- Page 1 Lenco Pro Control ™ Trim Tab System Installation Instructions...
-
Page 2: Table Of Contents
Warranty Policy ........... . . 19 Pro Control Keypad Cutout Template ....... . 20 CONGRATULATIONS! You have just purchased the finest trim tab system in the world! Welcome to the future. -
Page 3: Safety
Installation of Trim Tab Blades To begin, determine the location on the transom of the vessel where the TRANSOM Lenco Trim Tab Kit will be installed. Fig 1 Note: When determining the desired tab location, hold the tab against the transom with the bottom of the hinge knuckle (the lowest point on the hinge) 3/8"... -
Page 4: Actuator Installation
Note: You must use supplied hardware provided Using the 3/16" (.48 cm) drill bit, drill the by Lenco Marine. The hardware provided has previously marked hole locations to a depth of specific lengths and thread lock compound 1-1/4"... - Page 5 Actuator Installation lencomarine.com Ensure the actuator is fully retracted by rotating installing Standard Mount kits, the distance from the shaft of the ball screw clockwise as the shaft the bottom of the transom to the top of the upper faces you, as shown below. mounting bracket should or shall not exceed 14"...
- Page 6 Actuator Installation lencomarine.com Using the 3/16" (.48 cm) drill bit, drill the four WARNING: Installer must leave adequate previously marked screw hole locations to a wire loop as to not pull wire from actuator! depth of 1-1/4" (3.18 cm). Deutsch Connection Assembly Instructions, First Upper find 2 pin connector insert 16 GA red wire into slot Mounting...
-
Page 7: Keypad Installation
At the helm, determine where the tactile keypad will be installed (see Pro Control Keypad Cutout template on page 20) and secure to helm with tape. Cut a circular opening using a 2-1/16"... -
Page 8: Network And Power Wiring
3 amp circuit protection National Marine Electronics Association (supplied with most kits). (nmea.org) F. Pro Control Auto requires the Pro Control A. Connect the N2K cable from keypad to the Auto IMU for functionality (see following NMEA backbone already contained in boat. -
Page 9: Commissioning Pro Control, Assist And Auto
.5 m (20") Min Commissioning Pro Control, Assist and Auto Entering Setup Menu Manually The Pro Control system will automatically enter its commissioning menu upon the initial powerup. Should you need to access this manually, refer to the instructions below, otherwise skip... -
Page 10: Power First Time Set Up
Commisioning: Power first time set up lencomarine.com Power first time set up The Pro Control system will default to each menu on the first-time power up and continue through each option until all menu choices are completed. Data Verification This function indicates which boat systems the Pro Control keypad detects. -
Page 11: Actuator Commissioning
L2K system. The Pro Control Auto keypad auto detects the actuators. 1. Rotate the dial counterclockwise until the third The Pro Control Auto keypad may also be used to LED is flashing on left side dial LEDs. assign actuator location: port; or starboard. -
Page 12: Power First Time Set Up: Exiting First Time Power Up Locating
First time power-up after actuator locating and calibration; this is an automatic commissioning for the Pro Control Auto keypad, even if the system is powered OFF and then back ON. This process Entering must be completed prior to normal operation. -
Page 13: Set Pitch Control To On Or Off
(1 foot or less of water chop is preferred). Note: On first time power up Pro Control Auto will be in a commisioning mode with lights flashing fast in sync! The following two steps must be completed on open water with less than 1’... -
Page 14: High Speed Pitch Control Set Up
Sea Trial Commissioning lencomarine.com f. Press and hold DIM ( ) button 1 second to store the slow pitch control target, both Left and Right-side LEDs will flash three times. The left side LEDs will return to steady state lit. This indicates that the slow pitch control has been stored. -
Page 15: Disposal
Disposal Environmental Compliance Statement All Pro Control products that are subject to the Directive 2012/19/EU are compliant with the WEEE marking requirement. Such products are marked with the “crossed-out wheelie bin” WEEE symbol (shown below) in accordance with European Standard EN 50419. -
Page 16: Troubleshooting
Troubleshooting: Pro Control Assist lencomarine.com Troubleshooting Troubleshooting Pro Control Assist Symptom Status Cause Resolution Keypad does not Condition: Keypad not powered Secure all NMEA® and respond to inputs keypad NOT lit by L2K bus, as L2K cabling connections: required ensure Purple wire is... -
Page 17: Troubleshooting Pro Control Auto
Troubleshooting: Pro Control Auto lencomarine.com Troubleshooting Pro Control Auto Symptom Status Cause Resolution Keypad does not Condition: Keypad not powered Secure all NMEA® and respond to inputs keypad NOT lit by L2K bus, as L2K cabling connections: required ensure Purple wire is... -
Page 18: Notice
The contents of this manual are subject to change without notice and do not constitute a commitment on the part of Lenco Marine LLC. Every effort has been made to ensure the accuracy of this document. However, due to ongoing product... -
Page 19: Warranty Policy
There are no other warranties which extend beyond that set forth above. Lenco Marine LLC., reserves the right to void any warranty claim if the part is opened or repair was attempted, without the express written consent from Lenco Marine LLC. -
Page 20: Pro Control Keypad Cutout Template
Keypad Cutout Template lencomarine.com Pro Control Keypad Cutout Template 2.8" 70 mm 4.4" 111 mm ø2-1/16" ø52 mm... - Page 21 lencomarine.com...
- Page 22 Precision. Confidence. Adventure. LNC-015-TL-0624...
