- Page 1 PRO700 OPEN BURNERS AUTHENTIC COOKING EQUIPMENT INSTALLATION MANUAL APPLICABLE TO: INSTALLATION MANUAL V07000 V07001 V07006 V07007 V07123 FR_PRO700_G-FN-REV. C V07124 V07125 V07126 Written by ECE on 28/10/19 Revised by JGD on 11/06/20...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ___________________________________________________________________________ 1 1. FOREWORD ____________________________________________________________________________________________________ 1 2. USEFUL CONTACT DETAILS ________________________________________________________________________________________ 1 3. WARRANTY ____________________________________________________________________________________________________ 1 4. RESTRICTIONS ON USE ___________________________________________________________________________________________ 1 5. EQUIPMENT DISPOSAL ___________________________________________________________________________________________ 1 INSTALLATION ____________________________________________________________________________ 2 1. GENERAL ______________________________________________________________________________________________________ 2 2. HANDLING ____________________________________________________________________________________________________ 2 3. - Page 4 BASIC EMERGENCY SPARE PARTS ____________________________________________________________ 15 1. OPEN BURNERS ________________________________________________________________________________________________ 15 2. GAS OVEN _____________________________________________________________________________________________________ 16 INSTALLATION MANUAL FR_PRO700_G-FN_REV. C...
-
Page 5: Revision History
REVISION HISTORY Revision index Author of the revision Date of the revision Nature of the revision 28.10.2019 Use of original manual – Scope of application extended to other similar appliances 11 June 2020 New cast-iron griddles for open burners INSTALLATION GUIDE FR_PRO700_G-FN_REV. -
Page 7: Introduction
1. F OREWORD Thank you for choosing Charvet equipment for your installation. Our equipment is designed and manufactured in France by our teams, who are committed to meeting five targets: Robustness, performance, hygiene, ergonomics, and safety. If, however, despite our commitment and effort, you encounter a problem with one of our products, please get in touch with our After-sales service. -
Page 8: Installation
INSTALLATION 1. G ENERAL The installation must be performed by a certified installer, who will install the equipment in compliance with the instructions provided in this manual and in compliance with local regulations. Attention must be paid to the local regulations concerning fire prevention. 2. -
Page 9: Electrical Connection
ELECTRICAL CONNECTION Instructions for the electrical connection of the appliance: • Do not work on live cables. • The appliance must be earthed. • Use 245 IEC 57 or 245 IEC 66 standard cables (or other cables with similar characteristics). •... -
Page 10: Gas Connection
GAS CONNECTION Instructions for the connection of the gas-powered appliance: • The device must be installed according to best practice or else in accordance with the reference standards or the instructions in this manual. • This appliance is an A-type and must not be connected to a flue gas pipe. •... -
Page 11: Starting Up
STARTING UP 1. G ENERAL Once the appliance has been installed, remove all protective plastic wrapping, then test each function of the appliance; please refer to the paragraph on ‘Normal use’ in this user manual. If the test is successful, the appliance should be fully cleaned, in accordance with the instructions given in the paragraph on ‘Cleaning’ in the user manual, before delivery from the site to the end customer. -
Page 12: Functional Testing
3. F UNCTIONAL TESTING Before carrying out the functional tests, supply the appliance with gas (open the upstream block valve), and electricity (if the appliance is equipped with an electrical function or option). Open burners Press down the gas tap of one of the burners, then turn it to the ‘ignition’ position ( Proceed with the ignition of that burner: ▪... -
Page 13: Adjustments - Maintenance
ADJUSTMENTS – MAINTENANCE Instructions for maintenance operations on an electric appliance or for implementing electric power: Before any work: • Disconnect the appliance from its power supply at the circuit breaker. • Use a suitable checking device to check that there is no voltage present. WARNING The rules laid down in the ‘Electrical Connection’... -
Page 14: Combustion Control (Injectors, Air Supply)
Once the control panel has been removed, it is then possible to access the gas manifold, this is the tube on which all of the appliance’s gas valves are mounted, then: • Locate the brass plug on the manifold and unscrew •... -
Page 15: Procedure For Replacing Injectors And Adjusting Air Sleeves - Open Burners
