti-moisture material is harmful if swallowed. If it is accidentally swallowed, induce vomiting and go to the nearest hospital. MODIFICATIONS • Do not attempt to modify this product in any way.
  • Page 15 LASERS Do not look directly into the lens when the unit is switched on, as the laser light can damage your eyes. This unit is equipped with a laser module. This unit must not be damaged or modified in any way; otherwise injuries may occur. IEC 62471-5: 2015 LASER PRODUCT CLASS 1 IEC 60825-1: 2014...
  • Page 16 OVERVIEW OF SMART MINI PROJECTOR  1   2   3   1  CMOS image sensor module For autofocus and automatic keystone correction  2  ToF sensor For autofocus and eye protection  3  Lens OVERVIEW OF SMART MINI PROJECTOR...

  • Page 17: Detection Range Of The Sensors

    DETECTION RANGE OF THE SENSORS CMOS image sensor module: Horizontal angle of view: 77° ± 3° Vertical angle of view: 62° ± 3° Diagonal angle of view: 90° ± 3° Time of Flight sensor: Horizontal angle of view: 60° Vertical angle of view: 45°...
  • Page 18 OVERVIEW OF PORTS ON THE SMART MINI PROJECTOR  1   2   3   4   5   6   7   8   1  Audio out  2  HDMI 1 (eARC)  3  HDMI 2  4  USB 3.0  5  USB 3.0  6  Digital audio out  7   8  Power connector OVERVIEW OF PORTS ON THE SMART MINI PROJECTOR...

  • Page 19: Overview Of Remote Control

    OVERVIEW OF REMOTE CONTROL  1  Projector on/off  1   8   9   2  Activate automatic focus  3  Navigation buttons  10   2   4  Quick access image mode  11   5  Volume up/down  3   6  Mute/unmute  7  Access menu or pair re-  4   12   13  mote control via Bluetooth (press and hold button)  8 ...

  • Page 20: Basic Settings

    NOTE: • The remote control included in the scope of delivery varies de- pending on the model and country/region. Check the informa- tion on the remote control. • Insert two AAA batteries. Make sure that the positive and neg- ative poles of the batteries match the (+) and (-) markings inside the battery compartment.
  • Page 21 AUTOMATIC FOCUS When the automatic focus function is activated, the unit automati- cally adjusts the focus to obtain a sharp projector image. • Activate the automatic focus function by pressing the button on the remote control. • You can activate the manual focus function by pressing and hold- ing the button and adjusting the focus manually by pressing the navigation buttons on the remote control.

  • Page 22: Troubleshooting

    TROUBLESHOOTING If you are experiencing a problem with your projector, switch it off and on again. If this does not solve the problem, follow the sugges- tions below. When the projector is switched on, there is a delay of a few seconds before the image appears • This is normal, because the projector is initializing and searching for previous settings information.

  • Page 23: Product Specifications

    Fan fault Flashing three Error in the digital micro mirror times device (DMD) of the projector If you have additional questions, contact Leica Customer Care at customer.care@leica-camera.com. PRODUCT SPECIFICATIONS Disclaimer: All products, product specifications and data can be modified without advance notice to improve the reliability, function, design, or other factors.
  • Page 24 Network standby power ≤ 2.0 W consumption Power consumption in ≤ 0.5 W standby mode WLAN IEEE 802.11 a/b/g/n/ac/ax Bluetooth Bluetooth 5.3 Order numbers for the various models and information on coun- try-specific differences in the technical data can be found at www. leica-smartprojection.com. PRODUCT SPECIFICATIONS...
