IMPORTANT INSTRUCTIONS When using electrical heaters, basic precautions should al- 14. Do not allow combustible materials to come into contact ways be followed to reduce the risk of fire, electric shock and with the heater and keep them at least 3 ft (0.9 m) away personal injury, including the following: from it, as they could catch fire more easily than adjacent surfaces.
Page 3
INSTALLING THE INFRARED PATIO HEATER TAKE A FEW MINUTES TO READ THE USER'S GUIDE CAREFULLY. IT WILL HELP ENSURE A SAFE AND EASY INSTALLATION. WHAT'S IN THE BOX Infrared patio heater Installation template 3 connection caps 1 cord grip compatible 4 notched with a flexible cable with a tightening nuts...
Page 4
DETERMINING THE INFRARED PATIO HEATER LOCATION The heater can be mounted horizontally on a wall or ceiling on wood, gypsum, metal, brick, stone or concrete surfaces. The surface must be strong enough to support the weight of the heater and flat enough for the brackets to be aligned. Make sure that the anchor can support the total weight of the heater, including the mounting brackets.
Page 5
WARNING: The infrared patio heater must be installed by a certified electrician in accordance with the electrical and building codes in effect in your region. CUTTING THE POWER SUPPLY 1. To protect yourself against the risk of electric shock, cut the power supply to the wires coming from the electrical panel.
Page 6
5. Remove the sticker [E] that is blocking the opening at the back of the electronic module. 6. Unscrew the nut [F] on the cable clamp [G]. Insert the cable clamp in the opening behind the electronic module and tighten the nut from the inside. NOTE: The cord grip supplied is compatible with a 0.264 in (6.7 mm) to 0.472 in (12 mm) diameter flexible cable.
Page 7
3. Fully assembly one (1) screw into the centre hole 2. Secure the two (2) installation hooks [A] to the wall of each of the installation brackets [B] in the or ceiling as shown. orientation shown. NOTE: For wall installation, it is important to install the hook with the openings facing upwards, as shown.
CONNECTING THE ELECTRICAL WIRES 1. If necessary, use wire strippers to strip the WIRING DIAGRAM power cable wires. 2. Insert the power cable wires into the junction L2/N box and through the cord grip, then tighten the cord grip. 3. Connect the power cable wires to the heater wires as shown in the diagram on the right.
INSTALLING THE REMOTE CONTROL HOLDER 1. Decide where you want to install the remote control and its 3. Separate the remote control adapter [A] holder. Keep in mind that they must be installed indoors. A from the holder [B] and set aside. Then space 1.6 in (40 mm) by 3.4 in (86 mm) is required.
Indicates the time remaining on the timer. ERROR CODE E0, E1, E2 The electronic board has detected a problem. Please contact Stelpro Customer Service. The ambient temperature is outside the product's operating temperature range of -35°C to 35°C (-31 °F to 95 °F).
The heater isn’t heating. • If the heater stops working after a long period of use, the remote control’s battery may need replacing. • If the problem persists, the control module or an infrared lamp may be defective. Please contact Stelpro Customer Service.
(other than that prescribed by STELPRO) or a use other than that for which the unit was designed; CLAIM PROCEDURE 3) a natural disaster or an event out of STELPRO’s control, including,...