Procedure for replacing injectors and adjusting air sleeves – Open burners To access an open burner, proceed as follows: Remove the pan holder, burner cap, and the drip tray. Once the drip tray has been removed, reposition the burner cap(s) on the safety blocks. -
Page 16: Electric & Gas Diagrams
ELECTRIC & GAS DIAGRAMS 1. W IRING DIAGRAM 1-2-point electric ignition INSTALLATION MANUAL FR_PRO700_G-FN_REV. C... -
Page 17: 3-5-Point Electric Ignition
3-5-point electric ignition INSTALLATION MANUAL FR_PRO700_G-FN_REV. C... -
Page 18: Electric Oven
Electric oven INSTALLATION MANUAL FR_PRO700_G-FN_REV. C... -
Page 19: Gas Diagrams
2. G AS DIAGRAMS Open burner gas tap Nomenclature Item Description Gas inlet Burner gas outlet Regulator adjustment screw Thermocouple return Pilot light gas outlet Fig. 12 Open burner Nomenclature Item Description Main burner gas inlet Pilot light gas inlet Burner cap Burner body Thermocouple... -
Page 20: Oven Gas Tap
Oven gas tap Nomenclature Item Description Gas inlet Pilot light gas outlet Main burner gas outlet Max. output adjustment screw Thermocouple return Pressure gauge outlet at input stage (not used) Gas tap axis Thermostat axis control Minimum output adjustment screw Pressure gauge outlet at output stage (not used) Solenoid valve Fig. - Page 21 BASIC EMERGENCY SPARE PARTS 1. O PEN BURNERS Ref. Description Photo Ref. Description Photo 505722 Open burner valve 00290 A Open burner thermocouple 501929 Thermocouple coil 505690 Gas tap knob 172094 Full burner ø80 06976 A Burner cap ø80 F12669 Full burner ø100 06977 A Burner cap ø100...
- Page 22 2. G AS OVEN Ref. Description Photo Ref. Description Photo 08425 A Thermostatic valve 170846 Oven burner 07550 A Propane gas pilot light 07551 A Natural gas pilot light 506245 Thermostat 0 ~ 300°C 505957 Oven thermocouple Spark plug 505690 Gas tap knob 05315 A 505724...
- Page 23 PRO700 OPEN BURNERS AUTHENTIC COOKING EQUIPMENT USER MANUAL APPLICABLE TO: USER MANUAL V07000 V07001 V07006 V07007 V07123 FR_PRO700_G-FN_REV. C V07124 V07125 V07126 Written by ECE on 28/10/19 Revised by JGD on 11/06/20...
- Page 25 CONTENTS INTRODUCTION ___________________________________________________________________________ 1 1. FOREWORD ____________________________________________________________________________________________________ 1 2. USEFUL CONTACT DETAILS ________________________________________________________________________________________ 1 3. WARRANTY ____________________________________________________________________________________________________ 1 4. RESTRICTIONS ON USE ___________________________________________________________________________________________ 1 5. END-OF-LIFE RECYCLING OF THE APPLIANCE _________________________________________________________________________ 1 USE ____________________________________________________________________________________ 2 1. WARNINGS ____________________________________________________________________________________________________ 2 2. CONTROLS ____________________________________________________________________________________________________ 2 Burner control - ‘full or low’...
- Page 26 REVISION HISTORY Revision index Author of the revision Date of the revision Nature of the revision 28.10.2019 Use of original manual – Scope of application extended to other similar appliances 11 June 2020 New cast-iron griddles for open burners USER MANUAL FR_PRO700_G-FN_REV.
- Page 27 1. F OREWORD Thank you for choosing Charvet equipment for your installation. Our equipment is designed and manufactured in France by our teams, who are committed to meeting five targets: Robustness, performance, hygiene, ergonomics, and safety. If, however, despite our commitment and effort, you encounter a problem with one of our products, please get in touch with our After-sales service.
- Page 28 Some parts of this appliance are protected by the manufacturer, in case of a fault, contact the installer for replacement or repair. Neither the CHARVET company nor the installation company shall be liable for damage and/or injuries resulting from improper maintenance, misuse, or unauthorised modification of this appliance.
-
Page 29: Turning The Appliance Off
Electric oven control (thermostat) Nomenclature Item Description Switch – Top Switch – Base Switch – Top + Base gentle Switch – Top + Base intense Heating-up light – Top Heating-up light – Base Settings range Off position (at the switch or at the thermostat) Fig. -
Page 30: Cleaning And Maintenance
CLEANING & MAINTENANCE 1. W ARNINGS Before cleaning the appliance, make sure that the parts to be handled have cooled down or equip yourself with suitable protection. It is preferable to clean and maintain this equipment after switching it off. This appliance must not be cleaned by means of water spray, water jets under pressure or steam.
